MOVE IN 32 flex round trim | Spotlights & Downlights

Technical data

General

Ceiling
Semi-Recessed
tilt max 90°
rotation 360°
traffic white
Mounting set traffic white
RAL 9016
IP20
783 lm

LED

2700 K
CRI ≥ 90
L80 / 50000 h
initial MacAdam ≤ 2 SDCM
R_g: 97
R_f: 91
R_{1-15}: 87
MR 0.52
MDER 0.47

Optical

flood
beam angle 34°
$P_{st}^{LM}$ ≤ 1.0¹ ² ³ ⁴
SVM ≤ 0.4¹ ² ³ ⁴

Electrical

non DIM
220-240 V
system 11.6 W
fixture 8.7 W
fixture 90 lm/W ⁵
36 Vf
250 mA
PC2

Physical

trim
diameter 65 mm
height 93 mm
0.38 kg

Cutout

diameter 54 mm
min. ceiling thickness 2 mm
max. ceiling thickness 25 mm
recessed depth 110 mm

Circuit Breaker Types

Automatic Circuit Breaker Type

B10

B13

B16

B20

C10

C13

C16

C20

Number of Fixtures

115

^¹ oval lens BO 32 007-1965860 ^² wallwasher lens BO 32 007-1965760 ^³ soft lens BO 32 007-1965960 ^⁴ Value of containing product at full load (undimmed) ^⁵ incl. consideration of optical losses & internal control unit losses

Specification text

Round spotlight element in aluminium; surface traffic white powder coated; installation without tools in mounting set due to patented ball catch system; recessed light with trim traffic white; suitable for ceiling thickness of 2-25 mm; spotlight element height adjustable without tools: flush with the ceiling, or extended 25 mm or 35 mm; 360° rotatable and 90° tiltable; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 2700 K; binning initial MacAdam ≤ 2 SDCM; CRI ≥ 90; min. 80% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; high quality, aluminium, vapour deposition coated reflector with faceted lens design; precise radiation characteristic with 34° beam; good glare control through recessed light point level; optical attachment available as accessory; accessories are listed separately; degree of protection IP20; PC2; 220-240 V; incl. converter, non dimmable; converter wired secondary side; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
