MILA microprismatic ceiling system;MILA opal ceiling system

MILA microprismatic

ceiling system

045-9025138 006-4215010Z

Quickinfo

4000 K
CRI ≥ 90 / 3 SDCM
101 lm/W
L90 / 50000 h
DALI-2
Microprismatic
front IP20

Colour

General

  • Ceiling
  • Suspended
  • black
  • RAL 9005 1
  • 2300 lm/m
  • IP20
  • 3450 lm

LED

  • 4000 K
  • CRI ≥ 90
  • L90 / 50000 h
  • photobio. safety RG 0 - no Risk
  • initial MacAdam ≤ 3 SDCM
  • Rg: 99
  • Rf: 92
  • R{1-15}: 90
  • MR 0.81
  • MDER 0.74

Optical

  • Microprismatic
  • PstLM ≤ 1.0 2
  • SVM ≤ 0.4 2

Electrical

  • DALI-2
  • 34 W
  • PC2 220-240V
  • 101 lm/W
  • 23 W/m

Physical

  • length 1500 mm
  • width 38 mm
  • height 77 mm
  • 5.5 kg

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B16
C10
C16

Number of Fixtures

37
60
37
60
1 RAL code 2 Value of containing product at full load (undimmed)

Luminaire housing made of extruded aluminium profile; angular design; for continuous lighting systems; light-tight end caps in aluminium (available as an accessory); surface black powder coated; suitable for installation in the HAUFE louvre ceiling system; extruded profile for improved thermal management; light colour 4000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; microprismatic PMMA cover; degree of protection IP20; PC2 220-240V; photobiological safety according to IEC 62471 risk group RG 0 - no Risk; incl. DALI-2 converter; converter flexible positionable on the luminaire profile; converter suitable for through-wiring; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;

Product data & specification documents

Datasheets

Planing files & lighting data

Download all
lightDistribution
mainDrawing
