SASSO PRO 100 adjustable offset trimless;SASSO PRO 100 adjustable offset trimless concrete
SASSO PRO 100 adjustable offset trimless;SASSO PRO 100 adjustable offset trimless concrete
SASSO PRO 100 adjustable offset trim round;SASSO PRO 100 adjustable offset trim round concrete
SASSO PRO 100 adjustable offset trim round;SASSO PRO 100 adjustable offset trim round concrete
SASSO PRO 100 adjustable offset trimless;SASSO PRO 100 adjustable offset trimless concrete
SASSO PRO 100 adjustable offset trimless;SASSO PRO 100 adjustable offset trimless concrete
SASSO PRO 100 adjustable offset trim round;SASSO PRO 100 adjustable offset trim round concrete
SASSO PRO 100 adjustable offset trim round;SASSO PRO 100 adjustable offset trim round concrete

SASSO PRO 100 adjustable offset round

recessed

Quickinfo

2700 K, 3000 K, 4000 K, colour warm dimming, tunable white
CRI ≥ 90, CRI ≥ 92, CRI ≥ 95 / 3, 4 SDCM
UGR < 19
up to 105 lm/W, inset up to 124 lm/W
L80 / 50000 h, L85 / 50000 h, L90 / 50000 h
DALI-2, DALI-2 DT8, non DIM
front IP20

Colour

  • Mounting set

  • Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    • 3DS
    • DWG - 3D
    • Revit BIM data

    Description

    Round recessed spotlight in die-cast aluminium; installation without tools in mounting set (trimless or with trim) with ball catch system; surface powder coated; light inset rotatable and tiltable; offset lighting level; optical attachments available as accessories; high-quality reflector with spherical facet effect design, precise radiation characteristics with different beam angles; installed and exchanged without tools; COB (Chip on Board) technology for maximum efficiency; no multiple shadows; efficient LEDs with very good colour rendering

    DiiA® standards 251, 252, 253

    rotatable 360°, tiltable 35°

    Colour Warm Dimming 2000 – 3000 K

    tunable white 1800 – 3000 K or 2700 – 6500 K

    Dieser Bereich wird neu geladen sobald ein Eingabefeld geändert wird.

    Products and codes

    Filter
    57
    lm/W
    105
    lm/W
    853
    lm
    2840
    lm
    14.7
    W
    28
    W
    0.49
    1.15
    0.44
    1.04

    Colour

  • Mounting set

  • SASSO PRO 100 adjustable offset trim round;SASSO PRO 100 adjustable offset trim round concrete

    SASSO PRO 100 adjustable offset trim round

    SASSO PRO 100 adjustable offset trim round

    Status
    Article number(s)
    Type
    Dimming
    black, Mounting set jet black, 38° flood, 2700 K, 14.7 W, 90 lm/W
    non DIM
    black, Mounting set jet black, 24° medium, 2700 K, 14.7 W, 89 lm/W
    non DIM
    black, Mounting set jet black, 17° spot, 2700 K, 14.7 W, 90 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 2700 K, 14.7 W, 84 lm/W
    non DIM
    black, Mounting set jet black, 38° flood, 2700 K, 14.7 W, 90 lm/W
    DALI-2
    black, Mounting set jet black, 24° medium, 2700 K, 14.7 W, 89 lm/W
    DALI-2
    black, Mounting set jet black, 17° spot, 2700 K, 14.7 W, 90 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 2700 K, 14.7 W, 84 lm/W
    DALI-2
    black, Mounting set jet black, 38° flood, 3000 K, 14.7 W, 94 lm/W
    non DIM
    black, Mounting set jet black, 24° medium, 3000 K, 14.7 W, 93 lm/W
    non DIM
    black, Mounting set jet black, 17° spot, 3000 K, 14.7 W, 95 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 3000 K, 14.7 W, 88 lm/W
    non DIM
    black, Mounting set jet black, 38° flood, 3000 K, 14.7 W, 94 lm/W
    DALI-2
    black, Mounting set jet black, 24° medium, 3000 K, 14.7 W, 93 lm/W
    DALI-2
    black, Mounting set jet black, 17° spot, 3000 K, 14.7 W, 95 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 3000 K, 14.7 W, 88 lm/W
    DALI-2
    black, Mounting set jet black, 38° flood, 4000 K, 14.7 W, 99 lm/W
    non DIM
    black, Mounting set jet black, 24° medium, 4000 K, 14.7 W, 99 lm/W
    non DIM
    black, Mounting set jet black, 17° spot, 4000 K, 14.7 W, 100 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 4000 K, 14.7 W, 94 lm/W
    non DIM
    black, Mounting set jet black, 38° flood, 4000 K, 14.7 W, 99 lm/W
    DALI-2
    black, Mounting set jet black, 24° medium, 4000 K, 14.7 W, 99 lm/W
    DALI-2
    black, Mounting set jet black, 17° spot, 4000 K, 14.7 W, 100 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 4000 K, 14.7 W, 94 lm/W
    DALI-2
    black, Mounting set jet black, 36° flood, colour warm dimming, 2000 K - 3000 K, 14.9 W, 57 lm/W
    DALI-2
    black, Mounting set jet black, 38° flood, 2700 K, 27 W, 79 lm/W
    non DIM
    black, Mounting set jet black, 24° medium, 2700 K, 27 W, 78 lm/W
    non DIM
    black, Mounting set jet black, 17° spot, 2700 K, 27 W, 79 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 2700 K, 27 W, 74 lm/W
    non DIM
    black, Mounting set jet black, 38° flood, 2700 K, 27 W, 79 lm/W
    DALI-2
    black, Mounting set jet black, 24° medium, 2700 K, 27 W, 78 lm/W
    DALI-2
    black, Mounting set jet black, 17° spot, 2700 K, 27 W, 79 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 2700 K, 27 W, 74 lm/W
    DALI-2
    black, Mounting set jet black, 38° flood, 3000 K, 27 W, 82 lm/W
    non DIM
    black, Mounting set jet black, 24° medium, 3000 K, 27 W, 82 lm/W
    non DIM
    black, Mounting set jet black, 17° spot, 3000 K, 27 W, 83 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 3000 K, 27 W, 77 lm/W
    non DIM
    black, Mounting set jet black, 38° flood, 3000 K, 27 W, 82 lm/W
    DALI-2
    black, Mounting set jet black, 24° medium, 3000 K, 27 W, 82 lm/W
    DALI-2
    black, Mounting set jet black, 17° spot, 3000 K, 27 W, 83 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 3000 K, 27 W, 77 lm/W
    DALI-2
    black, Mounting set jet black, 38° flood, 4000 K, 27 W, 87 lm/W
    non DIM
    black, Mounting set jet black, 24° medium, 4000 K, 27 W, 86 lm/W
    non DIM
    black, Mounting set jet black, 17° spot, 4000 K, 27 W, 87 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 4000 K, 27 W, 82 lm/W
    non DIM
    black, Mounting set jet black, 38° flood, 4000 K, 27 W, 87 lm/W
    DALI-2
    black, Mounting set jet black, 24° medium, 4000 K, 27 W, 86 lm/W
    DALI-2
    black, Mounting set jet black, 17° spot, 4000 K, 27 W, 87 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 4000 K, 27 W, 82 lm/W
    DALI-2
    black, Mounting set jet black, 38° flood, tunable white, 2700 K - 6500 K, 27.7 W, 78 lm/W
    DALI-2 DT8
    black, Mounting set jet black, 38° flood, tunable white, 1800 K - 3000 K, 28 W, 61 lm/W
    DALI-2 DT8
    black, Mounting set jet black, 39° flood, 2700 K, 27 W, 93 lm/W
    non DIM
    black, Mounting set jet black, 26° medium, 2700 K, 27 W, 92 lm/W
    non DIM
    black, Mounting set jet black, 39° flood, 2700 K, 27 W, 93 lm/W
    DALI-2
    black, Mounting set jet black, 26° medium, 2700 K, 27 W, 92 lm/W
    DALI-2
    black, Mounting set jet black, 39° flood, 3000 K, 27 W, 101 lm/W
    non DIM
    black, Mounting set jet black, 26° medium, 3000 K, 27 W, 100 lm/W
    non DIM
    black, Mounting set jet black, 39° flood, 3000 K, 27 W, 101 lm/W
    DALI-2
    black, Mounting set jet black, 26° medium, 3000 K, 27 W, 100 lm/W
    DALI-2
    black, Mounting set jet black, 39° flood, 4000 K, 27 W, 102 lm/W
    non DIM
    black, Mounting set jet black, 26° medium, 4000 K, 27 W, 101 lm/W
    non DIM
    black, Mounting set jet black, 39° flood, 4000 K, 27 W, 102 lm/W
    DALI-2
    black, Mounting set jet black, 26° medium, 4000 K, 27 W, 101 lm/W
    DALI-2
    SASSO PRO 100 adjustable offset trim round;SASSO PRO 100 adjustable offset trim round concrete

    SASSO PRO 100 adjustable offset trim round

    SASSO PRO 100 adjustable offset trim round

    Status
    Article number(s)
    Type
    Dimming
    white, Mounting set jet black, 38° flood, 2700 K, 14.7 W, 93 lm/W
    non DIM
    white, Mounting set jet black, 24° medium, 2700 K, 14.7 W, 92 lm/W
    non DIM
    white, Mounting set jet black, 17° spot, 2700 K, 14.7 W, 92 lm/W
    non DIM
    white, Mounting set jet black, 57° wide flood, 2700 K, 14.7 W, 87 lm/W
    non DIM
    white, Mounting set jet black, 38° flood, 2700 K, 14.7 W, 93 lm/W
    DALI-2
    white, Mounting set jet black, 24° medium, 2700 K, 14.7 W, 92 lm/W
    DALI-2
    white, Mounting set jet black, 17° spot, 2700 K, 14.7 W, 92 lm/W
    DALI-2
    white, Mounting set jet black, 57° wide flood, 2700 K, 14.7 W, 87 lm/W
    DALI-2
    white, Mounting set jet black, 38° flood, 3000 K, 14.7 W, 97 lm/W
    non DIM
    white, Mounting set jet black, 24° medium, 3000 K, 14.7 W, 96 lm/W
    non DIM
    white, Mounting set jet black, 17° spot, 3000 K, 14.7 W, 96 lm/W
    non DIM
    white, Mounting set jet black, 57° wide flood, 3000 K, 14.7 W, 91 lm/W
    non DIM
