TILA 22 adjustable MOVE IT 10

TILA 22 adjustable

MOVE IT 10

030-6530539S

Quickinfo

3000 K
CRI ≥ 90 / 3 SDCM
61 lm/W
L80 / 50000 h
DALI-2
IP20 / PC3 / 48 V

Colour

General

  • Ceiling / Wall
  • Track
  • tilt max 135°
  • rotation 365°
  • rose gold
  • IP20
  • 313 lm
  • optical inset 61 lm/W 1

LED

  • 3000 K
  • CRI ≥ 90
  • L80 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • Rg: 100
  • Rf: 91
  • R{1-15}: 89
  • MR 0.59
  • MDER 0.53

Optical

  • spot
  • beam angle 15°
  • PstLM ≤ 1.0 2
  • SVM ≤ 0.4 2

Electrical

  • DALI-2
  • 48 V
  • fixture 5.7 W
  • optical inset 5.1 W
  • PC3
  • 1 DALI Addr.

Physical

  • diameter 22 mm
  • height 100 mm
  • 0.23 kg
1 incl. consideration of optical losses 2 Value of containing product at full load (undimmed)

Decorative spotlight inset made of aluminium; surface anodised rose gold; 365° rotatable and 135° tiltable; light inset can be installed and moved without tools by means of clip mount; power supplied via MOVE IT system track profile; hot plug protection; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 80% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; good glare control through recessed light point level; high quality reflector; precise radiation characteristic with 15° beam; no multiple shadows; optical attachment available as accessory; accessories are listed separately; degree of protection IP20; PC3; 48 V; DALI-2 control; flicker-free visual comfort through analogue current control (minimum value 1%); light source replaceable by an authorized professional;

Product data & specification documents

Datasheets

Planing files & lighting data

Download all

Accessories

Optical

article number
colour
dimensions
HONEYCOMB LOUVER
007-1965118
jet black
RAL 9005
diameter 20 mm
height 3 mm
0.02 kg

Mounting

article number
colour
dimensions
HOOK surface
030-1000017
traffic white
RAL 9016
diameter 16 mm
height 30 mm
3 kg
HOOK surface
030-1000018
jet black
RAL 9005
diameter 16 mm
height 30 mm
0.03 kg

System products

MOVE IT 10

trimless system

MOVE IT 10

surface system

MOVE IT 10

square / round suspended system

MOVE IT 10

square / round pole system
