PABLO focus
180-5220038
Quickinfo
3000 KCRI ≥ 95 / 2 SDCM
56 lm/W
L90 / 50000 h
DALI-2
IP20
Colour
General
- Ceiling
- Track
- tilt max 310°
- rotation 360°
- jet black
- RAL 9005
- IP20
- 4621-7852 lm
LED
- 3000 K
- CRI ≥ 95
- L90 / 50000 h
- initial MacAdam ≤ 2 SDCM
-
Rg: 99
-
Rf: 94
-
R{1-15}: 96
-
MR 0.66
-
MDER 0.6
Optical
- focus
- beam angle 17°1-47°2
-
≤ 1.01 2 3
-
SVM ≤ 0.41 2 3
Electrical
- DALI-2
- 220-240 V
- system 14.0 W
- system 331-562 lm/W 4
- PC1
- 1 DALI Addr.
Physical
- diameter 70 mm
- height 106 mm
- 0.9 kg
- tool-free fixation
Circuit Breaker Types
Automatic Circuit Breaker Type
Number of Fixtures
Track light made of die-cast aluminium; surface jet black powder coated; 360° rotatable and 310° tiltable; converter installed in aluminium spotlight housing; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 3000 K; binning initial MacAdam ≤ 2 SDCM; CRI ≥ 95; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; incl. high quality plano-convex glass lens; precise object focusing through adjustable lens; adjustable beam angle of 17° - 47°; focusing by means of rubberised adjusting ring on the spotlight head; degree of protection IP20; PC1; 220-240 V; adapter for toolless insertion or movement on a variety of 3-phase power tracks; adapter fixation without tools by means of knurled screw; incl. DALI-2 converter; point outlet, either in surface mounted housing or recessed housing, available as an accessory; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
