MINO 25

recessed

New

Quickinfo

3000 K, 4000 K
CRI ≥ 80, CRI ≥ 90 / 3 SDCM (initial MacAdam)
UGR ≤ 16, UGR ≤ 19
up to 168 lm/W
L90 / 100000 h, L90 / 50000 h
DALI-2
Wideflood
IP20

Colour

signal white

signal black

aluminium raw

Inset

chrome

traffic white

jet black

black

Products and codes

Simple drawing

Light distribution

Downloads & links

Product data & specification documents

Datasheet product line

Download all

Aggregated downloads

ROLF
ULD

Description

Luminaire housing from extruded aluminium profile, angular design; recessed luminaire with trim; surface raw or powder coated; high quality reflector with micro-faceted, aluminum-vaporised surface; or fitted with single LED light points; good glare reduction due to recessed light point plane; despite this increased efficiency through special lens technology; inserted lenses with wide flood radiation characteristic; precise radiation characteristic with symmetrical light distribution; or completely homogeneously illuminated, opal cover; converter integrated into luminaire housing; energy-efficient LEDs with very good colour rendering

black & chrome louver

up to 168 lm/W (high efficiency)

Products and codes

Filter

Colour

signal white

signal black

aluminium raw

Inset

chrome

traffic white

jet black

black

MINO 25 louver trim

Status

Article number(s)

Type

Dimming

signal white, Inset black reflector, 3000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal white, Inset black reflector, 4000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal white, Inset black reflector, 3000 K, CRI ≥ 80, system 10.7 W, 152 lm/W, length 1,004 mm

DALI-2

signal white, Inset black reflector, 4000 K, CRI ≥ 80, system 10.7 W, 162 lm/W, length 1,004 mm

DALI-2

signal white, Inset black reflector, 3000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal white, Inset black reflector, 4000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal white, Inset black reflector, 3000 K, CRI ≥ 80, system 20.6 W, 158 lm/W, length 2,004 mm

DALI-2

signal white, Inset black reflector, 4000 K, CRI ≥ 80, system 20.6 W, 168 lm/W, length 2,004 mm

DALI-2

signal white, Inset black reflector, 3000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal white, Inset black reflector, 4000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal white, Inset black reflector, 3000 K, CRI ≥ 80, system 27.5 W, 158 lm/W, length 2,754 mm

DALI-2

signal white, Inset black reflector, 4000 K, CRI ≥ 80, system 27.5 W, 168 lm/W, length 2,754 mm

DALI-2

MINO 25 louver trim

Status

Article number(s)

Type

Dimming

signal white, Inset chrome reflector, 3000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal white, Inset chrome reflector, 4000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal white, Inset chrome reflector, 3000 K, CRI ≥ 80, system 10.7 W, 152 lm/W, length 1,004 mm

DALI-2

signal white, Inset chrome reflector, 4000 K, CRI ≥ 80, system 10.7 W, 162 lm/W, length 1,004 mm

DALI-2

signal white, Inset chrome reflector, 3000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal white, Inset chrome reflector, 4000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal white, Inset chrome reflector, 3000 K, CRI ≥ 80, system 20.6 W, 158 lm/W, length 2,004 mm

DALI-2

signal white, Inset chrome reflector, 4000 K, CRI ≥ 80, system 20.6 W, 168 lm/W, length 2,004 mm

DALI-2

signal white, Inset chrome reflector, 3000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal white, Inset chrome reflector, 4000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal white, Inset chrome reflector, 3000 K, CRI ≥ 80, system 27.5 W, 158 lm/W, length 2,754 mm

DALI-2

signal white, Inset chrome reflector, 4000 K, CRI ≥ 80, system 27.5 W, 168 lm/W, length 2,754 mm

DALI-2

MINO 25 louver trim

Status

Article number(s)

Type

Dimming

signal black, Inset black reflector, 3000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal black, Inset black reflector, 4000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal black, Inset black reflector, 3000 K, CRI ≥ 80, system 10.7 W, 152 lm/W, length 1,004 mm

DALI-2

signal black, Inset black reflector, 4000 K, CRI ≥ 80, system 10.7 W, 162 lm/W, length 1,004 mm

DALI-2

signal black, Inset black reflector, 3000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal black, Inset black reflector, 4000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal black, Inset black reflector, 3000 K, CRI ≥ 80, system 20.6 W, 158 lm/W, length 2,004 mm

DALI-2

signal black, Inset black reflector, 4000 K, CRI ≥ 80, system 20.6 W, 168 lm/W, length 2,004 mm

DALI-2

signal black, Inset black reflector, 3000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal black, Inset black reflector, 4000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal black, Inset black reflector, 3000 K, CRI ≥ 80, system 27.5 W, 158 lm/W, length 2,754 mm

DALI-2

signal black, Inset black reflector, 4000 K, CRI ≥ 80, system 27.5 W, 168 lm/W, length 2,754 mm

DALI-2

MINO 25 louver trim

Status

Article number(s)

Type

Dimming

signal black, Inset chrome reflector, 3000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal black, Inset chrome reflector, 4000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

signal black, Inset chrome reflector, 3000 K, CRI ≥ 80, system 10.7 W, 152 lm/W, length 1,004 mm

DALI-2

signal black, Inset chrome reflector, 4000 K, CRI ≥ 80, system 10.7 W, 162 lm/W, length 1,004 mm

DALI-2

signal black, Inset chrome reflector, 3000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal black, Inset chrome reflector, 4000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

signal black, Inset chrome reflector, 3000 K, CRI ≥ 80, system 20.6 W, 158 lm/W, length 2,004 mm

DALI-2

signal black, Inset chrome reflector, 4000 K, CRI ≥ 80, system 20.6 W, 168 lm/W, length 2,004 mm

DALI-2

signal black, Inset chrome reflector, 3000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal black, Inset chrome reflector, 4000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

signal black, Inset chrome reflector, 3000 K, CRI ≥ 80, system 27.5 W, 158 lm/W, length 2,754 mm

DALI-2

signal black, Inset chrome reflector, 4000 K, CRI ≥ 80, system 27.5 W, 168 lm/W, length 2,754 mm

DALI-2

MINO 25 louver trim

Status

Article number(s)

Type

Dimming

aluminium raw, Inset black reflector, 3000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset black reflector, 4000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset black reflector, 3000 K, CRI ≥ 80, system 10.7 W, 152 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset black reflector, 4000 K, CRI ≥ 80, system 10.7 W, 162 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset black reflector, 3000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset black reflector, 4000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset black reflector, 3000 K, CRI ≥ 80, system 20.6 W, 158 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset black reflector, 4000 K, CRI ≥ 80, system 20.6 W, 168 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset black reflector, 3000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset black reflector, 4000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset black reflector, 3000 K, CRI ≥ 80, system 27.5 W, 158 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset black reflector, 4000 K, CRI ≥ 80, system 27.5 W, 168 lm/W, length 2,754 mm

DALI-2

MINO 25 louver trim

Status

Article number(s)

Type

Dimming

aluminium raw, Inset chrome reflector, 3000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 4000 K, CRI ≥ 90, system 10.7 W, 133 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 3000 K, CRI ≥ 80, system 10.7 W, 152 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 4000 K, CRI ≥ 80, system 10.7 W, 162 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 3000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 4000 K, CRI ≥ 90, system 20.6 W, 138 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 3000 K, CRI ≥ 80, system 20.6 W, 158 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 4000 K, CRI ≥ 80, system 20.6 W, 168 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset chrome reflector, 3000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset chrome reflector, 4000 K, CRI ≥ 90, system 27.5 W, 138 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset chrome reflector, 3000 K, CRI ≥ 80, system 27.5 W, 158 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset chrome reflector, 4000 K, CRI ≥ 80, system 27.5 W, 168 lm/W, length 2,754 mm

DALI-2

MINO 25 spotline trim

Status

Article number(s)

Type

Dimming

signal white, Inset jet black, 3000 K, CRI ≥ 90, system 10.7 W, 123 lm/W, length 1,004 mm

DALI-2

signal white, Inset jet black, 4000 K, CRI ≥ 90, system 10.7 W, 123 lm/W, length 1,004 mm

DALI-2

signal white, Inset jet black, 3000 K, CRI ≥ 80, system 10.7 W, 142 lm/W, length 1,004 mm

DALI-2

signal white, Inset jet black, 4000 K, CRI ≥ 80, system 10.7 W, 151 lm/W, length 1,004 mm

DALI-2

signal white, Inset jet black, 3000 K, CRI ≥ 90, system 20.6 W, 128 lm/W, length 2,004 mm

DALI-2

signal white, Inset jet black, 4000 K, CRI ≥ 90, system 20.6 W, 128 lm/W, length 2,004 mm

DALI-2

signal white, Inset jet black, 3000 K, CRI ≥ 80, system 20.6 W, 147 lm/W, length 2,004 mm

DALI-2

signal white, Inset jet black, 4000 K, CRI ≥ 80, system 20.6 W, 157 lm/W, length 2,004 mm

DALI-2

signal white, Inset jet black, 3000 K, CRI ≥ 90, system 27.5 W, 128 lm/W, length 2,754 mm

DALI-2

signal white, Inset jet black, 4000 K, CRI ≥ 90, system 27.5 W, 128 lm/W, length 2,754 mm

DALI-2

signal white, Inset jet black, 3000 K, CRI ≥ 80, system 27.5 W, 147 lm/W, length 2,754 mm

DALI-2

signal white, Inset jet black, 4000 K, CRI ≥ 80, system 27.5 W, 157 lm/W, length 2,754 mm

DALI-2

MINO 25 spotline trim

Status

Article number(s)

Type

Dimming

signal white, Inset traffic white, 3000 K, CRI ≥ 90, system 10.7 W, 131 lm/W, length 1,004 mm

DALI-2

signal white, Inset traffic white, 4000 K, CRI ≥ 90, system 10.7 W, 131 lm/W, length 1,004 mm

DALI-2

signal white, Inset traffic white, 3000 K, CRI ≥ 80, system 10.7 W, 150 lm/W, length 1,004 mm

DALI-2

signal white, Inset traffic white, 4000 K, CRI ≥ 80, system 10.7 W, 160 lm/W, length 1,004 mm

DALI-2

signal white, Inset traffic white, 3000 K, CRI ≥ 90, system 20.6 W, 135 lm/W, length 2,004 mm

DALI-2

signal white, Inset traffic white, 4000 K, CRI ≥ 90, system 20.6 W, 135 lm/W, length 2,004 mm

DALI-2

signal white, Inset traffic white, 3000 K, CRI ≥ 80, system 20.6 W, 156 lm/W, length 2,004 mm

DALI-2

signal white, Inset traffic white, 4000 K, CRI ≥ 80, system 20.6 W, 166 lm/W, length 2,004 mm

DALI-2

signal white, Inset traffic white, 3000 K, CRI ≥ 90, system 27.5 W, 136 lm/W, length 2,754 mm

DALI-2

signal white, Inset traffic white, 4000 K, CRI ≥ 90, system 27.5 W, 136 lm/W, length 2,754 mm

DALI-2

signal white, Inset traffic white, 3000 K, CRI ≥ 80, system 27.5 W, 156 lm/W, length 2,754 mm

DALI-2

signal white, Inset traffic white, 4000 K, CRI ≥ 80, system 27.5 W, 166 lm/W, length 2,754 mm

DALI-2

MINO 25 spotline trim

Status

Article number(s)

Type

Dimming

signal black, Inset jet black, 3000 K, CRI ≥ 90, system 10.7 W, 123 lm/W, length 1,004 mm

DALI-2

signal black, Inset jet black, 4000 K, CRI ≥ 90, system 10.7 W, 123 lm/W, length 1,004 mm

DALI-2

signal black, Inset jet black, 3000 K, CRI ≥ 80, system 10.7 W, 142 lm/W, length 1,004 mm

DALI-2

signal black, Inset jet black, 4000 K, CRI ≥ 80, system 10.7 W, 151 lm/W, length 1,004 mm

DALI-2

signal black, Inset jet black, 3000 K, CRI ≥ 90, system 20.6 W, 128 lm/W, length 2,004 mm

DALI-2

signal black, Inset jet black, 4000 K, CRI ≥ 90, system 20.6 W, 128 lm/W, length 2,004 mm

DALI-2

signal black, Inset jet black, 3000 K, CRI ≥ 80, system 20.6 W, 147 lm/W, length 2,004 mm

DALI-2

signal black, Inset jet black, 4000 K, CRI ≥ 80, system 20.6 W, 157 lm/W, length 2,004 mm

DALI-2

signal black, Inset jet black, 3000 K, CRI ≥ 90, system 27.5 W, 128 lm/W, length 2,754 mm

DALI-2

signal black, Inset jet black, 4000 K, CRI ≥ 90, system 27.5 W, 128 lm/W, length 2,754 mm

DALI-2

signal black, Inset jet black, 3000 K, CRI ≥ 80, system 27.5 W, 147 lm/W, length 2,754 mm

DALI-2

signal black, Inset jet black, 4000 K, CRI ≥ 80, system 27.5 W, 157 lm/W, length 2,754 mm

DALI-2

MINO 25 spotline trim

Status

Article number(s)

Type

Dimming

signal black, Inset traffic white, 3000 K, CRI ≥ 90, system 10.7 W, 131 lm/W, length 1,004 mm

DALI-2

signal black, Inset traffic white, 4000 K, CRI ≥ 90, system 10.7 W, 131 lm/W, length 1,004 mm

DALI-2

signal black, Inset traffic white, 3000 K, CRI ≥ 80, system 10.7 W, 150 lm/W, length 1,004 mm

DALI-2

signal black, Inset traffic white, 4000 K, CRI ≥ 80, system 10.7 W, 160 lm/W, length 1,004 mm

DALI-2

signal black, Inset traffic white, 3000 K, CRI ≥ 90, system 20.6 W, 135 lm/W, length 2,004 mm

DALI-2

signal black, Inset traffic white, 4000 K, CRI ≥ 90, system 20.6 W, 135 lm/W, length 2,004 mm

DALI-2

signal black, Inset traffic white, 3000 K, CRI ≥ 80, system 20.6 W, 156 lm/W, length 2,004 mm

DALI-2

signal black, Inset traffic white, 4000 K, CRI ≥ 80, system 20.6 W, 166 lm/W, length 2,004 mm

DALI-2

signal black, Inset traffic white, 3000 K, CRI ≥ 90, system 27.5 W, 136 lm/W, length 2,754 mm

DALI-2

signal black, Inset traffic white, 4000 K, CRI ≥ 90, system 27.5 W, 136 lm/W, length 2,754 mm

DALI-2

signal black, Inset traffic white, 3000 K, CRI ≥ 80, system 27.5 W, 156 lm/W, length 2,754 mm

DALI-2

signal black, Inset traffic white, 4000 K, CRI ≥ 80, system 27.5 W, 166 lm/W, length 2,754 mm

DALI-2

MINO 25 spotline trim

Status

Article number(s)

Type

Dimming

aluminium raw, Inset jet black, 3000 K, CRI ≥ 90, system 10.7 W, 123 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset jet black, 4000 K, CRI ≥ 90, system 10.7 W, 123 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset jet black, 3000 K, CRI ≥ 80, system 10.7 W, 142 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset jet black, 4000 K, CRI ≥ 80, system 10.7 W, 151 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset jet black, 3000 K, CRI ≥ 90, system 20.6 W, 128 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset jet black, 4000 K, CRI ≥ 90, system 20.6 W, 128 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset jet black, 3000 K, CRI ≥ 80, system 20.6 W, 147 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset jet black, 4000 K, CRI ≥ 80, system 20.6 W, 157 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset jet black, 3000 K, CRI ≥ 90, system 27.5 W, 128 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset jet black, 4000 K, CRI ≥ 90, system 27.5 W, 128 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset jet black, 3000 K, CRI ≥ 80, system 27.5 W, 147 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset jet black, 4000 K, CRI ≥ 80, system 27.5 W, 157 lm/W, length 2,754 mm

DALI-2

MINO 25 spotline trim

Status

Article number(s)

Type

Dimming

aluminium raw, Inset traffic white, 3000 K, CRI ≥ 90, system 10.7 W, 131 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset traffic white, 4000 K, CRI ≥ 90, system 10.7 W, 131 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset traffic white, 3000 K, CRI ≥ 80, system 10.7 W, 150 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset traffic white, 4000 K, CRI ≥ 80, system 10.7 W, 160 lm/W, length 1,004 mm

DALI-2

aluminium raw, Inset traffic white, 3000 K, CRI ≥ 90, system 20.6 W, 135 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset traffic white, 4000 K, CRI ≥ 90, system 20.6 W, 135 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset traffic white, 3000 K, CRI ≥ 80, system 20.6 W, 156 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset traffic white, 4000 K, CRI ≥ 80, system 20.6 W, 166 lm/W, length 2,004 mm

DALI-2

aluminium raw, Inset traffic white, 3000 K, CRI ≥ 90, system 27.5 W, 136 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset traffic white, 4000 K, CRI ≥ 90, system 27.5 W, 136 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset traffic white, 3000 K, CRI ≥ 80, system 27.5 W, 156 lm/W, length 2,754 mm

DALI-2

aluminium raw, Inset traffic white, 4000 K, CRI ≥ 80, system 27.5 W, 166 lm/W, length 2,754 mm

DALI-2

MINO 25

recessed

Quickinfo

Colour

Inset

Simple drawing

Light distribution

Product data & specification documents

Description

Products and codes

Colour

Inset

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 louver trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

MINO 25 spotline trim

Related products
