MOVE IT 45

suspended indirect system

Quickinfo

3000 K
CRI ≥ 90 / 3 SDCM
up to 118 lm/W
L80 / 50000 h
DALI-2 single control, non DIM
IP20 / PC3 48V

Colour

  • Inner colour

  • Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    • 3DS
    • DWG - 3D
    • Revit BIM data

    Description

    Extruded aluminium profile with 45 mm width groove; for suspended mounting (cable suspension); height adjustment without tools; incl. black feed; designed for continuous lighting systems, 90° angle connectors and node connectors with up to 4 profile connection options for flexible system design; with indirect light component for additional accentuation of the ceiling; indirect light component covered with opal lens cover; with integrated power track profile for take off of supply voltage and DALI signal; surface anodised or powder coated; insets can be installed flexibly and without tools by means of magnetic holders+locking; sound absorbing accessories for installation in the MOVE IT suspended system composed of node connectors and 1220 mm profiles available

    custom cut on building site or by XAL

    acoustic elements

    Dieser Bereich wird neu geladen sobald ein Eingabefeld geändert wird.

    Products and codes

    Filter
    105
    lm/W
    118
    lm/W
    648
    lm
    6000
    lm
    6.2
    W
    51
    W

    Colour

  • Inner colour

  • MOVE IT 45 suspended indirect system;MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    Status
    Article number(s)
    Type
    Dimming
    gold, 13.1 W, 118 lm/W, length 653 mm
    non DIM
    gold, 13.1 W, 118 lm/W, length 653 mm
    DALI-2 single control
    MOVE IT 45 suspended indirect system;MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    Status
    Article number(s)
    Type
    Dimming
    special colours, 13.1 W, 118 lm/W, length 653 mm
    non DIM
    special colours, 13.1 W, 118 lm/W, length 653 mm
    DALI-2 single control
    MOVE IT 45 suspended indirect system;MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    Status
    Article number(s)
    Type
    Dimming
    white, 13.1 W, 118 lm/W, length 653 mm
    non DIM
    white, 13.1 W, 118 lm/W, length 653 mm
    DALI-2 single control
    MOVE IT 45 suspended indirect system;MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    MOVE IT 45 track corner indirect

    Status
    Article number(s)
    Type
    Dimming
    black, 13.1 W, 118 lm/W, length 653 mm
    non DIM
    black, 13.1 W, 118 lm/W, length 653 mm
    DALI-2 single control
    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    Status
    Article number(s)
    Type
    Dimming
    gold, 6.2 W, 105 lm/W, length 620 mm
    non DIM
    gold, 6.2 W, 105 lm/W, length 620 mm
    DALI-2 single control
    gold, 15.3 W, 118 lm/W, length 1,220 mm
    non DIM
    gold, 15.3 W, 118 lm/W, length 1,220 mm
    DALI-2 single control
    gold, 33 W, 118 lm/W, length 2,420 mm
    non DIM
    gold, 33 W, 118 lm/W, length 2,420 mm
    DALI-2 single control
    gold, 51 W, 118 lm/W, length 3,625 mm
    non DIM
    gold, 51 W, 118 lm/W, length 3,625 mm
    DALI-2 single control
    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    Status
    Article number(s)
    Type
    Dimming
    special colours, 6.2 W, 105 lm/W, length 620 mm
    non DIM
    special colours, 6.2 W, 105 lm/W, length 620 mm
    DALI-2 single control
    special colours, 15.3 W, 118 lm/W, length 1,220 mm
    non DIM
    special colours, 15.3 W, 118 lm/W, length 1,220 mm
    DALI-2 single control
    special colours, 33 W, 118 lm/W, length 2,420 mm
    non DIM
    special colours, 33 W, 118 lm/W, length 2,420 mm
    DALI-2 single control
    special colours, 51 W, 118 lm/W, length 3,625 mm
    non DIM
    special colours, 51 W, 118 lm/W, length 3,625 mm
    DALI-2 single control
    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    Status
    Article number(s)
    Type
    Dimming
    white, 6.2 W, 105 lm/W, length 620 mm
    non DIM
    white, 6.2 W, 105 lm/W, length 620 mm
    DALI-2 single control
    white, 15.3 W, 118 lm/W, length 1,220 mm
    non DIM
    white, 15.3 W, 118 lm/W, length 1,220 mm
    DALI-2 single control
    white, 33 W, 118 lm/W, length 2,420 mm
    non DIM
    white, 33 W, 118 lm/W, length 2,420 mm
    DALI-2 single control
    white, 51 W, 118 lm/W, length 3,625 mm
    non DIM
    white, 51 W, 118 lm/W, length 3,625 mm
    DALI-2 single control
    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    MOVE IT 45 track indirect

    Status
    Article number(s)
    Type
    Dimming
    black, 6.2 W, 105 lm/W, length 620 mm
    non DIM
    black, 6.2 W, 105 lm/W, length 620 mm
    DALI-2 single control
    black, 15.3 W, 118 lm/W, length 1,220 mm
    non DIM
    black, 15.3 W, 118 lm/W, length 1,220 mm
    DALI-2 single control
    black, 33 W, 118 lm/W, length 2,420 mm
    non DIM
    black, 33 W, 118 lm/W, length 2,420 mm
    DALI-2 single control
    black, 51 W, 118 lm/W, length 3,625 mm
    non DIM
    black, 51 W, 118 lm/W, length 3,625 mm
    DALI-2 single control
