TWIST 100 1 lamp

recessed

Quickinfo

3000 K, 3500 K, 4000 K
CRI ≥ 90 / 2 SDCM
up to 141 lm/W
L80 / 50000 h
DALI-2, non DIM
front IP20, back IP20

Colour

    • Mounting set

    • Products and codes
    Discover family

    Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    Download all
    • 3DS
    • DWG - 3D
    • Revit BIM data

    Description

    Round recessed spotlight in die-cast aluminium; powder coated; installation without tools in mounting set (trimless or with trim) with ball catch system; 360° rotatable and 45° tiltable outward; COB (Chip on Board) technology for maximum efficiency; no multiple shadows; energy-efficient LEDs with very good colour rendering; high quality reflector with spherical facet finish; precise radiation characteristic; optical attachments as accessories; optical attachments can be combined

    360° rotatable, 45° tiltable

    optical accessories can be combined (max. 2)

    Products and codes

    Filter
    136
    lm/W
    141
    lm/W
    3100
    lm
    3200
    lm
    0.54
    0.78
    0.49
    0.71

    Colour

    • Mounting set

    • TWIST 100 trim

    TWIST 100 trim black

    TWIST 100 trim black

    Status
    Article number(s)
    Type
    Dimming
    black, Mounting set jet black, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    non DIM
    black, Mounting set jet black, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    DALI-2
    black, Mounting set jet black, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    non DIM
    black, Mounting set jet black, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    DALI-2
    black, Mounting set jet black, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    non DIM
    black, Mounting set jet black, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    DALI-2
    black, Mounting set jet black, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    non DIM
    black, Mounting set jet black, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    DALI-2
    black, Mounting set jet black, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    non DIM
    black, Mounting set jet black, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    DALI-2
    black, Mounting set jet black, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set jet black, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    DALI-2
    black, Mounting set jet black, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set jet black, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    black, Mounting set jet black, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    non DIM
    black, Mounting set jet black, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    DALI-2
    black, Mounting set jet black, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set jet black, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    TWIST 100 trim

    TWIST 100 trim black

    TWIST 100 trim black

    Status
    Article number(s)
    Type
    Dimming
    white, Mounting set jet black, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    non DIM
    white, Mounting set jet black, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    DALI-2
    white, Mounting set jet black, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    non DIM
    white, Mounting set jet black, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    DALI-2
    white, Mounting set jet black, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    non DIM
    white, Mounting set jet black, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    DALI-2
    white, Mounting set jet black, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    non DIM
    white, Mounting set jet black, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    DALI-2
    white, Mounting set jet black, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    non DIM
    white, Mounting set jet black, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    DALI-2
    white, Mounting set jet black, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set jet black, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    DALI-2
    white, Mounting set jet black, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set jet black, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    white, Mounting set jet black, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    non DIM
    white, Mounting set jet black, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    DALI-2
    white, Mounting set jet black, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set jet black, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    TWIST 100 trim

    TWIST 100 trim white

    TWIST 100 trim white

    Status
    Article number(s)
    Type
    Dimming
    black, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    non DIM
    black, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    DALI-2
    black, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    non DIM
    black, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    DALI-2
    black, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    non DIM
    black, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    DALI-2
    black, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    DALI-2
    black, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    DALI-2
    black, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    TWIST 100 trim

    TWIST 100 trim white

    TWIST 100 trim white

    Status
    Article number(s)
    Type
    Dimming
    white, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    non DIM
    white, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    DALI-2
    white, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    non DIM
    white, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    DALI-2
    white, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    non DIM
    white, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    DALI-2
    white, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    DALI-2
    white, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    DALI-2
    white, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    TWIST 100 trimless

    TWIST 100 trimless

    TWIST 100 trimless

    Status
    Article number(s)
    Type
    Dimming
    black, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    non DIM
    black, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    DALI-2
    black, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    non DIM
    black, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    DALI-2
    black, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    non DIM
    black, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    DALI-2
    black, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    DALI-2
    black, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    DALI-2
    black, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    black, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    TWIST 100 trimless

    TWIST 100 trimless

    TWIST 100 trimless

    Status
    Article number(s)
    Type
    Dimming
    white, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    non DIM
    white, Mounting set traffic white, 39° flood, 3000 K, system 25.3 W, 137 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 3000 K, system 25.3 W, 139 lm/W
    DALI-2
    white, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    non DIM
    white, Mounting set traffic white, 20° spot, 3000 K, system 25.3 W, 136 lm/W
    DALI-2
    white, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    non DIM
    white, Mounting set traffic white, 39° flood, 4000 K, system 25.3 W, 139 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 4000 K, system 25.3 W, 141 lm/W
    DALI-2
    white, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set traffic white, 20° spot, 4000 K, system 25.3 W, 138 lm/W
    DALI-2
    white, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set traffic white, 39° flood, 3500 K, system 25.3 W, 138 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 3500 K, system 25.3 W, 140 lm/W
    DALI-2
    white, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    non DIM
    white, Mounting set traffic white, 20° spot, 3500 K, system 25.3 W, 138 lm/W
    DALI-2

    Accessories

    Converter

    article number
    power
    voltage / frequency
    protection class
    constant current
    POWER SUPPLY
    002-90780
    31 W
    min 50 Hz
    max 60 Hz
    PC21
    constant current 650 mA
    POWER SUPPLY
    002-90789
    28 W
    min 50 Hz
    max 60 Hz
    PC21
    constant current 650 mA

    Mounting

    article number
    colour
    dimensions
    cut out dimensions
    MOUNTING SET trimless
    048-2796117
    traffic white
    RAL 9016
    diameter 105 mm
    height 29 mm
    0.09 kg
    diameter 106 mm
    MOUNTING SET with trim 1 lamp
    048-2796317
    traffic white
    RAL 9016
    diameter 118 mm
    height 40 mm
    0.07 kg
    diameter 108 mm
    MOUNTING SET with trim 1 lamp
    048-2796318
    jet black
    RAL 9005
    diameter 118 mm
    height 40 mm
    0.06 kg
    diameter 108 mm

    Electrical components

    article number
    type
    dimensions
    THROUGH WIRING CONNECTION BOX
    005-2531110
    non DIM cable ø 4 – 12 mm, Linect®-Ready
    length 105 mm
    width 58 mm
    height 30 mm
    0.06 kg
    THROUGH WIRING CONNECTION BOX
    005-2551110
    DALI cable ø 4 – 12 mm, Linect®-Ready
    length 105 mm
    width 58 mm
    height 30 mm
    0.07 kg

    Optical

    article number
    dimensions
    HONEYCOMB LOUVER
    080-6401118
    diameter 75 mm
    height 9 mm
    0.01 kg
    LINEAR PRISMATIC LENS
    080-6402110P
    diameter 75 mm
    height 9 mm
    0.02 kg
    SNOOT short
    080-6403118
    diameter 66 mm
    height 23 mm
    0.02 kg
    SNOOT medium
    080-6403218
    diameter 66 mm
    height 38 mm
    0.03 kg
    SNOOT angle
    080-6403318
    diameter 66 mm
    height 38 mm
    0.02 kg

    Related products

    TWIST 100

    2 lamps recessed

    UNICO

    pro recessed

    UNICO L2 / L3

    basic recessed

    UNICO L4 / L6

    basic recessed

    UNICO Q1 / Q4

    basic recessed

    UNICO Q1

    sensor recessed

    UNICO Q9

    basic recessed
    New Version

    SASSO 40

    round recessed 1 lamp
    New Version

    SASSO 40

    round recessed 2 lamps
    New Version

    SASSO 60

    round recessed 1 lamp
