TASK S

suspended system

Informazioni rapide

3000 K, 4000 K, tunable white
CRI ≥ 80, CRI ≥ 90 / 3 SDCM
UGR < 19
fino a 8,270 lm/↑ 4,470 lm
fino a 122 lm/W
L85 / 50000 h, L90 / 50000 h
DALI-2, DALI-2 sensor
Microprismatic
front IP20

Colore

  • Disegno semplice

    Distribuzione della luce

    Dati relativi ai prodotti e documenti di specifica

    Download intero
    • ROLF
    • ULD

    Descrizione

    Corpo illuminante in alluminio con bordi arrotondati; diverse varianti: forma rettangolare, angolare oppure a segmento di cerchio; forma ultrapiatta (solo 15 mm); per file continue; verniciatura a polvere; cavo regolabile in altezza senza attrezzi; pratico sistema di montaggio rapido senza utensili; distribuzione della luce diretta o diretta/indiretta con sistema LGP-Body (Light Guiding Prism); luce convogliata lateralmente e direzionata in basso o in basso e e su tramite incisione laser; direzionamento della luce con materiale del riflettore altamente riflettente; in opzione: percentuale indiretta con piastre a flusso luminoso potenziato e massima illuminazione del soffitto; illuminazione assolutamente omogenea; LED ad efficienza energetica con elevata resa cromatica; rosone per cablaggio passante; disponibile accessorio fonoassorbente

    DiiA® standards 251, 252, 253

    DIN EN 12464-1 UGR ≤ 19

    sistema a scatto

    connettore di sistema

    tunable white 2700 – 6500 K

    CRI ≥ 98 XPECTRUM (opzionale)

    System components

    Click to see components

    TASK S CURVE direct suspended system;TASK S CURVE direct / indirect power suspended system;TASK S CURVE direct / indirect soft suspended system

    TASK S curve direct suspended system

    3000 K, 4000 K, tunable white
    CRI ≥ 80, CRI ≥ 90 / 3 SDCM
    UGR < 19
    fino a 8,270 lm/↑ 4,470 lm
    fino a 122 lm/W
    L85 / 50000 h, L90 / 50000 h
    DALI-2, DALI-2 sensor
    Microprismatic
    front IP20
    TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct / indirect power suspended system

    3000 K, 4000 K, tunable white
    CRI ≥ 80, CRI ≥ 90 / 3 SDCM
    UGR < 19
    fino a 8,270 lm/↑ 4,470 lm
    fino a 122 lm/W
    L85 / 50000 h, L90 / 50000 h
    DALI-2, DALI-2 sensor
    Microprismatic
    front IP20

    TASK LINEAR CONNECTOR

    90° | meccanico, 90° | meccanico ed elettrico, meccanico, meccanico ed elettrico

    CABLE SUSPENSION

    Dieser Bereich wird neu geladen sobald ein Eingabefeld geändert wird.

    Prodotti e codici

    Filtro
    103
    lm/W
    122
    lm/W
    1460
    lm
    3110
    lm
    327
    lm
    4470
    lm
    1180
    mm
    2324
    mm
    12.9
    W
    117
    W
    0.61
    1.01
    0.56
    0.92

    Colore

  • TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct / indirect TW power suspended system

    TASK S linear direct / indirect TW power suspended system

    Stato
    N. articolo/i
    Tipo
    Dimming
    bianco, 3000 K, 49 W, 106 lm/W, 1.180 mm
    DALI-2
    bianco, 4000 K, 49 W, 110 lm/W, 1.180 mm
    DALI-2
    bianco, 3000 K, 61 W, 106 lm/W, 1.457 mm
    DALI-2
    bianco, 4000 K, 61 W, 110 lm/W, 1.457 mm
    DALI-2
    bianco, 3000 K, 71 W, 107 lm/W, 1.748 mm
    DALI-2
    bianco, 4000 K, 71 W, 111 lm/W, 1.748 mm
    DALI-2
    bianco, 3000 K, 92 W, 113 lm/W, 2.315 mm
    DALI-2
    bianco, 4000 K, 92 W, 117 lm/W, 2.315 mm
    DALI-2
    TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct / indirect TW power suspended system

    TASK S linear direct / indirect TW power suspended system

    Stato
    N. articolo/i
    Tipo
    Dimming
    nero, 3000 K, 49 W, 106 lm/W, 1.180 mm
    DALI-2
    nero, 4000 K, 49 W, 110 lm/W, 1.180 mm
    DALI-2
    nero, 3000 K, 61 W, 106 lm/W, 1.457 mm
    DALI-2
    nero, 4000 K, 61 W, 110 lm/W, 1.457 mm
    DALI-2
    nero, 3000 K, 71 W, 107 lm/W, 1.748 mm
    DALI-2
    nero, 4000 K, 71 W, 111 lm/W, 1.748 mm
    DALI-2
    nero, 3000 K, 92 W, 113 lm/W, 2.315 mm
    DALI-2
    nero, 4000 K, 92 W, 117 lm/W, 2.315 mm
    DALI-2
    TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct / indirect power suspended system

    TASK S linear direct / indirect power suspended system

    Stato
    N. articolo/i
    Tipo
    Dimming
    bianco, 3000 K, 42 W, 114 lm/W, 1.180 mm
    DALI-2
    bianco, 4000 K, 42 W, 121 lm/W, 1.180 mm
    DALI-2
    bianco, tunable white, 62 W, 103 lm/W, 1.180 mm
    DALI-2
    bianco, 3000 K, 53 W, 113 lm/W, 1.457 mm
    DALI-2
    bianco, 4000 K, 53 W, 120 lm/W, 1.457 mm
    DALI-2
    bianco, tunable white, 77 W, 103 lm/W, 1.457 mm
    DALI-2
    bianco, 3000 K, 63 W, 114 lm/W, 1.748 mm
    DALI-2
    bianco, 4000 K, 63 W, 121 lm/W, 1.748 mm
    DALI-2
    bianco, tunable white, 85 W, 105 lm/W, 1.748 mm
    DALI-2
    bianco, 3000 K, 84 W, 114 lm/W, 2.315 mm
    DALI-2
    bianco, 4000 K, 84 W, 121 lm/W, 2.315 mm
    DALI-2
    bianco, tunable white, 117 W, 109 lm/W, 2.315 mm
    DALI-2
    TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct / indirect power suspended system

    TASK S linear direct / indirect power suspended system

    Stato
    N. articolo/i
    Tipo
    Dimming
    nero, 3000 K, 42 W, 114 lm/W, 1.180 mm
    DALI-2
    nero, 4000 K, 42 W, 121 lm/W, 1.180 mm
    DALI-2
    nero, tunable white, 62 W, 103 lm/W, 1.180 mm
    DALI-2
    nero, 3000 K, 53 W, 113 lm/W, 1.457 mm
    DALI-2
    nero, 4000 K, 53 W, 120 lm/W, 1.457 mm
    DALI-2
    nero, tunable white, 77 W, 103 lm/W, 1.457 mm
    DALI-2
    nero, 3000 K, 63 W, 114 lm/W, 1.748 mm
    DALI-2
    nero, 4000 K, 63 W, 121 lm/W, 1.748 mm
    DALI-2
    nero, tunable white, 85 W, 105 lm/W, 1.748 mm
    DALI-2
    nero, 3000 K, 84 W, 114 lm/W, 2.315 mm
    DALI-2
    nero, 4000 K, 84 W, 121 lm/W, 2.315 mm
    DALI-2
    nero, tunable white, 117 W, 109 lm/W, 2.315 mm
    DALI-2
    TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct / indirect soft suspended system

    TASK S linear direct / indirect soft suspended system

    Stato
    N. articolo/i
    Tipo
    Dimming
    bianco, 3000 K, 19,5 W, 114 lm/W, 1.180 mm
    DALI-2
    bianco, 4000 K, 19,5 W, 122 lm/W, 1.180 mm
    DALI-2
    bianco, 3000 K, 24,4 W, 114 lm/W, 1.457 mm
    DALI-2
    bianco, 4000 K, 24,4 W, 122 lm/W, 1.457 mm
    DALI-2
    bianco, 3000 K, 29,2 W, 115 lm/W, 1.748 mm
    DALI-2
    bianco, 4000 K, 29,2 W, 122 lm/W, 1.748 mm
    DALI-2
    bianco, 3000 K, 39 W, 114 lm/W, 2.315 mm
    DALI-2
    bianco, 4000 K, 39 W, 122 lm/W, 2.315 mm
    DALI-2
    TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct / indirect soft suspended system

    TASK S linear direct / indirect soft suspended system

    Stato
    N. articolo/i
    Tipo
    Dimming
    nero, 3000 K, 19,5 W, 114 lm/W, 1.180 mm
    DALI-2
    nero, 4000 K, 19,5 W, 122 lm/W, 1.180 mm
    DALI-2
    nero, 3000 K, 24,4 W, 114 lm/W, 1.457 mm
    DALI-2
    nero, 4000 K, 24,4 W, 122 lm/W, 1.457 mm
    DALI-2
    nero, 3000 K, 29,2 W, 115 lm/W, 1.748 mm
    DALI-2
    nero, 4000 K, 29,2 W, 122 lm/W, 1.748 mm
    DALI-2
    nero, 3000 K, 39 W, 114 lm/W, 2.315 mm
    DALI-2
    nero, 4000 K, 39 W, 122 lm/W, 2.315 mm
    DALI-2
    TASK S LINEAR direct suspended system;TASK S LINEAR direct / indirect power suspended system;TASK S LINEAR direct / indirect soft suspended system;TASK S LINEAR sensor direct suspended system;TASK S LINEAR sensor direct / indirect power suspended system;TASK S LINEAR sensor direct / indirect soft suspended system;TASK S LINEAR sensor direct / indirect TW power suspended system;TASK S LINEAR direct / indirect TW power suspended system

    TASK S linear direct suspended system

    TASK S linear direct suspended system

    Stato
    N. articolo/i
    Tipo
    Dimming
    bianco, 3000 K, 12,9 W, 113 lm/W, 1.180 mm
    DALI-2
