MINO 40 mid lumen
surface
042-1112038H
Quickinfo
3000 KCRI ≥ 90 / 3 SDCM
1,360 lm/m
112 lm/W
L90 / 50000 h
DALI-2
High Performance Opal
IP20
Colour
General
- Ceiling
- Surface
- jet black
- RAL 9005
- IP20
- 1360 lm
- 1360 lm/m
LED
- 3000 K
- CRI ≥ 90
- L90 / 50000 h
- initial MacAdam ≤ 3 SDCM
- Rg: 99
- Rf: 91
- R{1-15}: 89
- MR 0.61
- MDER 0.55
Optical
- High Performance Opal
- opal (lambertsch)
- ≤ 1.0 1
- SVM ≤ 0.4 1
Electrical
- DALI-2
- 220-240 V
- system 12.1 W
- system 112 lm/W 2
- PC1
- 1 DALI Addr.
- 12 W/m
Physical
- length 1008 mm
- width 40 mm
- height 65 mm
- 1.75 kg
Circuit Breaker Types
Automatic Circuit Breaker Type
Number of Fixtures
Luminaire housing made of extruded aluminium profile; light tight final end caps made of aluminium; no visible screws; angular design; surface jet black powder coated; suitable for ceiling mounting; luminaire profile can be pre-mounted; remaining lamp components mounted without tools; LED light inset consisting of highly reflective lacquered aluminium for improved thermal management; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; HPO (High Performance Opal) cover for uniform illumination; degree of protection IP20; PC1; 220-240 V; internal wiring in light halogen free; incl. DALI-2 converter; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
