TILA 16 adjustable MOVE IT 10

TILA 16 adjustable

MOVE IT 10

030-6500538M

Quickinfo

3000 K
CRI ≥ 90 / 3 SDCM
71 lm/W
L85 / 50000 h
DALI-2
IP20 / PC3 / 48 V

Colour

General

  • Ceiling / Wall
  • Track
  • tilt max 135°
  • rotation 365°
  • jet black
  • RAL 9005 1
  • IP20
  • 187 lm
  • optical inset 71 lm/W 2

LED

  • 3000 K
  • CRI ≥ 90
  • L85 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • Rg: 98
  • Rf: 91
  • R{1-15}: 89
  • MR 0.6
  • MDER 0.55

Optical

  • medium
  • beam angle 23°
  • PstLM ≤ 1.0 3
  • SVM ≤ 0.4 3

Electrical

  • DALI-2
  • 48 V
  • fixture 3.3 W
  • optical inset 2.6 W
  • PC3
  • 1 DALI Addr.

Physical

  • diameter 16 mm
  • height 80 mm
  • 0.12 kg
1 RAL code 2 incl. consideration of optical losses 3 Value of containing product at full load (undimmed)

Decorative spotlight inset made of aluminium; surface jet black powder coated; 365° rotatable and 135° tiltable; light inset can be installed and moved without tools by means of clip mount; power supplied via MOVE IT system track profile; hot plug protection; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 85% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; good glare control through recessed light point level; high quality reflector; precise radiation characteristic with 23° beam; no multiple shadows; degree of protection IP20; PC3; 48 V; DALI-2 control; flicker-free visual comfort through analogue current control (minimum value 1%); light source replaceable by an authorized professional;

Product data & specification documents

Datasheets

Planing files & lighting data

Download all

Accessories

Mounting

article number
colour
dimensions
HOOK surface
030-1000017
traffic white
RAL 9016
diameter 16 mm
height 30 mm
3 kg
HOOK surface
030-1000018
jet black
RAL 9005
diameter 16 mm
height 30 mm
0.03 kg
