MOVE IT 10 track round suspended / pole
Showroom Gartner Interiors
Showroom Gartner Interiors
Showroom Gartner Interiors
Visualisation Retail
Private Residence Styria

MOVE IT 10 track round suspended /

pole

030-1415038

Quickinfo

DALI-2
IP20 / PC3 / 48 V

Colour

Datasheet

General

  • Ceiling
  • Track Suspended
  • jet black
  • RAL 9005
  • IP20

Electrical

  • DALI-2
  • 48 V
  • PC3

Physical

  • length 2100 mm
  • width 29 mm
  • height 26 mm
  • 1.13 kg

Thin extruded aluminium profile with 26 mm height and 10 mm width groove; tubular design; for vertical, horizontal or suspended mounting (1500 mm cable suspension as an accessory); height adjustment without tools; surface anodised jet black; with integrated power track profile on both sides for take off of supply voltage and DALI-2 signal; power supply and DALI-2 signal for both power tracks with only one feed by means of PASS THROUGH connector (as an accessory); light insets can be installed and moved without tools by means of clip mount; degree of protection IP20; PC3; 48 V; accessories are listed separately;

Product data & specification documents

Download all

Datasheets

Download all

Planing files & lighting data

Download all

Certificates

Download all
Download all
mainDrawing

System products

TILA

adjustable MOVE IT 10

TARO

MOVE IT 10

NOBA

adjustable MOVE IT 10

Accessories

Converter

article number
power
voltage / frequency
protection class
constant voltage
POWER SUPPLY external
002-62133
60 W
min 47 Hz
max 63 Hz
PC2
48 V
POWER SUPPLY external
002-62135
150 W
min 50 Hz
max 60 Hz
PC2
48 V
POWER SUPPLY external
002-62139
250 W
min 50 Hz
max 60 Hz
PC2
48 V
DIN RAIL POWER SUPPLY PRO
005-6220110
240 W
min 50 Hz
max 60 Hz
PC2
DIN RAIL POWER SUPPLY PRO
005-6220210
480 W
min 50 Hz
max 60 Hz
PC2
DIN RAIL POWER SUPPLY BASIC
005-6520210
160 W
min 50 Hz
max 60 Hz
PC2
48 V

Electrical components

article number
type
dimensions
colour
CANOPY square
005-2311717
length 90 mm
width 90 mm
height 22 mm
0.1 kg
traffic white
RAL 9016
CANOPY square
005-2311718
length 90 mm
width 90 mm
height 22 mm
0.1 kg
jet black
RAL 9005
CANOPY round
005-2600737
diameter 90 mm
height 22 mm
0.08 kg
traffic white
RAL 9016
CANOPY round
005-2600738
diameter 90 mm
height 22 mm
0.08 kg
jet black
RAL 9005
DIN RAIL DALI-2 SELV DEVICE
005-6620030
length 107 mm
width 37 mm
height 58 mm
WIRELESS TO DALI-2 CONTROL DEVICE
030-2531030
length 150 mm
width 11 mm
height 23 mm
0.02 kg
DALI-2 SELV DEVICE
050-2061130
control unit
length 212 mm
width 37 mm
height 26 mm
0.1 kg

Optical

article number
colour
dimensions
BLIND COVER
030-1003017
traffic white
RAL 9016
length 1,100 mm
width 12 mm
height 10 mm
0.06 kg
BLIND COVER
030-1003018
jet black
RAL 9005
length 1,100 mm
width 12 mm
height 10 mm
0.05 kg
BLIND COVER
030-1005017
traffic white
RAL 9016
length 2,100 mm
width 12 mm
height 10 mm
0.12 kg
BLIND COVER
030-1005018
jet black
RAL 9005
length 2,100 mm
width 12 mm
height 10 mm
0.15 kg
BLIND COVER
030-1007017
traffic white
RAL 9016
length 3,100 mm
width 12 mm
height 10 mm
0.08 kg
BLIND COVER
030-1007018
jet black
RAL 9005
length 3,100 mm
width 12 mm
height 10 mm
0.38 kg
BLIND COVER
E83600....7
traffic white
RAL 9016
custom cut
width 12 mm
height 10 mm
BLIND COVER
E83600....8
jet black
RAL 9005
custom cut
width 12 mm
height 10 mm

Mounting

article number
colour
dimensions
cable length
type
END CAPS
030-1420017
traffic white
RAL 9016
length 29 mm
width 26 mm
height 10 mm
0.01 kg
1 pair
END CAPS
030-1420018
jet black
RAL 9005
length 29 mm
width 26 mm
height 10 mm
0.01 kg
1 pair
L CONNECTOR
030-1435017
traffic white
RAL 9016
length 31 mm
width 31 mm
0.2 kg
mechanical
L CONNECTOR
030-1435018
jet black
RAL 9005
length 31 mm
width 31 mm
0.1 kg
mechanical
T CONNECTOR
030-1436017
traffic white
RAL 9016
length 31 mm
width 33 mm
0.2 kg
mechanical
T CONNECTOR
030-1436018
jet black
RAL 9005
length 31 mm
width 33 mm
0.05 kg
mechanical
X CONNECTOR
030-1437017
traffic white
RAL 9016
length 33 mm
width 33 mm
0.2 kg
mechanical
X CONNECTOR
030-1437018
jet black
RAL 9005
length 33 mm
width 33 mm
mechanical
POLE MOUNTING SET
030-1441017
traffic white
RAL 9016
0.2 kg
1 pair | floor to ceiling or wall to wall
POLE MOUNTING SET
030-1441018
jet black
RAL 9005
0.04 kg
1 pair | floor to ceiling or wall to wall
POLE MOUNTING SET
030-1442017
traffic white
RAL 9016
0.44 kg
wall bracket 400 mm incl. end cap | floor to wall
POLE MOUNTING SET
030-1442018
jet black
RAL 9005
0.26 kg
wall bracket 400 mm incl. end cap | floor to wall
MOUNTING SET ceiling
030-1443017
traffic white
RAL 9016
incl. end cap
MOUNTING SET ceiling
030-1443018
jet black
RAL 9005
0.1 kg
incl. end cap
CABLE SUSPENSION LINEAR CONNECTOR
030-2210014
chrome
0.05 kg
CABLE SUSPENSION LINEAR CONNECTOR
030-2210017
traffic white
RAL 9016
0.06 kg
CABLE SUSPENSION LINEAR CONNECTOR
030-2210018
jet black
RAL 9005
0.05 kg
CABLE SUSPENSION LINEAR CONNECTOR electrical
030-2220014
chrome
0.06 kg
CABLE SUSPENSION LINEAR CONNECTOR electrical
030-2220017
traffic white
RAL 9016
0.07 kg
CABLE SUSPENSION LINEAR CONNECTOR electrical
030-2220018
jet black
RAL 9005
0.08 kg
CABLE SUSPENSION
030-2230014
chrome
0.04 kg
CABLE SUSPENSION
030-2230017
traffic white
RAL 9016
0.5 kg
CABLE SUSPENSION
030-2230018
jet black
RAL 9005
0.04 kg
LINEAR CONNECTOR
030-2300018
length 50 mm
width 16 mm
height 13 mm
0.02 kg
mechanical
LEVEL CONNECTOR
030-2351118
jet black
RAL 9005
length 141 mm
width 11 mm
height 27 mm
0.02 kg
mechanical

Electrical mounting

article number
colour
type
dimensions
LINEAR CONNECTOR
030-2101138
jet black
RAL 9005
electrical
length 120 mm
width 10 mm
0.2 kg
L CONNECTOR
030-2111138
jet black
RAL 9005
electrical
length 85 mm
width 10 mm
height 85 mm
0.02 kg
T CONNECTOR
030-2121138
jet black
RAL 9005
electrical
length 160 mm
width 10 mm
height 75 mm
0.02 kg
X CONNECTOR
030-2131138
jet black
RAL 9005
electrical
length 160 mm
width 10 mm
height 160 mm
0.05 kg
FLEX CONNECTOR
030-2141138
jet black
RAL 9005
electrical
length 304 mm
width 10 mm
0.03 kg
LEVEL CONNECTOR
030-2151138
jet black
RAL 9005
electrical
length 141 mm
width 11 mm
height 27 mm
0.3 kg
CONNECTOR ceiling to wall
030-2161138
jet black
RAL 9005
electrical
length 84 mm
width 10 mm
0.02 kg
PASS THROUGH CONNECTOR
030-2171138
jet black
RAL 9005
electrical | 1 pair
length 85 mm
width 21 mm
0.05 kg
LINEAR CONNECTOR
030-2301038
mechanical & electrical
length 140 mm
width 16 mm
height 13 mm
0.04 kg

Feeder

article number
colour
dimensions
feeder cable length
INTERNAL POWER FEEDER
030-2525038
jet black
RAL 9005
length 115 mm
width 11 mm
height 10 mm
0.15 kg
2,000 mm
INTERNAL POWER FEEDER
030-2525138
jet black
RAL 9005
length 115 mm
width 11 mm
height 10 mm
0.38 kg
5,000 mm

accessory.category.mounting tools

article number
dimensions
3-in-1 mounting tool
030-2611000
length 96 mm
width 11 mm
0.04 kg
