TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended
TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended
TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended
XAL headquarters
Pleasant room acoustics
Ultra-slim and versatile

TASK square

suspended

Quickinfo

3000 K, 4000 K
CRI ≥ 90 / 3 SDCM
UGR ≤ 19
up to ↓ 6,020 lm / ↑ 1,620 lm
up to 137 lm/W
L90 / 50000 h
DALI-2
Microprismatic
IP20

Colour

    • Products and codes
    Discover family

    Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    Download all
    • 3DS
    • DWG - 3D
    • Revit BIM data

    Description

    Square housing made of aluminium with rounded edges; ultra low-profile design (only 15 mm); surface powder coated; pendant fitting with cable suspension (4 cables); with integrated toolless suspension height adjustment; incl. feeder cable; direct light distribution by LGP body (Light Guiding Prism); side coupled light directed downwards by laser engraving; light control via highly reflective reflector material; optional: indirect light component with special PCBs for increased luminous flux and maximum ceiling illumination; completely homogeneous illumination; energy-efficient LEDs with very good colour rendering; canopy for through wiring; sound absorbing accessories available

    DiiA® standards 251, 252, 253

    DIN EN 12464-1 UGR ≤ 19

    flat design (15 mm)

    acoustic elements

    CRI ≥ 98 XPECTRUM (optional)

    Products and codes

    Filter
    125
    lm/W
    137
    lm/W
    1880
    lm
    3730
    lm
    1470
    lm
    1620
    lm
    15
    W
    57
    W
    0.61
    0.75
    0.56
    0.68

    Colour

    • TASK 450 square direct / indirect power suspended, TASK 450 square direct suspended

    TASK 450 square direct / indirect power suspended

    TASK 450 square direct / indirect power suspended

    Status
    Article number(s)
    Type
    Dimming
    black, 3000 K, 125 lm/W
    DALI-2
    black, 4000 K, 133 lm/W
    DALI-2
    TASK 450 square direct / indirect power suspended, TASK 450 square direct suspended

    TASK 450 square direct / indirect power suspended

    TASK 450 square direct / indirect power suspended

    Status
    Article number(s)
    Type
    Dimming
    special colours, 3000 K, 125 lm/W
    DALI-2
    special colours, 4000 K, 133 lm/W
    DALI-2
    TASK 450 square direct / indirect power suspended, TASK 450 square direct suspended

    TASK 450 square direct / indirect power suspended

    TASK 450 square direct / indirect power suspended

    Status
    Article number(s)
    Type
    Dimming
    white, 3000 K, 125 lm/W
    DALI-2
    white, 4000 K, 133 lm/W
    DALI-2
    TASK 450 square direct / indirect power suspended, TASK 450 square direct suspended

    TASK 450 square direct suspended

    TASK 450 square direct suspended

    Status
    Article number(s)
    Type
    Dimming
    black, 3000 K, 125 lm/W
    DALI-2
    black, 4000 K, 133 lm/W
    DALI-2
    TASK 450 square direct / indirect power suspended, TASK 450 square direct suspended

    TASK 450 square direct suspended

    TASK 450 square direct suspended

    Status
    Article number(s)
    Type
    Dimming
    special colours, 3000 K, 125 lm/W
    DALI-2
    special colours, 4000 K, 133 lm/W
    DALI-2
    TASK 450 square direct / indirect power suspended, TASK 450 square direct suspended

    TASK 450 square direct suspended

    TASK 450 square direct suspended

    Status
    Article number(s)
    Type
    Dimming
    white, 3000 K, 125 lm/W
    DALI-2
    white, 4000 K, 133 lm/W
    DALI-2
    TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended

    TASK 600 square direct / indirect power suspended

    TASK 600 square direct / indirect power suspended

    Status
    Article number(s)
    Type
    Dimming
    black, 3000 K, 126 lm/W
    DALI-2
    black, 4000 K, 134 lm/W
    DALI-2
    TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended

    TASK 600 square direct / indirect power suspended

    TASK 600 square direct / indirect power suspended

    Status
    Article number(s)
    Type
    Dimming
    special colours, 3000 K, 126 lm/W
    DALI-2
    special colours, 4000 K, 134 lm/W
    DALI-2
    TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended

    TASK 600 square direct / indirect power suspended

    TASK 600 square direct / indirect power suspended

    Status
    Article number(s)
    Type
    Dimming
    white, 3000 K, 126 lm/W
    DALI-2
    white, 4000 K, 134 lm/W
    DALI-2
    TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended

    TASK 600 square direct suspended

    TASK 600 square direct suspended

    Status
    Article number(s)
    Type
    Dimming
    black, 3000 K, 129 lm/W
    DALI-2
    black, 4000 K, 137 lm/W
    DALI-2
    TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended

    TASK 600 square direct suspended

    TASK 600 square direct suspended

    Status
    Article number(s)
    Type
    Dimming
    special colours, 3000 K, 129 lm/W
    DALI-2
    special colours, 4000 K, 137 lm/W
    DALI-2
    TASK 600 square direct suspended, TASK 600 square direct / indirect power suspended

    TASK 600 square direct suspended

    TASK 600 square direct suspended

    Status
    Article number(s)
    Type
    Dimming
    white, 3000 K, 129 lm/W
    DALI-2
    white, 4000 K, 137 lm/W
    DALI-2
