TASK S curve direct
suspended system
059-5542137K
Quickinfo
4000 KCRI ≥ 90 / 3 SDCM (initial MacAdam)
UGR ≤ 19 / 65° ≤ 3,000 cd/m²
120 lm/W
L90 / 50000 h
DALI-2
Microprismatic
IP20 / PC1 / 220-240 V
Colour
General
- Ceiling
- Suspended
- pure white
- RAL 9010
- IP20
- 1550 lm
LED
- 4000 K
- CRI ≥ 90
- L90 / 50000 h
- ≤ 3 SDCM (initial MacAdam)
- Rg: 96
- Rf: 90
- R{1-15}: 87
- MR 0.75
- MDER 0.68
Optical
- Microprismatic
- microprismatic
- UGR ≤ 19
- ≤ 1.0 1
- SVM ≤ 0.4 1
- ≥65° <3000 cd/m²
Electrical
- DALI-2
- 220-240 V
- system 12.9 W
- system 120 lm/W 2
- PC1
- 1 DALI Addr.
- without power feeder
Physical
- length 763 mm
- width 180 mm
- height 34 mm
- centerline radius 675 mm
- 3.2 kg
Circuit Breaker Types
Automatic Circuit Breaker Type
Number of Fixtures
Luminaire housing made of aluminium with rounded edges; extremely flat (only 15mm) and slim (only 180mm) design; modern shape in an elegant design for high demands; for continuous lighting systems; surface pure white powder coated; with integrated toolless suspension height adjustment on the luminaire; convenient quick mounting system without tools; direct light distribution through LGP body (Light Guiding Prism); side coupled light directed downwards by laser engraving; light control via highly reflective reflector material; microprismatic PMMA cover; completely homogeneous illumination; same light density for all surface lights with the same components; UGR ≤ 19; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 3000 cd/m²; light colour 4000 K; ≤ 3 SDCM (initial MacAdam); CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; degree of protection IP20; PC1; 220-240 V; internal wiring in light halogen free; incl. DALI-2 converter; sound absorbing accessories available; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
Accessories
Mounting
Feeder
Electrical mounting
