BETO linear blackboard direct / indirect suspended system

BETO linear blackboard direct / indirect

suspended system

074-7736638R

Quickinfo

4000 K
CRI ≥ 80 / 3 SDCM (initial MacAdam)
5,120 lm/↑ 4,220 lm
132 lm/W
L90 / 50000 h
DALI-2
Reflector
IP20 / PC1 / 220-240 V
1,700 mm,

Colour

Colour

Reflector

Reflector

General

  • Ceiling
  • Suspended
  • jet black
  • Reflector chrome
  • RAL 9005
  • IP20
  • indirect 4220 lm
  • direct 5120 lm
  • total 9340 lm

LED

  • 4000 K
  • CRI ≥ 80
  • L90 / 50000 h
  • ≤ 3 SDCM (initial MacAdam)
  • MR 0.74
  • MDER 0.67

Optical

  • Reflector
  • wallwasher floor
  • PstLM ≤ 1.01 2 3 4
  • SVM ≤ 0.41 2 3 4

Electrical

  • DALI-2
  • 220-240 V
  • system 71 W
  • system 132 lm/W 5
  • PC1
  • 2 DALI Addr.

Physical

  • length 1700 mm
  • width 42 mm
  • height 42 mm

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B13
B16
B20
C10
C13
C16
C20

Number of Fixtures

6
9
11
14
11
15
19
23
1 combined 2 indirect 3 direct 4 Value of containing product at full load (undimmed) 5 incl. consideration of optical losses, internal control unit losses & operating device efficiency

Luminaire housing made of extruded aluminium profile; extremely slim design (only 42 x 42 mm) linear; converter integrated into luminaire housing; no visible screws; angular design; for lighting systems; surface jet black powder coated; for suspended mounting (1500 mm cable suspension as an accessory); with integrated toolless suspension height adjustment on the luminaire; spring clip attachment to the luminaire; extruded profile for improved thermal management; light colour 4000 K; ≤ 3 SDCM (initial MacAdam); CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; high quality reflector with micro-faceted, aluminum-vaporised surface; asymmetrical light distribution with precise radiation characteristic; direct/indirect illumination characteristic; indirect light component with integrated PC boards and high quality lens system for maximum, homogeneous ceiling illumination, separately controllable; degree of protection IP20; PC1; 220-240 V; internal wiring in light halogen free; incl. DALI-2 converter; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;

Product data & specification documents

Datasheets

Planning files & lighting data

Download all

Accessories

Electrical cable

article number
type
control
dimensions
THROUGH WIRE
004-90005
5 × 1.5 mm² | 10 pieces
DALI-2
0.3 kg

Mounting

article number
type
colour
dimensions
CABLE SUSPENSION
005-2152110
chrome
width 46 mm
0.05 kg
END CAPS
074-6090017
1 pair
pure white
RAL 9010
length 30 mm
width 42 mm
height 42 mm
0.03 kg
END CAPS
074-6090018
1 pair
jet black
RAL 9005
length 30 mm
width 42 mm
height 42 mm
0.04 kg
LINEAR CONNECTOR incl. cable suspension
074-6091120
mechanical
length 120 mm
width 28 mm
0.1 kg

Electrical components

article number
colour
type
dimensions
feeder cable length
CANOPY square
005-2212417
pure white
RAL 9010
incl. feeder cable 5 × 1.5 mm²
length 90 mm
width 90 mm
height 22 mm
0.29 kg
1,500 mm
CANOPY square
005-2212418
jet black
RAL 9005
incl. feeder cable 5 × 1.5 mm²
length 90 mm
width 90 mm
height 22 mm
0.29 kg
1,500 mm

Electrical mounting

article number
colour
type
dimensions
CORNER CONNECTOR 90°
074-6091217
pure white
RAL 9010
incl. through wire 5 × 1.5 mm²
length 250 mm
width 250 mm
height 42 mm
0.7 kg
CORNER CONNECTOR 90°
074-6091218
jet black
RAL 9005
incl. through wire 5 × 1.5 mm²
length 250 mm
width 250 mm
height 42 mm
1.3 kg

Optical

article number
colour
dimensions
BLIND COVER
074-6099107
pure white
RAL 9010
length 250 mm
width 38 mm
0.04 kg
BLIND COVER
074-6099108
jet black
RAL 9005
length 250 mm
width 38 mm
0.05 kg
BLIND COVER
074-6099117
pure white
RAL 9010
length 500 mm
width 38 mm
0.1 kg
BLIND COVER
074-6099118
jet black
RAL 9005
length 500 mm
width 38 mm
0.08 kg
