SASSO recessed colours
Ball catch system

SASSO 100 round adjustable

recessed 1 lamp

Quickinfo

2700 K, 3000 K, 3500 K, 4000 K, colour warm dimming 1800 - 3000 K, tunable white 1800 - 4000 K, tunable white 2700 - 6500 K
CRI ≥ 90, CRI ≥ 92 / 2 SDCM (initial MacAdam), 3 SDCM (initial MacAdam)
UGR ≤ 10, UGR ≤ 13, UGR ≤ 16, UGR ≤ 19
up to 127 lm/W
L85 / 50000 h, L90 / 100000 h
DALI-2, non DIM
front IP40, back IP20

Colour

Mounting set

Products and codes
Discover family

Simple drawing

Light distribution

Product data & specification documents

Download all
Download all
  • 3DS
  • DWG - 3D
  • Revit BIM data
  • EPD

Description

Round recessed spotlight; installation without tools in mounting set (trimless or with trim) with ball catch system; surface lacquered; installation possible in different housings; light inset rotatable and tiltable; precise radiation characteristic due to high quality lens system; COB (Chip on Board) technology for maximum efficiency; no multiple shadows; efficient LEDs with very good colour rendering

360° rotatable, 30° tiltable

glare control (UGR ≤ 16)

quick mounting in soft acoustic ceilings

Colour Warm Dimming 1800 – 3000 K

CRI ≥ 95 2 SDCM (optional)

Products and codes

Filter
67
lm/W
127
lm/W
1510
lm
2620
lm
17.9
W
28
W
15.2
W
23.8
W
0.52
1.15
0.47
1.04

Colour

Mounting set

SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

Status
Article number(s)
Type
Dimming
traffic white, Mounting set jet black, flood, 3000 K, fixture 15.2 W, 113 lm/W
non DIM
traffic white, Mounting set jet black, flood, 3000 K, fixture 15.2 W, 113 lm/W
DALI-2
traffic white, Mounting set jet black, flood, 3000 K, fixture 22.7 W, 102 lm/W
non DIM
traffic white, Mounting set jet black, flood, 3000 K, fixture 22.7 W, 102 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 3000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set jet black, medium, 3000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 3000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set jet black, medium, 3000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 3000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set jet black, spot, 3000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 3000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set jet black, spot, 3000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 3000 K, fixture 15.2 W, 120 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 3000 K, fixture 15.2 W, 120 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 3000 K, fixture 22.7 W, 109 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 3000 K, fixture 22.7 W, 109 lm/W
DALI-2
traffic white, Mounting set jet black, flood, 4000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set jet black, flood, 4000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set jet black, flood, 4000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set jet black, flood, 4000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 4000 K, fixture 15.2 W, 124 lm/W
non DIM
traffic white, Mounting set jet black, medium, 4000 K, fixture 15.2 W, 124 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 4000 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set jet black, medium, 4000 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 4000 K, fixture 15.2 W, 123 lm/W
non DIM
traffic white, Mounting set jet black, spot, 4000 K, fixture 15.2 W, 123 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 4000 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set jet black, spot, 4000 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 4000 K, fixture 15.2 W, 126 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 4000 K, fixture 15.2 W, 126 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 4000 K, fixture 22.7 W, 114 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 4000 K, fixture 22.7 W, 114 lm/W
DALI-2
traffic white, Mounting set jet black, flood, 3500 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set jet black, flood, 3500 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set jet black, flood, 3500 K, fixture 22.7 W, 105 lm/W
non DIM
traffic white, Mounting set jet black, flood, 3500 K, fixture 22.7 W, 105 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 3500 K, fixture 15.2 W, 121 lm/W
non DIM
traffic white, Mounting set jet black, medium, 3500 K, fixture 15.2 W, 121 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 3500 K, fixture 22.7 W, 110 lm/W
non DIM
traffic white, Mounting set jet black, medium, 3500 K, fixture 22.7 W, 110 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 3500 K, fixture 15.2 W, 121 lm/W
non DIM
traffic white, Mounting set jet black, spot, 3500 K, fixture 15.2 W, 121 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 3500 K, fixture 22.7 W, 110 lm/W
non DIM
traffic white, Mounting set jet black, spot, 3500 K, fixture 22.7 W, 110 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 3500 K, fixture 15.2 W, 123 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 3500 K, fixture 15.2 W, 123 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 3500 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 3500 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set jet black, flood, 2700 K, fixture 15.2 W, 109 lm/W
non DIM
traffic white, Mounting set jet black, flood, 2700 K, fixture 15.2 W, 109 lm/W
DALI-2
traffic white, Mounting set jet black, flood, 2700 K, fixture 22.7 W, 101 lm/W
non DIM
traffic white, Mounting set jet black, flood, 2700 K, fixture 22.7 W, 101 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 2700 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set jet black, medium, 2700 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set jet black, medium, 2700 K, fixture 22.7 W, 106 lm/W
non DIM
traffic white, Mounting set jet black, medium, 2700 K, fixture 22.7 W, 106 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 2700 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set jet black, spot, 2700 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set jet black, spot, 2700 K, fixture 22.7 W, 106 lm/W
non DIM
traffic white, Mounting set jet black, spot, 2700 K, fixture 22.7 W, 106 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 2700 K, fixture 15.2 W, 117 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 2700 K, fixture 15.2 W, 117 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, 2700 K, fixture 22.7 W, 108 lm/W
non DIM
traffic white, Mounting set jet black, wide flood, 2700 K, fixture 22.7 W, 108 lm/W
DALI-2
traffic white, Mounting set jet black, medium, tunable white, 2700 - 6500 K, 75 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, tunable white, 2700 - 6500 K, 77 lm/W
DALI-2
traffic white, Mounting set jet black, medium, colour warm dimming, 1800 - 3000 K, fixture 23.8 W, 87 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, colour warm dimming, 1800 - 3000 K, fixture 23.8 W, 96 lm/W
DALI-2
traffic white, Mounting set jet black, medium, tunable white, 1800 - 4000 K, 72 lm/W
DALI-2
traffic white, Mounting set jet black, wide flood, tunable white, 1800 - 4000 K, 74 lm/W
DALI-2
SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

Status
Article number(s)
Type
Dimming
traffic white, Mounting set traffic white, flood, 3000 K, fixture 15.2 W, 113 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 3000 K, fixture 15.2 W, 113 lm/W
DALI-2
traffic white, Mounting set traffic white, flood, 3000 K, fixture 22.7 W, 102 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 3000 K, fixture 22.7 W, 102 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 3000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 3000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 3000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 3000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 3000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 3000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 3000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 3000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 3000 K, fixture 15.2 W, 120 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 3000 K, fixture 15.2 W, 120 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 3000 K, fixture 22.7 W, 109 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 3000 K, fixture 22.7 W, 109 lm/W
DALI-2
traffic white, Mounting set traffic white, flood, 4000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 4000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set traffic white, flood, 4000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 4000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 4000 K, fixture 15.2 W, 124 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 4000 K, fixture 15.2 W, 124 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 4000 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 4000 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 4000 K, fixture 15.2 W, 123 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 4000 K, fixture 15.2 W, 123 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 4000 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 4000 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 4000 K, fixture 15.2 W, 126 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 4000 K, fixture 15.2 W, 126 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 4000 K, fixture 22.7 W, 114 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 4000 K, fixture 22.7 W, 114 lm/W
DALI-2
traffic white, Mounting set traffic white, flood, 3500 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 3500 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set traffic white, flood, 3500 K, fixture 22.7 W, 105 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 3500 K, fixture 22.7 W, 105 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 3500 K, fixture 15.2 W, 121 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 3500 K, fixture 15.2 W, 121 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 3500 K, fixture 22.7 W, 110 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 3500 K, fixture 22.7 W, 110 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 3500 K, fixture 15.2 W, 121 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 3500 K, fixture 15.2 W, 121 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 3500 K, fixture 22.7 W, 110 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 3500 K, fixture 22.7 W, 110 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 3500 K, fixture 15.2 W, 123 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 3500 K, fixture 15.2 W, 123 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 3500 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 3500 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set traffic white, flood, 2700 K, fixture 15.2 W, 109 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 2700 K, fixture 15.2 W, 109 lm/W
DALI-2
traffic white, Mounting set traffic white, flood, 2700 K, fixture 22.7 W, 101 lm/W
non DIM
traffic white, Mounting set traffic white, flood, 2700 K, fixture 22.7 W, 101 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 2700 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 2700 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, 2700 K, fixture 22.7 W, 106 lm/W
non DIM
traffic white, Mounting set traffic white, medium, 2700 K, fixture 22.7 W, 106 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 2700 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 2700 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set traffic white, spot, 2700 K, fixture 22.7 W, 106 lm/W
non DIM
traffic white, Mounting set traffic white, spot, 2700 K, fixture 22.7 W, 106 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 2700 K, fixture 15.2 W, 117 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 2700 K, fixture 15.2 W, 117 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, 2700 K, fixture 22.7 W, 108 lm/W
non DIM
traffic white, Mounting set traffic white, wide flood, 2700 K, fixture 22.7 W, 108 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, tunable white, 2700 - 6500 K, 75 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, tunable white, 2700 - 6500 K, 77 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, colour warm dimming, 1800 - 3000 K, fixture 23.8 W, 87 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, colour warm dimming, 1800 - 3000 K, fixture 23.8 W, 96 lm/W
DALI-2
traffic white, Mounting set traffic white, medium, tunable white, 1800 - 4000 K, 72 lm/W
DALI-2
traffic white, Mounting set traffic white, wide flood, tunable white, 1800 - 4000 K, 74 lm/W
DALI-2
SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

Status
Article number(s)
Type
Dimming
traffic white, Mounting set white aluminium, flood, 3000 K, fixture 15.2 W, 113 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 3000 K, fixture 15.2 W, 113 lm/W
DALI-2
traffic white, Mounting set white aluminium, flood, 3000 K, fixture 22.7 W, 102 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 3000 K, fixture 22.7 W, 102 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 3000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 3000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 3000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 3000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 3000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 3000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 3000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 3000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 3000 K, fixture 15.2 W, 120 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 3000 K, fixture 15.2 W, 120 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 3000 K, fixture 22.7 W, 109 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 3000 K, fixture 22.7 W, 109 lm/W
DALI-2
traffic white, Mounting set white aluminium, flood, 4000 K, fixture 15.2 W, 118 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 4000 K, fixture 15.2 W, 118 lm/W
DALI-2
traffic white, Mounting set white aluminium, flood, 4000 K, fixture 22.7 W, 107 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 4000 K, fixture 22.7 W, 107 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 4000 K, fixture 15.2 W, 124 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 4000 K, fixture 15.2 W, 124 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 4000 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 4000 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 4000 K, fixture 15.2 W, 123 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 4000 K, fixture 15.2 W, 123 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 4000 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 4000 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 4000 K, fixture 15.2 W, 126 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 4000 K, fixture 15.2 W, 126 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 4000 K, fixture 22.7 W, 114 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 4000 K, fixture 22.7 W, 114 lm/W
DALI-2
traffic white, Mounting set white aluminium, flood, 3500 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 3500 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set white aluminium, flood, 3500 K, fixture 22.7 W, 105 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 3500 K, fixture 22.7 W, 105 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 3500 K, fixture 15.2 W, 121 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 3500 K, fixture 15.2 W, 121 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 3500 K, fixture 22.7 W, 110 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 3500 K, fixture 22.7 W, 110 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 3500 K, fixture 15.2 W, 121 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 3500 K, fixture 15.2 W, 121 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 3500 K, fixture 22.7 W, 110 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 3500 K, fixture 22.7 W, 110 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 3500 K, fixture 15.2 W, 123 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 3500 K, fixture 15.2 W, 123 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 3500 K, fixture 22.7 W, 112 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 3500 K, fixture 22.7 W, 112 lm/W
DALI-2
traffic white, Mounting set white aluminium, flood, 2700 K, fixture 15.2 W, 109 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 2700 K, fixture 15.2 W, 109 lm/W
DALI-2
traffic white, Mounting set white aluminium, flood, 2700 K, fixture 22.7 W, 101 lm/W
non DIM
traffic white, Mounting set white aluminium, flood, 2700 K, fixture 22.7 W, 101 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 2700 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 2700 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, 2700 K, fixture 22.7 W, 106 lm/W
non DIM
traffic white, Mounting set white aluminium, medium, 2700 K, fixture 22.7 W, 106 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 2700 K, fixture 15.2 W, 115 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 2700 K, fixture 15.2 W, 115 lm/W
DALI-2
traffic white, Mounting set white aluminium, spot, 2700 K, fixture 22.7 W, 106 lm/W
non DIM
traffic white, Mounting set white aluminium, spot, 2700 K, fixture 22.7 W, 106 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 2700 K, fixture 15.2 W, 117 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 2700 K, fixture 15.2 W, 117 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, 2700 K, fixture 22.7 W, 108 lm/W
non DIM
traffic white, Mounting set white aluminium, wide flood, 2700 K, fixture 22.7 W, 108 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, tunable white, 2700 - 6500 K, 75 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, tunable white, 2700 - 6500 K, 77 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, colour warm dimming, 1800 - 3000 K, fixture 23.8 W, 87 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, colour warm dimming, 1800 - 3000 K, fixture 23.8 W, 96 lm/W
DALI-2
traffic white, Mounting set white aluminium, medium, tunable white, 1800 - 4000 K, 72 lm/W
DALI-2
traffic white, Mounting set white aluminium, wide flood, tunable white, 1800 - 4000 K, 74 lm/W
DALI-2
SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

SASSO 100 round adjustable trim

Status
Article number(s)
Type
Dimming
jet black, Mounting set jet black, flood, 3000 K, fixture 15.2 W, 102 lm/W
non DIM
jet black, Mounting set jet black, flood, 3000 K, fixture 15.2 W, 102 lm/W
DALI-2
jet black, Mounting set jet black, flood, 3000 K, fixture 22.7 W, 93 lm/W
non DIM
jet black, Mounting set jet black, flood, 3000 K, fixture 22.7 W, 93 lm/W
DALI-2
jet black, Mounting set jet black, medium, 3000 K, fixture 15.2 W, 111 lm/W
non DIM
jet black, Mounting set jet black, medium, 3000 K, fixture 22.7 W, 101 lm/W
non DIM
jet black, Mounting set jet black, medium, 3000 K, fixture 22.7 W, 101 lm/W
DALI-2
jet black, Mounting set jet black, spot, 3000 K, fixture 15.2 W, 109 lm/W
non DIM
jet black, Mounting set jet black, spot, 3000 K, fixture 15.2 W, 109 lm/W
DALI-2
jet black, Mounting set jet black, spot, 3000 K, fixture 22.7 W, 99 lm/W
non DIM
jet black, Mounting set jet black, spot, 3000 K, fixture 22.7 W, 99 lm/W
DALI-2
jet black, Mounting set jet black, wide flood, 3000 K, fixture 15.2 W, 115 lm/W
non DIM
jet black, Mounting set jet black, wide flood, 3000 K, fixture 15.2 W, 115 lm/W
DALI-2
jet black, Mounting set jet black, wide flood, 3000 K, fixture 22.7 W, 105 lm/W
non DIM
jet black, Mounting set jet black, wide flood, 3000 K, fixture 22.7 W, 105 lm/W
DALI-2
jet black, Mounting set jet black, spot, 4000 K, fixture 15.2 W, 114 lm/W
non DIM
jet black, Mounting set jet black, spot, 4000 K, fixture 15.2 W, 114 lm/W
DALI-2
jet black, Mounting set jet black, spot, 4000 K, fixture 22.7 W, 103 lm/W
non DIM
jet black, Mounting set jet black, spot, 4000 K, fixture 22.7 W, 103 lm/W
DALI-2
jet black, Mounting set jet black, flood, 3500 K, fixture 15.2 W, 104 lm/W
non DIM
jet black, Mounting set jet black, flood, 3500 K, fixture 15.2 W, 104 lm/W
DALI-2
jet black, Mounting set jet black, flood, 3500 K, fixture 22.7 W, 95 lm/W
non DIM
jet black, Mounting set jet black, flood, 3500 K, fixture 22.7 W, 95 lm/W
DALI-2
jet black, Mounting set jet black, medium, 3500 K, fixture 15.2 W, 114 lm/W
non DIM
jet black, Mounting set jet black, medium, 3500 K, fixture 15.2 W, 114 lm/W
DALI-2
jet black, Mounting set jet black, medium, 3500 K, fixture 22.7 W, 103 lm/W
non DIM
jet black, Mounting set jet black, medium, 3500 K, fixture 22.7 W, 103 lm/W
DALI-2
jet black, Mounting set jet black, wide flood, 3500 K, fixture 15.2 W, 118 lm/W
non DIM
jet black, Mounting set jet black, wide flood, 3500 K, fixture 15.2 W, 118 lm/W
DALI-2
jet black, Mounting set jet black, wide flood, 3500 K, fixture 22.7 W, 107 lm/W
non DIM
jet black, Mounting set jet black, wide flood, 3500 K, fixture 22.7 W, 107 lm/W
DALI-2
jet black, Mounting set jet black, flood, 2700 K, fixture 15.2 W, 99 lm/W
non DIM
jet black, Mounting set jet black, flood, 2700 K, fixture 22.7 W, 91 lm/W
non DIM
jet black, Mounting set jet black, medium, 2700 K, fixture 15.2 W, 108 lm/W
non DIM
jet black, Mounting set jet black, spot, 2700 K, fixture 15.2 W, 106 lm/W
non DIM
jet black, Mounting set jet black, spot, 2700 K, fixture 15.2 W, 106 lm/W
DALI-2
jet black, Mounting set jet black, spot, 2700 K, fixture 22.7 W, 97 lm/W
non DIM
jet black, Mounting set jet black, spot, 2700 K, fixture 22.7 W, 97 lm/W
DALI-2
jet black, Mounting set jet black, wide flood, 2700 K, fixture 15.2 W, 112 lm/W
non DIM
jet black, Mounting set jet black, wide flood, 2700 K, fixture 22.7 W, 103 lm/W
non DIM

Accessories

Converter

article number
power
voltage / frequency
protection class
constant current
control
POWER SUPPLY
002-90766
21 W
min 50 Hz
max 60 Hz
PC2
450 mA
non DIM
POWER SUPPLY
002-90767
28 W
min 50 Hz
max 60 Hz
PC2
450 mA
DALI-2
POWER SUPPLY
002-90776
28 W
min 50 Hz
max 60 Hz
PC2
700 mA
DALI-2
POWER SUPPLY
002-90780
100 W
min 50 Hz
max 60 Hz
PC2
650 mA
non DIM
POWER SUPPLY
002-90789
28 W
min 50 Hz
max 60 Hz
PC2
650 mA
DALI-2

Mounting

article number
type
colour
dimensions
mounting type
cut out dimensions
ceiling thickness
plaster board thickness
EXPOSED CONCRETE MOUNTING HOUSING
048-2795210
white aluminium
RAL 9006
length 230 mm
width 230 mm
height 162 mm
2.2 kg
MOUNTING SET trimless
048-2796117
for plasterboard ceilings
traffic white
RAL 9016
diameter 105 mm
height 29 mm
0.1 kg
diameter
12.5/15/20/25 mm
MOUNTING SET trimless
048-2796197
for soft acoustic ceilings
traffic white
RAL 9016
diameter 114 mm
height 27 mm
0.1 kg
For Rockfon Mono® Acoustic
diameter
min. ceiling thickness 25 mm
max. ceiling thickness 40 mm
MOUNTING SET with trim 1 lamp
048-2796317
for intermediate ceilings
traffic white
RAL 9016
diameter 118 mm
height 40 mm
0.1 kg
diameter
min. ceiling thickness 2 mm
max. ceiling thickness 25 mm
MOUNTING SET with trim 1 lamp
048-2796318
for intermediate ceilings
jet black
RAL 9005
diameter 118 mm
height 40 mm
0.06 kg
diameter
min. ceiling thickness 2 mm
max. ceiling thickness 25 mm
MOUNTING SET with trim 1 lamp
048-279631G
for intermediate ceilings
white aluminium
RAL 9006
diameter 118 mm
height 40 mm
0.06 kg
diameter
min. ceiling thickness 2 mm
max. ceiling thickness 25 mm
MOUNTING SET with trim
048-2796397
for soft acoustic ceilings
traffic white
RAL 9016
diameter 114 mm
height 25 mm
0.15 kg
For Rockfon Mono® Acoustic
diameter
min. ceiling thickness 25 mm
max. ceiling thickness 40 mm
MOUNTING SET with trim
048-2796398
for soft acoustic ceilings
jet black
RAL 9005
diameter 114 mm
height 25 mm
0.1 kg
For Rockfon Mono® Acoustic
diameter
min. ceiling thickness 25 mm
max. ceiling thickness 40 mm

Converter

article number
power
voltage / frequency
protection class
constant voltage
constant current
control
POWER SUPPLY PRE-WIRED with junction box
002-90766A
28 W
max 60 Hz
PC2
450 mA
non DIM
POWER SUPPLY PRE-WIRED with junction box
002-90767A
28 W
min 50 Hz
max 60 Hz
PC2
450 mA
DALI-2
POWER SUPPLY PRE-WIRED with junction box
002-90774A
28 W
max 60 Hz
PC2
700 mA
non DIM
POWER SUPPLY PRE-WIRED with junction box
002-90776A
28 W
min 50 Hz
max 60 Hz
PC2
700 mA
DALI-2
POWER SUPPLY PRE-WIRED with junction box
002-90780A
28 W
max 60 Hz
PC2
650 mA
non DIM
POWER SUPPLY PRE-WIRED with junction box
002-90789A
28 W
min 50 Hz
max 60 Hz
PC2
650 mA
DALI-2
DIN RAIL LED DRIVER
005-6121030
DALI-2 DT6 1 - 2 addresses / DT8 1 adress
DIN RAIL POWER SUPPLY BASIC
005-6520210
160 W
min 50 Hz
max 60 Hz
PC2
48 V

Electrical mounting

article number
type
dimensions
THROUGH WIRING CONNECTION BOX
005-2531110
non DIM cable ø 4 – 12 mm
length 105 mm
width 58 mm
height 30 mm
0.06 kg
THROUGH WIRING CONNECTION BOX
005-2551110
DALI cable ø 4 – 12 mm
length 105 mm
width 58 mm
height 30 mm
0.07 kg

Optical

article number
colour
type
dimensions
HONEYCOMB LOUVER
007-1965598
jet black
RAL 9005
for BO 55 | JUST 55 | SASSO 100
diameter 50 mm
height 3 mm

Mounting

article number
dimensions
PRIMED CONCRETE MOUNTING HOUSING
048-2695110
length 614 mm
width 307 mm
height 120 mm
0.17 kg

Mounting tools

article number
type
colour
dimensions
MOUNTING TOOL
048-2795918
for soft acoustic ceilings
traffic black
RAL 9017
length 104 mm
width 104 mm
height 35 mm
0.2 kg

Related products

SASSO 40

round adjustable recessed 1 lamp

SASSO 40

round downlight recessed 1 lamp

SASSO 40

round wallwasher recessed 1 lamp

SASSO 40

round wallwasher/floor recessed 1 lamp

SASSO 40

round adjustable recessed 2 lamps

SASSO 40

round downlight recessed 2 lamps

SASSO 40

round wallwasher recessed 2 lamps

SASSO 40

round wallwasher/floor recessed 2 lamps

SASSO 60

round adjustable recessed 1 lamp

SASSO 60

round downlight recessed 1 lamp
