LINEA opal / 1 spot wall system

Technical data

General

Wall
Surface
tilt max 89°
pure white
RAL 9010
IP20
172 lm

LED

3000 K
CRI ≥ 97¹-90²
L95 / 50000 h¹-L85 / 50000 h²
initial MacAdam ≤ 3 SDCM
R_g: 102¹-99²
R_f: 96¹-91²
R_{1-15}: 96¹-89²
MR 0.63¹-0.61²
MDER 0.57¹-0.55²

Optical

flood¹-opal (lambertsch)²
beam angle 30°
$P_{st}^{LM}$ ≤ 1.0¹ ² ³
SVM ≤ 0.4¹ ² ³
High Performance Opal

Electrical

non DIM
220-240 V
system 2.7¹-17.6² W
system 64¹-100² lm/W ⁴
PC1

Physical

length 706 mm
width 40 mm
height 100 mm
spotlight left

Circuit Breaker Types

Automatic Circuit Breaker Type

B10

B13

B16

B20

C10

C13

C16

C20

Number of Fixtures

^¹ Spot ^² Linear ^³ Value of containing product at full load (undimmed) ^⁴ incl. consideration of optical losses, internal control unit losses & operating device efficiency

Specification text

Light fitting and front cover made of extruded aluminium profile; angular design; linear; for lighting systems; no visible screws; surface pure white powder coated; suitable for wall mounting; homogeneous wall or ceiling illumination through uniform direct/indirect light distribution; direct and indirect light component: HPO (High Performance Opal) cover for uniform illumination; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 97; min. 95% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; degree of protection IP20; PC1; 220-240 V; JUST 26 spotlight module 2,6 W / 159 lm / 3000 K left; incl. converter, non dimmable; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
