BO 32 surface

Technical data

General

Ceiling
Surface
tilt max 90°
rotation 350°
jet black
RAL 9005
IP20
788 lm

LED

2700 K
CRI ≥ 90
L80 / 50000 h
initial MacAdam ≤ 2 SDCM
R_g: 97
R_f: 91
R_{1-15}: 87
MR 0.52
MDER 0.47

Optical

spot
beam angle 18°
$P_{st}^{LM}$ ≤ 1.0¹ ² ³ ⁴
SVM ≤ 0.4¹ ² ³ ⁴

Electrical

DALI-2
220-240 V
system 11.6 W
fixture 8.7 W
fixture 91 lm/W ⁵
250 mA
36 Vf
PC2
1 DALI Addr.

Physical

diameter 32 mm
height 145 mm
0.39 kg

Circuit Breaker Types

Automatic Circuit Breaker Type

B10

B13

B16

B20

C10

C13

C16

C20

Number of Fixtures

104

130

162

135

175

220

270

^¹ wallwasher lens BO 32 007-1965760 ^² soft lens BO 32 007-1965960 ^³ oval lens BO 32 007-1965860 ^⁴ Value of containing product at full load (undimmed) ^⁵ incl. consideration of optical losses & internal control unit losses

Specification text

Cylindrical spotlight in aluminium; surface jet black powder coated; 350° rotatable and 90° tiltable; with surface mounted housing; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 2700 K; binning initial MacAdam ≤ 2 SDCM; CRI ≥ 90; min. 80% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; high quality, aluminium, vapour deposition coated reflector with faceted lens design; precise radiation characteristic with 18° beam; good glare control through recessed light point level; optical attachment available as accessory; accessories are listed separately; degree of protection IP20; PC2; 220-240 V; incl. DALI-2 converter; flicker-free visual comfort through analogue current control (minimum value 1%); external converter for ceiling insertion, through-wiring suitable; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
