FINA opal

FINA opal

011-1105116O

Quickinfo

4000 K
CRI ≥ 97 / 3 SDCM
1,130 lm/m
79 lm/W
L85 / 50000 h
excl. driver
Opal
IP20

Colour

Datasheet

General

  • Showcase
  • Recessed
  • white aluminium
  • RAL 9006
  • IP20
  • Interior
  • 873 lm
  • 1130 lm/m
  • optical inset 79 lm/W 1

LED

  • 4000 K
  • CRI ≥ 97
  • L85 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • Rg: 100
  • Rf: 96
  • R{1-15}: 98
  • MR 0.86
  • MDER 0.78

Optical

  • Opal
  • opal (lambertsch)

Electrical

  • excl. driver
  • 24 V
  • fixture 14.6 W
  • optical inset 11.0 W
  • PC3
  • 19 W/m
  • 24 V

Physical

  • length 800 mm
  • width 9 mm
  • height 9 mm
1 incl. consideration of optical losses

Miniature linear light inset made of aluminium; tubular design; surface lacquered in white aluminium; optionally for recessed or surface mounting (available as an accessory); plug and play electrical connector system for toolless mounting; different connectors for mechanical and electrical connection available - for flexible system design (available as an accessory); completely homogeneously illuminated, satinised PMMA cover; light colour 4000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 97; min. 85% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; light inset rotatable; degree of protection IP20; PC3; 24 V; accessories are listed separately; light source replaceable by an authorized professional;

Product data & specification documents

Download all

Datasheets

Download all

Planing files & lighting data

Download all
Download all
lightDistribution Download
mainDrawing

Accessories

Mounting

article number
colour
dimensions
MOUNTING CLIP 90 surface
011-9100008
tar black
RAL 9021
0.03 kg
MOUNTING CHANNEL 90
011-9100206
white aluminium
RAL 9006
length 230 mm
width 17 mm
height 11 mm
MOUNTING CHANNEL 90
011-9100208
tar black
RAL 9021
length 230 mm
width 17 mm
height 11 mm
0.02 kg
MOUNTING CHANNEL 90
011-9100306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 90
011-9100308
tar black
RAL 9021
length 430 mm
width 17 mm
height 11 mm
0.02 kg
MOUNTING CHANNEL 90
011-9100406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 11 mm
0.5 kg
MOUNTING CHANNEL 90
011-9100408
tar black
RAL 9021
length 630 mm
width 17 mm
height 11 mm
0.03 kg
MOUNTING CHANNEL 90
011-9100506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 11 mm
0.02 kg
MOUNTING CHANNEL 90
011-9100508
tar black
RAL 9021
length 830 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 90
011-9100606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 11 mm
0.08 kg
MOUNTING CHANNEL 90
011-9100608
tar black
RAL 9021
length 1,030 mm
width 17 mm
height 11 mm
0.08 kg
MOUNTING CHANNEL 90
011-9100706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 11 mm
0.08 kg
MOUNTING CHANNEL 90
011-9100708
tar black
RAL 9021
length 1,230 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101206
white aluminium
RAL 9006
length 230 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101208
tar black
RAL 9021
length 230 mm
width 17 mm
height 15 mm
0.01 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 15 mm
0.06 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101308
tar black
RAL 9021
length 430 mm
width 17 mm
height 15 mm
0.02 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101408
tar black
RAL 9021
length 630 mm
width 17 mm
height 15 mm
0.01 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101508
tar black
RAL 9021
length 830 mm
width 17 mm
height 15 mm
0.06 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 15 mm
0.08 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101608
tar black
RAL 9021
length 1,030 mm
width 17 mm
height 15 mm
0.08 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101708
tar black
RAL 9021
length 1,230 mm
width 17 mm
height 15 mm
MOUNTING CLIP 60 surface
011-9102008
tar black
RAL 9021
0.03 kg
MOUNTING CHANNEL 60
011-9102206
white aluminium
RAL 9006
length 230 mm
width 40 mm
height 11 mm
MOUNTING CHANNEL 60
011-9102208
tar black
RAL 9021
length 230 mm
width 40 mm
height 11 mm
0.02 kg
MOUNTING CHANNEL 60
011-9102306
white aluminium
RAL 9006
length 430 mm
width 40 mm
height 11 mm
0.04 kg
MOUNTING CHANNEL 60
011-9102308
tar black
RAL 9021
length 430 mm
width 40 mm
height 11 mm
0.05 kg
MOUNTING CHANNEL 60
011-9102406
white aluminium
RAL 9006
length 630 mm
width 40 mm
height 11 mm
0.04 kg
MOUNTING CHANNEL 60
011-9102408
tar black
RAL 9021
length 630 mm
width 40 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 60
011-9102506
white aluminium
RAL 9006
length 830 mm
width 40 mm
height 11 mm
MOUNTING CHANNEL 60
011-9102508
tar black
RAL 9021
length 830 mm
width 40 mm
height 11 mm
0.07 kg
MOUNTING CHANNEL 60
011-9102606
white aluminium
RAL 9006
length 1,030 mm
width 40 mm
height 11 mm
MOUNTING CHANNEL 60
011-9102608
tar black
RAL 9021
length 1,030 mm
width 40 mm
height 11 mm
0.1 kg
MOUNTING CHANNEL 60
011-9102706
white aluminium
RAL 9006
length 1,230 mm
width 40 mm
height 11 mm
MOUNTING CHANNEL 60
011-9102708
tar black
RAL 9021
length 1,230 mm
width 40 mm
height 11 mm
0.14 kg
MOUNTING CLIP 45 surface
011-9103008
tar black
RAL 9021
0.03 kg
MOUNTING CHANNEL 45
011-9103206
white aluminium
RAL 9006
length 230 mm
width 17 mm
height 11 mm
MOUNTING CHANNEL 45
011-9103208
tar black
RAL 9021
length 230 mm
width 17 mm
height 11 mm
0.01 kg
MOUNTING CHANNEL 45
011-9103306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 11 mm
0.03 kg
MOUNTING CHANNEL 45
011-9103308
tar black
RAL 9021
length 430 mm
width 17 mm
height 11 mm
0.02 kg
MOUNTING CHANNEL 45
011-9103406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 45
011-9103408
tar black
RAL 9021
length 630 mm
width 17 mm
height 11 mm
0.05 kg
MOUNTING CHANNEL 45
011-9103506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 45
011-9103508
tar black
RAL 9021
length 830 mm
width 17 mm
height 11 mm
0.08 kg
MOUNTING CHANNEL 45
011-9103606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 11 mm
0.09 kg
MOUNTING CHANNEL 45
011-9103608
tar black
RAL 9021
length 1,030 mm
width 17 mm
height 11 mm
0.1 kg
MOUNTING CHANNEL 45
011-9103706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 11 mm
0.12 kg
MOUNTING CHANNEL 45
011-9103708
tar black
RAL 9021
length 1,230 mm
width 17 mm
height 11 mm
7 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104206
white aluminium
RAL 9006
length 230 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104208
tar black
RAL 9021
length 230 mm
width 17 mm
height 18 mm
0.02 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 18 mm
0.03 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104308
tar black
RAL 9021
length 430 mm
width 17 mm
height 18 mm
0.04 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 18 mm
0.05 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104408
tar black
RAL 9021
length 630 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104508
tar black
RAL 9021
length 830 mm
width 17 mm
height 18 mm
0.5 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104608
tar black
RAL 9021
length 1,030 mm
width 17 mm
height 18 mm
0.08 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104708
tar black
RAL 9021
length 1,230 mm
width 17 mm
height 18 mm
MOUNTING TOOL
011-9190000
0.01 kg

Optical

article number
colour
dimensions
BLIND INSET
011-9109206
white aluminium
RAL 9006
diameter 9 mm
height 200 mm
0.02 kg
BLIND INSET
011-9109208
tar black
RAL 9021
diameter 9 mm
height 200 mm
0.05 kg
BLIND INSET
011-9109306
white aluminium
RAL 9006
diameter 9 mm
height 400 mm
0.05 kg
BLIND INSET
011-9109308
tar black
RAL 9021
diameter 9 mm
height 400 mm
0.05 kg
BLIND INSET
011-9109406
white aluminium
RAL 9006
diameter 9 mm
height 600 mm
BLIND INSET
011-9109408
tar black
RAL 9021
diameter 9 mm
height 600 mm
BLIND INSET
011-9109506
white aluminium
RAL 9006
diameter 9 mm
height 800 mm
0.1 kg
BLIND INSET
011-9109508
tar black
RAL 9021
diameter 9 mm
height 800 mm
BLIND INSET
011-9109606
white aluminium
RAL 9006
diameter 9 mm
height 1,000 mm
BLIND INSET
011-9109608
tar black
RAL 9021
diameter 9 mm
height 1,000 mm
0.09 kg
BLIND INSET
011-9109706
white aluminium
RAL 9006
diameter 9 mm
height 1,200 mm
BLIND INSET
011-9109708
tar black
RAL 9021
diameter 9 mm
height 1,200 mm
0.12 kg

Converter

article number
power
voltage / frequency
protection class
constant current
control
POWER SUPPLY 24V EU
011-9212110
18 W
min 50 Hz
max 60 Hz
PC2
350 mA
non DIM
POWER SUPPLY 24V EU
011-9212130
18 W
min 50 Hz
max 60 Hz
PC2
350 mA
DALI-2
POWER SUPPLY 24V EU
011-9212210
35 W
min 50 Hz
max 60 Hz
PC2
350 mA
non DIM
POWER SUPPLY 24V EU
011-9212230
35 W
min 50 Hz
max 60 Hz
PC2
350 mA
DALI-2
POWER SUPPLY 24V EU
011-9212310
100 W
min 50 Hz
max 60 Hz
PC2
350 mA
non DIM
POWER SUPPLY 24V EU
011-9212330
60 W
min 50 Hz
max 60 Hz
PC2
350 mA
DALI-2
POWER SUPPLY 24V UL
011-9282110
60 W
min 50 Hz
max 60 Hz
PC2
350 mA
non DIM
POWER SUPPLY 24V UL
011-9282210
40 W
min 50 Hz
max 60 Hz
PC2
350 mA
non DIM
POWER SUPPLY 24V UL
011-9282310
350 mA
non DIM
POWER SUPPLY 24V UL
011-9282320
60 W
min 50 Hz
max 60 Hz
PC2
350 mA
POWER SUPPLY 24V UL
011-9282330
60 W
min 50 Hz
max 60 Hz
PC2
350 mA
DALI-2

Electrical cable

article number
type
dimensions
feeder cable length
EXTENSION CABLE
011-9222120
1 × socket / 1 × plug
0.04 kg
1,000 mm
EXTENSION CABLE
011-9222140
1 × socket / 1 × plug
0.07 kg
2,000 mm
EXTENSION CABLE
011-9222180
1 × socket / 1 × plug
0.13 kg
4,000 mm
EXTENSION CABLE
011-9222220
1 × socket / 1 × plug 90°
0.04 kg
1,000 mm
EXTENSION CABLE
011-9222240
1 × socket / 1 × plug 90°
0.34 kg
2,000 mm
EXTENSION CABLE
011-9222280
1 × socket / 1 × plug 90°
0.13 kg
4,000 mm

Electrical mounting

article number
type
dimensions
FLEX CONNECTOR
011-9225100
electrical
length 100 mm
width 9 mm
0.01 kg
FLEX CONNECTOR
011-9225200
electrical | 90°
length 39 mm
width 39 mm
height 9 mm
LINEAR CONNECTOR
011-9225300
electrical
length 18 mm
width 6 mm
0.02 kg

Related products

New Version

FINA

spot line system
New Version

FINA

lead system

FINA

stadio system

FINA SUPPORT

stadio standing system
New Version

FINA

spot line system
New Version

FINA

lead system

FINA

stadio system
New Version

FINA SUPPORT

spot line standing system
New Version

FINA SUPPORT

opal standing system
New Version

FINA SUPPORT

lead standing system
