BO 45 base surface 1 lamp

Technical data

General

Ceiling
Surface
tilt max 90°
rotation 350°
special colours
IP20
1140 lm

LED

2700 K
CRI ≥ 90
L80 / 50000 h
initial MacAdam ≤ 2 SDCM
R_g: 97
R_f: 91
R_{1-15}: 87
MR 0.52
MDER 0.47

Optical

spot
beam angle 12°
$P_{st}^{LM}$ ≤ 1.0¹ ² ³ ⁴
SVM ≤ 0.4¹ ² ³ ⁴

Electrical

DALI-2
220-240 V
system 15.0 W
system 76 lm/W ⁵
PC1
1 DALI Addr.

Physical

length 180 mm
width 55 mm
height 163 mm
0.5 kg

Circuit Breaker Types

Automatic Circuit Breaker Type

B10

B13

B16

B20

B25

C10

C13

C16

C20

C25

Number of Fixtures

104

130

^¹ soft lens BO 45 007-1965980 ^² wallwasher lens BO 45 007-1965780 ^³ oval lens BO 45 007-1965880 ^⁴ Value of containing product at full load (undimmed) ^⁵ incl. consideration of optical losses, internal control unit losses & operating device efficiency

Specification text

Surface mounted spotlight made of aluminium; 1 lamp; cylindrical spotlight head; surface special colours powder coated; 350° rotatable and 90° tiltable; surface mounted housing in aluminium incl. converter; mounting plate with pre-assembled converter unit can be pre-mounted; luminaire housing can be attached without tools by interlock; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 2700 K; binning initial MacAdam ≤ 2 SDCM; CRI ≥ 90; min. 80% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; high quality, aluminium, vapour deposition coated reflector with faceted lens design; precise radiation characteristic with 12° beam; good glare control through recessed light point level; optical attachment available as accessory; accessories are listed separately; degree of protection IP20; PC1; 220-240 V; incl. DALI-2 converter; flicker-free visual comfort through analogue current control (minimum value 1%); luminaire for through wiring; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
