FRAME 60 high lumen
trim
052-4735D37G
Quickinfo
tunable white 2700 - 6500 KCRI ≥ 80 / 3 SDCM (initial MacAd
2,220 lm/m
105 lm/W
L90 / 50000 h
DALI-2
Microprismatic
IP20
Colour
General
- Ceiling
- Recessed
- traffic white
- RAL 9016
- IP20
- 3270 lm
- 2220 lm/m
LED
- tunable white
- 2700 - 6500 K
- CRI ≥ 80
- L90 / 50000 h
- ≤ 3 SDCM (initial MacAdam)
- MR 0.48
- MDER 0.44
Optical
- Microprismatic
- microprismatic
- ≤ 1.0 1
- SVM ≤ 0.4 1
Electrical
- DALI-2
- DT8
- 220-240 V
- system 31 W
- system 105 lm/W 2
- PC1
- 1 DALI Addr.
- 21 W/m
Physical
- length 1493 mm
- width 77 mm
- height 78 mm
- 3.9 kg
Cutout
- length 1483 mm
- width 66 mm
- min. ceiling thickness 8 mm
- max. ceiling thickness 25 mm
- recessed depth 104 mm
Circuit Breaker Types
Automatic Circuit Breaker Type
Number of Fixtures
Luminaire housing made of extruded aluminium profile; recessed light with wrap around edge; suitable for ceiling thickness of 8-25 mm; surface traffic white powder coated; lighting profile (end cover and mounting bracket pre-assembled) available in advance for installation; remaining lamp components mounted without tools; LED light inset consisting of highly reflective lacquered aluminium for improved thermal management; light colour 2700 - 6500 K tunable white; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; micro prismatic PMMA diffuser incl. diffuser film for homogeneous illumination and reduced luminance; degree of protection IP20; PC1; 220-240 V; internal wiring in light halogen free; incl. DALI-2 converter; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
