L2 MOVE IT 45

L2

MOVE IT 45

090-9L253AB001

Quickinfo

3000 K
CRI ≥ 90 / 3 SDCM
87 lm/W
L80 / 50000 h
DALI-2
IP20

Colour

Reflector

General

  • Ceiling
  • Track
  • black
  • Reflector chrome
  • RAL9005 1
  • IP20
  • 592 lm

LED

  • 3000 K
  • CRI ≥ 90
  • L80 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • Rg: 100
  • Rf: 92
  • R{1-15}: 91
  • MR 0.64
  • MDER 0.58

Optical

  • wallwasher

Electrical

  • DALI-2
  • 6.8 W
  • PC3 48V
  • 87 lm/W
  • 1 DALI Addr.

Physical

  • length 81 mm
  • width 43 mm
  • height 48 mm
  • 0.14 kg
1 RAL code

Linear light inset made of aluminium; surface anodised black; light inset can be installed and moved without tools by means of magnetic holders+locking; flush with profile system; power supplied via MOVE IT system track profile; hot plug protection; equipped with two wallwasher light elements; asymmetrical light distribution with precise radiation characteristic; high quality reflector with micro-faceted, aluminum-vaporised surface; Reflector chrome; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 80% of luminous flux after 50000 operating hours; energy-efficient high power LEDs with very good colour rendering; degree of protection IP20; PC3 48V; DALI single control; flicker-free visual comfort through analogue current control (minimum value 1%); light source not replaceable;

Product data & specification documents

Datasheets

Planing files & lighting data

Certificates

Download all
lightDistribution
mainDrawing
