FINA opal
011-1106118O
Quickinfo
4000 KCRI ≥ 97 / 3 SDCM (initial MacAd
1,120 lm/m
79 lm/W
L85 / 50000 h
excl. driver
Opal
IP20
Colour
General
- Showcase
- Recessed
- tar black
- RAL 9021
- IP20
- Interior
- 1090 lm
- 1120 lm/m
- optical inset 79 lm/W 1
LED
- 4000 K
- CRI ≥ 97
- L85 / 50000 h
- ≤ 3 SDCM (initial MacAdam)
- Rg: 100
- Rf: 96
- R{1-15}: 98
- MR 0.86
- MDER 0.78
Optical
- Opal
- opal (lambertsch)
Electrical
- excl. driver
- 24 V
- fixture 18.2 W
- optical inset 13.8 W
- PC3
- 19 W/m
- 24 V
Physical
- length 1000 mm
- width 9 mm
- height 9 mm
- 0.2 kg
1 incl. consideration of optical losses
Miniature linear light inset made of aluminium; tubular design; surface lacquered in tar black; optionally for recessed or surface mounting (available as an accessory); plug and play electrical connector system for toolless mounting; different connectors for mechanical and electrical connection available - for flexible system design (available as an accessory); completely homogeneously illuminated, satinised PMMA cover; light colour 4000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 97; min. 85% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; light inset rotatable; degree of protection IP20; PC3; 24 V; accessories are listed separately; light source replaceable by an authorized professional;
Accessories
Mounting
article number
colour
dimensions
MOUNTING CHANNEL 90
011-9100306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 90
011-9100406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 11 mm
0.5 kg
MOUNTING CHANNEL 90
011-9100506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 11 mm
0.02 kg
MOUNTING CHANNEL 90
011-9100606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 11 mm
0.08 kg
MOUNTING CHANNEL 90
011-9100706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 11 mm
0.08 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101206
white aluminium
RAL 9006
length 230 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101208
tar black
RAL 9021
length 230 mm
width 17 mm
height 15 mm
0.01 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 15 mm
0.06 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101308
tar black
RAL 9021
length 430 mm
width 17 mm
height 15 mm
0.02 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101408
tar black
RAL 9021
length 630 mm
width 17 mm
height 15 mm
0.01 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101508
tar black
RAL 9021
length 830 mm
width 17 mm
height 15 mm
0.06 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 15 mm
0.08 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101608
tar black
RAL 9021
length 1,030 mm
width 17 mm
height 15 mm
0.08 kg
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 15 mm
MOUNTING CHANNEL 90 ANTI-GLARE
011-9101708
tar black
RAL 9021
length 1,230 mm
width 17 mm
height 15 mm
0.06 kg
MOUNTING CHANNEL 60
011-9102306
white aluminium
RAL 9006
length 430 mm
width 40 mm
height 11 mm
0.04 kg
MOUNTING CHANNEL 60
011-9102406
white aluminium
RAL 9006
length 630 mm
width 40 mm
height 11 mm
0.04 kg
MOUNTING CHANNEL 45
011-9103306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 11 mm
0.03 kg
MOUNTING CHANNEL 45
011-9103406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 45
011-9103506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 11 mm
0.06 kg
MOUNTING CHANNEL 45
011-9103606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 11 mm
0.09 kg
MOUNTING CHANNEL 45
011-9103706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 11 mm
0.12 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104206
white aluminium
RAL 9006
length 230 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104208
tar black
RAL 9021
length 230 mm
width 17 mm
height 18 mm
0.02 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104306
white aluminium
RAL 9006
length 430 mm
width 17 mm
height 18 mm
0.03 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104308
tar black
RAL 9021
length 430 mm
width 17 mm
height 18 mm
0.04 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104406
white aluminium
RAL 9006
length 630 mm
width 17 mm
height 18 mm
0.05 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104506
white aluminium
RAL 9006
length 830 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104508
tar black
RAL 9021
length 830 mm
width 17 mm
height 18 mm
0.5 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104606
white aluminium
RAL 9006
length 1,030 mm
width 17 mm
height 18 mm
MOUNTING CHANNEL 45 JUT-OUT
011-9104608
tar black
RAL 9021
length 1,030 mm
width 17 mm
height 18 mm
0.08 kg
MOUNTING CHANNEL 45 JUT-OUT
011-9104706
white aluminium
RAL 9006
length 1,230 mm
width 17 mm
height 18 mm
