Variety
SASSO recessed colours
Ball catch system

SASSO 60 square

recessed 1 lamp

New colour temperature Efficiency upgrade

Quickinfo

2700 K, 3000 K, 3500 K, 4000 K
CRI ≥ 90 / 2 SDCM, 3 SDCM
UGR ≤ 13, UGR ≤ 16, UGR ≤ 19
up to 124 lm/W
L80 / 50000 h, L85 / 50000 h, L90 / 50000 h
DALI-2, non DIM
front IP20, IP44, back IP20

Colour

    • Mounting set

    • Products and codes
    Discover family

    Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    Download all
    • 3DS
    • DWG - 3D
    • Revit BIM data
    • EPD

    Description

    Square recessed spotlight; installation without tools in mounting set (trimless or with trim) with ball catch system; surface lacquered; installation possible in different housings; choice of fixed symmetric or asymmetric radiation characteristic; variants with symmetric radiation characteristic: precise radiation characteristic due to high quality lens system; variants with asymmetric radiation characteristic: high-quality reflector with micro-faceted, aluminum-vaporised surface; COB (Chip on Board) technology for maximum efficiency (DOWNLIGHT); no multiple shadows; efficient LEDs with very good colour rendering

    wallwasher and wallwasher floor inset

    glare control (UGR ≤ 16)

    60 mm recessed depth

    Colour Warm Dimming 1800 – 3000 K

    CRI ≥ 95 2 SDCM (optional)

    Products and codes

    Filter
    67
    lm/W
    124
    lm/W
    542
    lm
    1160
    lm
    9.5
    W
    12.8
    W
    8.1
    W
    10.9
    W
    0.51
    0.82
    0.46
    0.74

    Colour

    • Mounting set

    • SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    black, Mounting set jet black, 40° flood, 3000 K, fixture 10.6 W, 86 lm/W
    non DIM
    black, Mounting set jet black, 40° flood, 3000 K, fixture 10.6 W, 86 lm/W
    DALI-2
    black, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 95 lm/W
    non DIM
    black, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 95 lm/W
    DALI-2
    black, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 79 lm/W
    non DIM
    black, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 79 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 3000 K, fixture 10.6 W, 93 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 3000 K, fixture 10.6 W, 93 lm/W
    DALI-2
    black, Mounting set jet black, 40° flood, 4000 K, fixture 10.6 W, 90 lm/W
    non DIM
    black, Mounting set jet black, 40° flood, 4000 K, fixture 10.6 W, 90 lm/W
    DALI-2
    black, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 99 lm/W
    non DIM
    black, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 99 lm/W
    DALI-2
    black, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 83 lm/W
    non DIM
    black, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 83 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 4000 K, fixture 10.6 W, 97 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 4000 K, fixture 10.6 W, 97 lm/W
    DALI-2
    black, Mounting set jet black, 40° flood, 3500 K, fixture 10.6 W, 88 lm/W
    non DIM
    black, Mounting set jet black, 40° flood, 3500 K, fixture 10.6 W, 88 lm/W
    DALI-2
    black, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 97 lm/W
    non DIM
    black, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 97 lm/W
    DALI-2
    black, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 81 lm/W
    non DIM
    black, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 81 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 3500 K, fixture 10.6 W, 95 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 3500 K, fixture 10.6 W, 95 lm/W
    DALI-2
    black, Mounting set jet black, 40° flood, 2700 K, fixture 10.6 W, 83 lm/W
    non DIM
    black, Mounting set jet black, 40° flood, 2700 K, fixture 10.6 W, 83 lm/W
    DALI-2
    black, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 91 lm/W
    non DIM
    black, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 91 lm/W
    DALI-2
    black, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 77 lm/W
    non DIM
    black, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 77 lm/W
    DALI-2
    black, Mounting set jet black, 57° wide flood, 2700 K, fixture 10.6 W, 90 lm/W
    non DIM
    black, Mounting set jet black, 57° wide flood, 2700 K, fixture 10.6 W, 90 lm/W
    DALI-2
    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    gold, Mounting set jet black, 41° flood, 3000 K, fixture 10.6 W, 92 lm/W
    non DIM
    gold, Mounting set jet black, 41° flood, 3000 K, fixture 10.6 W, 92 lm/W
    DALI-2
    gold, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 99 lm/W
    non DIM
    gold, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 99 lm/W
    DALI-2
    gold, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 82 lm/W
    non DIM
    gold, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 82 lm/W
    DALI-2
    gold, Mounting set jet black, 57° wide flood, 3000 K, fixture 10.6 W, 98 lm/W
    non DIM
    gold, Mounting set jet black, 57° wide flood, 3000 K, fixture 10.6 W, 98 lm/W
    DALI-2
    gold, Mounting set jet black, 41° flood, 4000 K, fixture 10.6 W, 96 lm/W
    non DIM
    gold, Mounting set jet black, 41° flood, 4000 K, fixture 10.6 W, 96 lm/W
    DALI-2
    gold, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 103 lm/W
    non DIM
    gold, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 103 lm/W
    DALI-2
    gold, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 86 lm/W
    non DIM
    gold, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 86 lm/W
    DALI-2
    gold, Mounting set jet black, 57° wide flood, 4000 K, fixture 10.6 W, 102 lm/W
    non DIM
    gold, Mounting set jet black, 57° wide flood, 4000 K, fixture 10.6 W, 102 lm/W
    DALI-2
    gold, Mounting set jet black, 41° flood, 3500 K, fixture 10.6 W, 94 lm/W
    non DIM
    gold, Mounting set jet black, 41° flood, 3500 K, fixture 10.6 W, 94 lm/W
    DALI-2
    gold, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 101 lm/W
    non DIM
    gold, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 101 lm/W
    DALI-2
    gold, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 84 lm/W
    non DIM
    gold, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 84 lm/W
    DALI-2
    gold, Mounting set jet black, 57° wide flood, 3500 K, fixture 10.6 W, 100 lm/W
    non DIM
    gold, Mounting set jet black, 57° wide flood, 3500 K, fixture 10.6 W, 100 lm/W
    DALI-2
    gold, Mounting set jet black, 41° flood, 2700 K, fixture 10.6 W, 89 lm/W
    non DIM
    gold, Mounting set jet black, 41° flood, 2700 K, fixture 10.6 W, 89 lm/W
    DALI-2
    gold, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 95 lm/W
    non DIM
    gold, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 95 lm/W
    DALI-2
    gold, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 79 lm/W
    non DIM
    gold, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 79 lm/W
    DALI-2
    gold, Mounting set jet black, 57° wide flood, 2700 K, fixture 10.6 W, 95 lm/W
    non DIM
    gold, Mounting set jet black, 57° wide flood, 2700 K, fixture 10.6 W, 95 lm/W
    DALI-2
    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    matt silver, Mounting set jet black, 42° flood, 3000 K, fixture 10.6 W, 100 lm/W
    non DIM
    matt silver, Mounting set jet black, 42° flood, 3000 K, fixture 10.6 W, 100 lm/W
    DALI-2
    matt silver, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 104 lm/W
    non DIM
    matt silver, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 104 lm/W
    DALI-2
    matt silver, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 85 lm/W
    non DIM
    matt silver, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 85 lm/W
    DALI-2
    matt silver, Mounting set jet black, 58° wide flood, 3000 K, fixture 10.6 W, 104 lm/W
    non DIM
    matt silver, Mounting set jet black, 58° wide flood, 3000 K, fixture 10.6 W, 104 lm/W
    DALI-2
    matt silver, Mounting set jet black, 42° flood, 4000 K, fixture 10.6 W, 104 lm/W
    non DIM
    matt silver, Mounting set jet black, 42° flood, 4000 K, fixture 10.6 W, 104 lm/W
    DALI-2
    matt silver, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 109 lm/W
    non DIM
    matt silver, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 109 lm/W
    DALI-2
    matt silver, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 90 lm/W
    non DIM
    matt silver, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 90 lm/W
    DALI-2
    matt silver, Mounting set jet black, 58° wide flood, 4000 K, fixture 10.6 W, 109 lm/W
    non DIM
    matt silver, Mounting set jet black, 58° wide flood, 4000 K, fixture 10.6 W, 109 lm/W
    DALI-2
    matt silver, Mounting set jet black, 42° flood, 3500 K, fixture 10.6 W, 102 lm/W
    non DIM
    matt silver, Mounting set jet black, 42° flood, 3500 K, fixture 10.6 W, 102 lm/W
    DALI-2
    matt silver, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 106 lm/W
    non DIM
    matt silver, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 106 lm/W
    DALI-2
    matt silver, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 87 lm/W
    non DIM
    matt silver, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 87 lm/W
    DALI-2
    matt silver, Mounting set jet black, 58° wide flood, 3500 K, fixture 10.6 W, 107 lm/W
    non DIM
    matt silver, Mounting set jet black, 58° wide flood, 3500 K, fixture 10.6 W, 107 lm/W
    DALI-2
    matt silver, Mounting set jet black, 42° flood, 2700 K, fixture 10.6 W, 96 lm/W
    non DIM
    matt silver, Mounting set jet black, 42° flood, 2700 K, fixture 10.6 W, 96 lm/W
    DALI-2
    matt silver, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 100 lm/W
    non DIM
    matt silver, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 100 lm/W
    DALI-2
    matt silver, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 83 lm/W
    non DIM
    matt silver, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 83 lm/W
    DALI-2
    matt silver, Mounting set jet black, 58° wide flood, 2700 K, fixture 10.6 W, 101 lm/W
    non DIM
    matt silver, Mounting set jet black, 58° wide flood, 2700 K, fixture 10.6 W, 101 lm/W
    DALI-2
    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    white, Mounting set jet black, 41° flood, 3000 K, fixture 10.6 W, 98 lm/W
    non DIM
    white, Mounting set jet black, 41° flood, 3000 K, fixture 10.6 W, 98 lm/W
    DALI-2
    white, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 103 lm/W
    non DIM
    white, Mounting set jet black, 27° medium, 3000 K, fixture 10.6 W, 103 lm/W
    DALI-2
    white, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 84 lm/W
    non DIM
    white, Mounting set jet black, 15° spot, 3000 K, fixture 10.9 W, 84 lm/W
    DALI-2
    white, Mounting set jet black, 57° wide flood, 3000 K, fixture 10.6 W, 102 lm/W
    non DIM
    white, Mounting set jet black, 57° wide flood, 3000 K, fixture 10.6 W, 102 lm/W
    DALI-2
    white, Mounting set jet black, 41° flood, 4000 K, fixture 10.6 W, 102 lm/W
    non DIM
    white, Mounting set jet black, 41° flood, 4000 K, fixture 10.6 W, 102 lm/W
    DALI-2
    white, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 107 lm/W
    non DIM
    white, Mounting set jet black, 27° medium, 4000 K, fixture 10.6 W, 107 lm/W
    DALI-2
    white, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 89 lm/W
    non DIM
    white, Mounting set jet black, 15° spot, 4000 K, fixture 10.9 W, 89 lm/W
    DALI-2
    white, Mounting set jet black, 57° wide flood, 4000 K, fixture 10.6 W, 107 lm/W
    non DIM
    white, Mounting set jet black, 57° wide flood, 4000 K, fixture 10.6 W, 107 lm/W
    DALI-2
    white, Mounting set jet black, 41° flood, 3500 K, fixture 10.6 W, 100 lm/W
    non DIM
    white, Mounting set jet black, 41° flood, 3500 K, fixture 10.6 W, 100 lm/W
    DALI-2
    white, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 105 lm/W
    non DIM
    white, Mounting set jet black, 27° medium, 3500 K, fixture 10.6 W, 105 lm/W
    DALI-2
    white, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 86 lm/W
    non DIM
    white, Mounting set jet black, 15° spot, 3500 K, fixture 10.9 W, 86 lm/W
    DALI-2
    white, Mounting set jet black, 57° wide flood, 3500 K, fixture 10.6 W, 104 lm/W
    non DIM
    white, Mounting set jet black, 57° wide flood, 3500 K, fixture 10.6 W, 104 lm/W
    DALI-2
    white, Mounting set jet black, 41° flood, 2700 K, fixture 10.6 W, 94 lm/W
    non DIM
    white, Mounting set jet black, 41° flood, 2700 K, fixture 10.6 W, 94 lm/W
    DALI-2
    white, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 99 lm/W
    non DIM
    white, Mounting set jet black, 27° medium, 2700 K, fixture 10.6 W, 99 lm/W
    DALI-2
    white, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 81 lm/W
    non DIM
    white, Mounting set jet black, 15° spot, 2700 K, fixture 10.9 W, 81 lm/W
    DALI-2
    white, Mounting set jet black, 57° wide flood, 2700 K, fixture 10.6 W, 98 lm/W
    non DIM
    white, Mounting set jet black, 57° wide flood, 2700 K, fixture 10.6 W, 98 lm/W
    DALI-2
    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    black, Mounting set traffic white, 40° flood, 3000 K, fixture 10.6 W, 86 lm/W
    non DIM
    black, Mounting set traffic white, 40° flood, 3000 K, fixture 10.6 W, 86 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 3000 K, fixture 10.6 W, 95 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 3000 K, fixture 10.6 W, 95 lm/W
    DALI-2
    black, Mounting set traffic white, 15° spot, 3000 K, fixture 10.9 W, 79 lm/W
    non DIM
    black, Mounting set traffic white, 15° spot, 3000 K, fixture 10.9 W, 79 lm/W
    DALI-2
    black, Mounting set traffic white, 57° wide flood, 3000 K, fixture 10.6 W, 93 lm/W
    non DIM
    black, Mounting set traffic white, 57° wide flood, 3000 K, fixture 10.6 W, 93 lm/W
    DALI-2
    black, Mounting set traffic white, 40° flood, 4000 K, fixture 10.6 W, 90 lm/W
    non DIM
    black, Mounting set traffic white, 40° flood, 4000 K, fixture 10.6 W, 90 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 99 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 99 lm/W
    DALI-2
    black, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 83 lm/W
    non DIM
    black, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 83 lm/W
    DALI-2
    black, Mounting set traffic white, 57° wide flood, 4000 K, fixture 10.6 W, 97 lm/W
    non DIM
    black, Mounting set traffic white, 57° wide flood, 4000 K, fixture 10.6 W, 97 lm/W
    DALI-2
    black, Mounting set traffic white, 40° flood, 3500 K, fixture 10.6 W, 88 lm/W
    non DIM
    black, Mounting set traffic white, 40° flood, 3500 K, fixture 10.6 W, 88 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 97 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 97 lm/W
    DALI-2
    black, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 81 lm/W
    non DIM
    black, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 81 lm/W
    DALI-2
    black, Mounting set traffic white, 57° wide flood, 3500 K, fixture 10.6 W, 95 lm/W
    non DIM
    black, Mounting set traffic white, 57° wide flood, 3500 K, fixture 10.6 W, 95 lm/W
    DALI-2
    black, Mounting set traffic white, 40° flood, 2700 K, fixture 10.6 W, 83 lm/W
    non DIM
    black, Mounting set traffic white, 40° flood, 2700 K, fixture 10.6 W, 83 lm/W
    DALI-2
    black, Mounting set traffic white, 27° medium, 2700 K, fixture 10.6 W, 91 lm/W
    non DIM
    black, Mounting set traffic white, 27° medium, 2700 K, fixture 10.6 W, 91 lm/W
    DALI-2
    black, Mounting set traffic white, 15° spot, 2700 K, fixture 10.9 W, 77 lm/W
    non DIM
    black, Mounting set traffic white, 15° spot, 2700 K, fixture 10.9 W, 77 lm/W
    DALI-2
    black, Mounting set traffic white, 57° wide flood, 2700 K, fixture 10.6 W, 90 lm/W
    non DIM
    black, Mounting set traffic white, 57° wide flood, 2700 K, fixture 10.6 W, 90 lm/W
    DALI-2
    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    gold, Mounting set traffic white, 41° flood, 3000 K, fixture 10.6 W, 92 lm/W
    non DIM
    gold, Mounting set traffic white, 41° flood, 3000 K, fixture 10.6 W, 92 lm/W
    DALI-2
    gold, Mounting set traffic white, 27° medium, 3000 K, fixture 10.6 W, 99 lm/W
    non DIM
    gold, Mounting set traffic white, 27° medium, 3000 K, fixture 10.6 W, 99 lm/W
    DALI-2
    gold, Mounting set traffic white, 15° spot, 3000 K, fixture 10.9 W, 82 lm/W
    non DIM
    gold, Mounting set traffic white, 15° spot, 3000 K, fixture 10.9 W, 82 lm/W
    DALI-2
    gold, Mounting set traffic white, 57° wide flood, 3000 K, fixture 10.6 W, 98 lm/W
    non DIM
    gold, Mounting set traffic white, 57° wide flood, 3000 K, fixture 10.6 W, 98 lm/W
    DALI-2
    gold, Mounting set traffic white, 41° flood, 4000 K, fixture 10.6 W, 96 lm/W
    non DIM
    gold, Mounting set traffic white, 41° flood, 4000 K, fixture 10.6 W, 96 lm/W
    DALI-2
    gold, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 103 lm/W
    non DIM
    gold, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 103 lm/W
    DALI-2
    gold, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 86 lm/W
    non DIM
    gold, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 86 lm/W
    DALI-2
    gold, Mounting set traffic white, 57° wide flood, 4000 K, fixture 10.6 W, 102 lm/W
    non DIM
    gold, Mounting set traffic white, 57° wide flood, 4000 K, fixture 10.6 W, 102 lm/W
    DALI-2
    gold, Mounting set traffic white, 41° flood, 3500 K, fixture 10.6 W, 94 lm/W
    non DIM
    gold, Mounting set traffic white, 41° flood, 3500 K, fixture 10.6 W, 94 lm/W
    DALI-2
    gold, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 101 lm/W
    non DIM
    gold, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 101 lm/W
    DALI-2
    gold, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 84 lm/W
    non DIM
    gold, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 84 lm/W
    DALI-2
    gold, Mounting set traffic white, 57° wide flood, 3500 K, fixture 10.6 W, 100 lm/W
    non DIM
    gold, Mounting set traffic white, 57° wide flood, 3500 K, fixture 10.6 W, 100 lm/W
    DALI-2
    gold, Mounting set traffic white, 41° flood, 2700 K, fixture 10.6 W, 89 lm/W
    non DIM
    gold, Mounting set traffic white, 41° flood, 2700 K, fixture 10.6 W, 89 lm/W
    DALI-2
    gold, Mounting set traffic white, 27° medium, 2700 K, fixture 10.6 W, 95 lm/W
    non DIM
    gold, Mounting set traffic white, 27° medium, 2700 K, fixture 10.6 W, 95 lm/W
    DALI-2
    gold, Mounting set traffic white, 15° spot, 2700 K, fixture 10.9 W, 79 lm/W
    non DIM
    gold, Mounting set traffic white, 15° spot, 2700 K, fixture 10.9 W, 79 lm/W
    DALI-2
    gold, Mounting set traffic white, 57° wide flood, 2700 K, fixture 10.6 W, 95 lm/W
    non DIM
    gold, Mounting set traffic white, 57° wide flood, 2700 K, fixture 10.6 W, 95 lm/W
    DALI-2
    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    matt silver, Mounting set traffic white, 42° flood, 3000 K, fixture 10.6 W, 100 lm/W
    non DIM
    matt silver, Mounting set traffic white, 42° flood, 3000 K, fixture 10.6 W, 100 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 27° medium, 3000 K, fixture 10.6 W, 104 lm/W
    non DIM
    matt silver, Mounting set traffic white, 27° medium, 3000 K, fixture 10.6 W, 104 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 15° spot, 3000 K, fixture 10.9 W, 85 lm/W
    non DIM
    matt silver, Mounting set traffic white, 15° spot, 3000 K, fixture 10.9 W, 85 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 58° wide flood, 3000 K, fixture 10.6 W, 104 lm/W
    non DIM
    matt silver, Mounting set traffic white, 58° wide flood, 3000 K, fixture 10.6 W, 104 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 42° flood, 4000 K, fixture 10.6 W, 104 lm/W
    non DIM
    matt silver, Mounting set traffic white, 42° flood, 4000 K, fixture 10.6 W, 104 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 109 lm/W
    non DIM
    matt silver, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 109 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 90 lm/W
    non DIM
    matt silver, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 90 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 58° wide flood, 4000 K, fixture 10.6 W, 109 lm/W
    non DIM
    matt silver, Mounting set traffic white, 58° wide flood, 4000 K, fixture 10.6 W, 109 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 42° flood, 3500 K, fixture 10.6 W, 102 lm/W
    non DIM
    matt silver, Mounting set traffic white, 42° flood, 3500 K, fixture 10.6 W, 102 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 106 lm/W
    non DIM
    matt silver, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 106 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 87 lm/W
    non DIM
    matt silver, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 87 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 58° wide flood, 3500 K, fixture 10.6 W, 107 lm/W
    non DIM
    matt silver, Mounting set traffic white, 58° wide flood, 3500 K, fixture 10.6 W, 107 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 42° flood, 2700 K, fixture 10.6 W, 96 lm/W
    non DIM
    matt silver, Mounting set traffic white, 42° flood, 2700 K, fixture 10.6 W, 96 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 27° medium, 2700 K, fixture 10.6 W, 100 lm/W
    non DIM
    matt silver, Mounting set traffic white, 27° medium, 2700 K, fixture 10.6 W, 100 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 15° spot, 2700 K, fixture 10.9 W, 83 lm/W
    non DIM
    matt silver, Mounting set traffic white, 15° spot, 2700 K, fixture 10.9 W, 83 lm/W
    DALI-2
    matt silver, Mounting set traffic white, 58° wide flood, 2700 K, fixture 10.6 W, 101 lm/W
    non DIM
    matt silver, Mounting set traffic white, 58° wide flood, 2700 K, fixture 10.6 W, 101 lm/W
    DALI-2
    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    SASSO 60 square downlight trim

    Status
    Article number(s)
    Type
    Dimming
    white, Mounting set traffic white, 41° flood, 3000 K, fixture 10.6 W, 98 lm/W
    non DIM
    white, Mounting set traffic white, 41° flood, 3000 K, fixture 10.6 W, 98 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 3000 K, fixture 10.6 W, 103 lm/W
    non DIM
    white, Mounting set traffic white, 15° spot, 3000 K, fixture 10.9 W, 84 lm/W
    non DIM
    white, Mounting set traffic white, 57° wide flood, 3000 K, fixture 10.6 W, 102 lm/W
    non DIM
    white, Mounting set traffic white, 57° wide flood, 3000 K, fixture 10.6 W, 102 lm/W
    DALI-2
    white, Mounting set traffic white, 41° flood, 4000 K, fixture 10.6 W, 102 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 107 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 4000 K, fixture 10.6 W, 107 lm/W
    DALI-2
    white, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 89 lm/W
    non DIM
    white, Mounting set traffic white, 15° spot, 4000 K, fixture 10.9 W, 89 lm/W
    DALI-2
    white, Mounting set traffic white, 57° wide flood, 4000 K, fixture 10.6 W, 107 lm/W
    non DIM
    white, Mounting set traffic white, 57° wide flood, 4000 K, fixture 10.6 W, 107 lm/W
    DALI-2
    white, Mounting set traffic white, 41° flood, 3500 K, fixture 10.6 W, 100 lm/W
    non DIM
    white, Mounting set traffic white, 41° flood, 3500 K, fixture 10.6 W, 100 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 105 lm/W
    non DIM
    white, Mounting set traffic white, 27° medium, 3500 K, fixture 10.6 W, 105 lm/W
    DALI-2
    white, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 86 lm/W
    non DIM
    white, Mounting set traffic white, 15° spot, 3500 K, fixture 10.9 W, 86 lm/W
    DALI-2
    white, Mounting set traffic white, 57° wide flood, 3500 K, fixture 10.6 W, 104 lm/W
    non DIM
    white, Mounting set traffic white, 57° wide flood, 3500 K, fixture 10.6 W, 104 lm/W
    DALI-2
    white, Mounting set traffic white, 41° flood, 2700 K, fixture 10.6 W, 94 lm/W
    non DIM
    white, Mounting set traffic white, 41° flood, 2700 K, fixture 10.6 W, 94 lm/W
    DALI-2
    white, Mounting set traffic white, 27° medium, 2700 K, fixture 10.6 W, 99 lm/W
    non DIM
    white, Mounting set traffic white, 15° spot, 2700 K, fixture 10.9 W, 81 lm/W
    non DIM
    white, Mounting set traffic white, 57° wide flood, 2700 K, fixture 10.6 W, 98 lm/W
    non DIM

    Accessories

    Converter

    article number
    power
    voltage / frequency
    protection class
    constant current
    control
    POWER SUPPLY
    002-90742
    10 W
    min 50 Hz
    max 60 Hz
    PC21
    250 mA
    POWER SUPPLY
    002-90748
    250 mA
    POWER SUPPLY
    002-90771
    13 W
    min 50 Hz
    max 60 Hz
    PC21
    300 mA
    non DIM
    POWER SUPPLY
    002-90790

    Mounting

    article number
    colour
    dimensions
    cut out dimensions
    MOUNTING SET trimless
    048-2697117
    traffic white
    RAL 9016
    length 72 mm
    width 72 mm
    height 29 mm
    0.07 kg
    length 73 mm
    width 73 mm
    MOUNTING SET with trim 1 lamp
    048-2697317
    traffic white
    RAL 9016
    length 80 mm
    width 80 mm
    height 21 mm
    0.08 kg
    length 73 mm
    width 73 mm
    MOUNTING SET with trim 1 lamp
    048-2697318
    jet black
    RAL 9005
    length 80 mm
    width 80 mm
    height 21 mm
    0.68 kg
    length 73 mm
    width 73 mm
    MOUNTING SET with trim 1 lamp
    048-269731G
    white aluminium
    RAL 9006
    length 80 mm
    width 80 mm
    height 21 mm
    0.12 kg
    length 73 mm
    width 73 mm

    Converter

    article number
    power
    voltage / frequency
    protection class
    constant voltage
    constant current
    control
    POWER SUPPLY PREWIRED
    002-90742A
    250 mA
    non DIM
    POWER SUPPLY
    002-90747
    250 mA
    POWER SUPPLY PREWIRED
    002-90748A
    250 mA
    DALI-2
    POWER SUPPLY
    002-90770
    300 mA
    POWER SUPPLY PREWIRED
    002-90771A
    300 mA
    non DIM
    POWER SUPPLY PREWIRED
    002-90790A
    300 mA
    DALI-2
    DIN RAIL LED DRIVER
    005-6121030
    DALI-2
    DIN RAIL POWER SUPPLY
    005-6520210
    160 W
    min 50 Hz
    max 60 Hz
    PC21
    48 V

    Electrical components

    article number
    type
    dimensions
    THROUGH WIRING CONNECTION BOX
    005-2531110
    non DIM cable ø 4 – 12 mm, Linect®-Ready
    length 105 mm
    width 58 mm
    height 30 mm
    0.06 kg
    THROUGH WIRING CONNECTION BOX
    005-2551110
    DALI cable ø 4 – 12 mm, Linect®-Ready
    length 105 mm
    width 58 mm
    height 30 mm
    0.07 kg

    Mounting

    article number
    colour
    dimensions
    PRIMED CONCRETE MOUNTING HOUSING
    048-2695110
    white aluminium
    RAL 9006
    length 614 mm
    width 307 mm
    height 120 mm
    0.17 kg

    Related products

    New Version

    SASSO 40

    round recessed 1 lamp
    New Version

    SASSO 40

    round recessed 2 lamps
    New Version

    SASSO 60

    round recessed 1 lamp
    New Version

    SASSO 60

    round recessed 2 lamps

    SASSO 60

    round sensor / emergency
    New Version

    SASSO 100

    round adjustable recessed 1 lamp
    New Version

    SASSO 100

    round downlight recessed 1 lamp

    SASSO 100

    round wallwasher recessed 1 lamp
    New Version

    SASSO 100

    round wallwasher/floor recessed 1 lamp
    New Version

    SASSO 100

    round recessed 2 lamps
