VELA 450 direct
surface
073-114153XO
Quickinfo
3000 KCRI ≥ 80 / 3 SDCM
123 lm/W
L90 / 50000 h
DALI-2
Opal
IP40
Colour
General
- Ceiling / Wall
- Surface
- special colours
- IP40
- 2050 lm
LED
- 3000 K
- CRI ≥ 80
- L90 / 50000 h
- initial MacAdam ≤ 3 SDCM
- MR 0.54
- MDER 0.49
Optical
- Opal
- opal (lambertsch)
- ≤ 1.0 1
- SVM ≤ 0.4 1
Electrical
- DALI-2
- 220-240 V
- system 16.7 W
- system 123 lm/W 2
- PC1
- 1 DALI Addr.
Physical
- diameter 450 mm
- height 92 mm
- 3.8 kg
Circuit Breaker Types
Automatic Circuit Breaker Type
Number of Fixtures
Round luminaire housing in aluminium, rolled profile, seamlessly welded; surface special colours powder coated; highly reflective coating for improved efficiency; suitable for wall or ceiling mounting; convenient quick mounting system without tools; completely homogeneously illuminated, satinised PMMA cover; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; luminaire with 2 cable openings and plug-in terminal for through wiring; degree of protection IP40; PC1; 220-240 V; internal wiring in light halogen free; incl. DALI-2 converter; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
