MOVE IT 10 track trimless
Visualisation House
Visualisation House
Visualisation House

MOVE IT 10 track

trimless

030-1113038

Quickinfo

DALI-2
IP20 / PC3 / 48 V

Colour

Datasheet

General

  • Ceiling
  • Recessed
  • jet black
  • RAL 9005 1
  • IP20

Electrical

  • DALI-2
  • 48 V
  • PC3

Physical

  • length 1100 mm
  • width 75 mm
  • height 16 mm
  • 0.72 kg

Cutout

  • length 1104 mm
  • width 36 mm
  • recessed depth 50 mm
1 RAL code

Thin extruded aluminium profile with 16 mm height and 10 mm width groove; for trimless installation in plasterboard ceilings; suitable for wall or ceiling mounting; suitable for ceiling thickness of 12.5 mm; with integrated power track profile for take off of supply voltage and DALI-2 signal; surface anodised jet black; light insets can be installed and moved without tools by means of clip mount; degree of protection IP20; PC3; 48 V; accessories are listed separately;

Product data & specification documents

Download all

Datasheets

Download all

Planing files & lighting data

Download all
Download all
mainDrawing

Accessories

Converter

article number
power
voltage / frequency
protection class
constant voltage
POWER SUPPLY EXTERNAL
002-62133
60 W
min 47 Hz
max 63 Hz
PC21
48 V
POWER SUPPLY EXTERNAL
002-62135
150 W
min 50 Hz
max 60 Hz
PC21
48 V
POWER SUPPLY EXTERNAL
002-62139
250 W
min 50 Hz
max 60 Hz
PC21
48 V
DIN RAIL POWER SUPPLY PRO
005-6220210
480 W
min 50 Hz
max 60 Hz
PC21
DIN RAIL POWER SUPPLY
005-6520210
160 W
min 50 Hz
max 60 Hz
PC21
48 V

Optical

article number
colour
type
dimensions
BLIND COVER
030-1003017
traffic white
RAL 9016
length 1,100 mm
width 12 mm
height 10 mm
0.06 kg
BLIND COVER
030-1003018
jet black
RAL 9005
length 1,100 mm
width 12 mm
height 10 mm
0.05 kg
BLIND COVER
030-1005017
traffic white
RAL 9016
length 2,100 mm
width 12 mm
height 10 mm
0.12 kg
BLIND COVER
030-1005018
jet black
RAL 9005
length 2,100 mm
width 12 mm
height 10 mm
0.15 kg
BLIND COVER
030-1007017
traffic white
RAL 9016
length 3,100 mm
width 12 mm
height 10 mm
0.08 kg
BLIND COVER
030-1007018
jet black
RAL 9005
length 3,100 mm
width 12 mm
height 10 mm
0.38 kg
BLIND COVER
E83600....7
traffic white
RAL 9016
custom cut
width 12 mm
height 10 mm
BLIND COVER
E83600....8
jet black
RAL 9005
custom cut
width 12 mm
height 10 mm

Mounting

article number
colour
dimensions
END CAPS
030-1120018
jet black
RAL 9005
length 33 mm
width 16 mm
height 2 mm
0.03 kg
LINEAR CONNECTOR
030-1134018
jet black
RAL 9005
length 50 mm
width 5 mm
0.01 kg
L CONNECTOR
030-1135018
jet black
RAL 9005
length 479 mm
width 75 mm
0.62 kg
LEVEL CONNECTOR
030-2351118
jet black
RAL 9005
length 141 mm
width 11 mm
height 27 mm
0.02 kg
3-in-1 mounting tool
030-2611000
length 96 mm
width 11 mm
0.04 kg

Electrical mounting

article number
colour
type
dimensions
LINEAR CONNECTOR
030-2101138
jet black
RAL 9005
electrical
length 120 mm
width 10 mm
0.2 kg
L CONNECTOR
030-2111138
jet black
RAL 9005
electrical
length 85 mm
width 10 mm
height 85 mm
0.02 kg
T CONNECTOR
030-2121138
jet black
RAL 9005
electrical
length 160 mm
width 10 mm
height 75 mm
0.02 kg
X CONNECTOR
030-2131138
jet black
RAL 9005
electrical
length 160 mm
width 10 mm
height 160 mm
0.05 kg
FLEX CONNECTOR
030-2141138
jet black
RAL 9005
electrical
length 304 mm
width 10 mm
0.03 kg
LEVEL CONNECTOR
030-2151138
jet black
RAL 9005
electrical
length 141 mm
width 11 mm
height 27 mm
0.3 kg
CONNECTOR CEILING TO WALL
030-2161138
jet black
RAL 9005
electrical
length 84 mm
width 10 mm
0.02 kg

Feeder

article number
colour
dimensions
INTERNAL POWER FEEDER
030-2525038
jet black
RAL 9005
length 115 mm
width 11 mm
height 10 mm
0.15 kg

Electrical components

article number
type
dimensions
WIRELESS TO DALI-2 CONTROL DEVICE
030-2531030
length 150 mm
width 11 mm
height 23 mm
0.02 kg
DALI-2 SELV DEVICE
050-2061130
control unit
length 212 mm
width 37 mm
height 26 mm
0.1 kg

System products

TILA

adjustable MOVE IT 10

NOBA

adjustable MOVE IT 10
