FRAME 60

trim

Quickinfo

3000 K, 4000 K, tunable white
CRI ≥ 80, 90 / 3 SDCM
UGR ≤ 19
bis zu 125 lm/W
L80 / 50000 h, L85 / 50000 h, L90 / 50000 h
DALI-2, DALI-2 DT8, nicht dimmbar
High Performance Opal, Microprismatic
IP20

Farbe

Weiß

Grau

Produkte und Artikelnummern

Skizze

Lichtverteilung

Downloads & Links

Produktdaten & Ausschreibungsunterlagen

Katalogseite(n)

DWG - 2D

Gesamtdownload

Sammeldownloads

ROLF
ULD

Beschreibung

Leuchtenkörper aus Aluminiumstrangpressprofil; Einbauleuchte mit umlaufendem Rand; geeignet für Deckenstärken von 8-25 mm; Oberfläche pulverbeschichtet; Leuchtenprofil für Montage vorab lieferbar; restliche Leuchtenkomponenten werkzeuglos montierbar; Lichteinsatz bestehend aus hochreflektierend lackiertem Strangpressprofil für verbessertes Thermomanagement; HPO (High Performance Opal) Abdeckung für homogene Ausleuchtung; mikroprismatische PMMA-Abdeckung inkl. Diffusorfolie zur Reduktion der Leuchtdichte bei homogener Ausleuchtung; energieeffiziente LEDs mit sehr guter Farbwiedergabe

DiiA^® standards 251, 252, 253

Systemlösung

mikroprismatisch UGR ≤ 19

tunable white 2700 – 6500 K

CRI ≥ 98 XPECTRUM (optional)

Produkte und Artikelnummern

Filter

Farbe

Weiß

Grau

FRAME 60 high lumen trim

Status

Artikelnummer(n)

Typ

Dimming

Grau, Microprismatic, tunable white, 80, 2.300 lm/m, 21,7 W, 2.010 lm, 93 lm/W, 893 mm

DALI-2 DT8

Grau, High Performance Opal, tunable white, 80, 2.640 lm/m, 21,7 W, 2.300 lm, 106 lm/W, 893 mm

DALI-2 DT8

Grau, Microprismatic, tunable white, 80, 2.300 lm/m, 21,7 W, 2.000 lm, 92 lm/W, 893 mm

DALI-2 DT8

Grau, Microprismatic, tunable white, 80, 2.280 lm/m, 29 W, 2.670 lm, 92 lm/W, 1.193 mm

DALI-2 DT8

Grau, High Performance Opal, tunable white, 80, 2.620 lm/m, 29 W, 3.070 lm, 106 lm/W, 1.193 mm

DALI-2 DT8

Grau, Microprismatic, tunable white, 80, 2.280 lm/m, 29 W, 2.670 lm, 92 lm/W, 1.193 mm

DALI-2 DT8

Grau, Microprismatic, tunable white, 80, 2.270 lm/m, 36 W, 3.340 lm, 93 lm/W, 1.493 mm

DALI-2 DT8

Grau, High Performance Opal, tunable white, 80, 2.610 lm/m, 36 W, 3.840 lm, 107 lm/W, 1.493 mm

DALI-2 DT8

Grau, Microprismatic, tunable white, 80, 2.270 lm/m, 36 W, 3.340 lm, 93 lm/W, 1.493 mm

DALI-2 DT8

Grau, Microprismatic, tunable white, 80, 2.280 lm/m, 58 W, 5.350 lm, 92 lm/W, 2.365 mm

DALI-2 DT8

Grau, High Performance Opal, tunable white, 80, 2.620 lm/m, 58 W, 6.140 lm, 106 lm/W, 2.365 mm

DALI-2 DT8

Grau, Microprismatic, tunable white, 80, 2.280 lm/m, 58 W, 5.340 lm, 92 lm/W, 2.365 mm

DALI-2 DT8

Grau, Microprismatic, 3000 K, 90, 2.090 lm/m, 13,9 W, 1.200 lm, 86 lm/W, 593 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 90, 2.400 lm/m, 13,9 W, 1.370 lm, 99 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.090 lm/m, 13,9 W, 1.190 lm, 86 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.090 lm/m, 13,9 W, 1.200 lm, 86 lm/W, 593 mm

DALI-2

Grau, High Performance Opal, 3000 K, 90, 2.400 lm/m, 13,9 W, 1.370 lm, 99 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 3000 K, 90, 2.090 lm/m, 13,9 W, 1.190 lm, 86 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.160 lm/m, 13,9 W, 1.240 lm, 89 lm/W, 593 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 90, 2.480 lm/m, 13,9 W, 1.420 lm, 102 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.160 lm/m, 13,9 W, 1.230 lm, 88 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.160 lm/m, 13,9 W, 1.240 lm, 89 lm/W, 593 mm

DALI-2

Grau, High Performance Opal, 4000 K, 90, 2.480 lm/m, 13,9 W, 1.420 lm, 102 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.160 lm/m, 13,9 W, 1.230 lm, 88 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.270 lm/m, 13,8 W, 1.300 lm, 94 lm/W, 593 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 80, 2.610 lm/m, 13,8 W, 1.490 lm, 108 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.270 lm/m, 13,8 W, 1.300 lm, 94 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.270 lm/m, 13,8 W, 1.300 lm, 94 lm/W, 593 mm

DALI-2

Grau, High Performance Opal, 3000 K, 80, 2.610 lm/m, 13,8 W, 1.490 lm, 108 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.270 lm/m, 13,8 W, 1.300 lm, 94 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 4000 K, 80, 2.400 lm/m, 13,8 W, 1.370 lm, 99 lm/W, 593 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 80, 2.760 lm/m, 13,8 W, 1.580 lm, 114 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.400 lm/m, 13,8 W, 1.370 lm, 99 lm/W, 593 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.400 lm/m, 13,8 W, 1.370 lm, 99 lm/W, 593 mm

DALI-2

Grau, High Performance Opal, 4000 K, 80, 2.760 lm/m, 13,8 W, 1.580 lm, 114 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 4000 K, 80, 2.400 lm/m, 13,8 W, 1.370 lm, 99 lm/W, 593 mm

DALI-2

Grau, Microprismatic, 3000 K, 90, 2.060 lm/m, 20,8 W, 1.790 lm, 86 lm/W, 893 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 90, 2.370 lm/m, 20,8 W, 2.060 lm, 99 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.060 lm/m, 20,8 W, 1.790 lm, 86 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.060 lm/m, 20,8 W, 1.790 lm, 86 lm/W, 893 mm

DALI-2

Grau, High Performance Opal, 3000 K, 90, 2.370 lm/m, 20,8 W, 2.060 lm, 99 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 3000 K, 90, 2.060 lm/m, 20,8 W, 1.790 lm, 86 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.120 lm/m, 20,8 W, 1.850 lm, 89 lm/W, 893 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 90, 2.440 lm/m, 20,8 W, 2.130 lm, 102 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.120 lm/m, 20,8 W, 1.850 lm, 89 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.120 lm/m, 20,8 W, 1.850 lm, 89 lm/W, 893 mm

DALI-2

Grau, High Performance Opal, 4000 K, 90, 2.440 lm/m, 20,8 W, 2.130 lm, 102 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.120 lm/m, 20,8 W, 1.850 lm, 89 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.230 lm/m, 20,6 W, 1.950 lm, 95 lm/W, 893 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 80, 2.570 lm/m, 20,6 W, 2.240 lm, 109 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.230 lm/m, 20,6 W, 1.940 lm, 94 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.230 lm/m, 20,6 W, 1.950 lm, 95 lm/W, 893 mm

DALI-2

Grau, High Performance Opal, 3000 K, 80, 2.570 lm/m, 20,6 W, 2.240 lm, 109 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.230 lm/m, 20,6 W, 1.940 lm, 94 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 4000 K, 80, 2.360 lm/m, 20,6 W, 2.060 lm, 100 lm/W, 893 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 80, 2.720 lm/m, 20,6 W, 2.370 lm, 115 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.360 lm/m, 20,6 W, 2.060 lm, 100 lm/W, 893 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.360 lm/m, 20,6 W, 2.060 lm, 100 lm/W, 893 mm

DALI-2

Grau, High Performance Opal, 4000 K, 80, 2.720 lm/m, 20,6 W, 2.370 lm, 115 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 4000 K, 80, 2.360 lm/m, 20,6 W, 2.060 lm, 100 lm/W, 893 mm

DALI-2

Grau, Microprismatic, 3000 K, 90, 2.040 lm/m, 27,7 W, 2.390 lm, 86 lm/W, 1.193 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 90, 2.350 lm/m, 27,7 W, 2.750 lm, 99 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.040 lm/m, 27,7 W, 2.390 lm, 86 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.040 lm/m, 27,7 W, 2.390 lm, 86 lm/W, 1.193 mm

DALI-2

Grau, High Performance Opal, 3000 K, 90, 2.350 lm/m, 27,7 W, 2.750 lm, 99 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 3000 K, 90, 2.040 lm/m, 27,7 W, 2.390 lm, 86 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.110 lm/m, 27,7 W, 2.470 lm, 89 lm/W, 1.193 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 90, 2.420 lm/m, 27,7 W, 2.840 lm, 103 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.100 lm/m, 27,7 W, 2.470 lm, 89 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.110 lm/m, 27,7 W, 2.470 lm, 89 lm/W, 1.193 mm

DALI-2

Grau, High Performance Opal, 4000 K, 90, 2.420 lm/m, 27,7 W, 2.840 lm, 103 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.100 lm/m, 27,7 W, 2.470 lm, 89 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.210 lm/m, 27,5 W, 2.600 lm, 95 lm/W, 1.193 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 80, 2.540 lm/m, 27,5 W, 2.980 lm, 108 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.210 lm/m, 27,5 W, 2.590 lm, 94 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.210 lm/m, 27,5 W, 2.600 lm, 95 lm/W, 1.193 mm

DALI-2

Grau, High Performance Opal, 3000 K, 80, 2.540 lm/m, 27,5 W, 2.980 lm, 108 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.210 lm/m, 27,5 W, 2.590 lm, 94 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 4000 K, 80, 2.350 lm/m, 27,5 W, 2.750 lm, 100 lm/W, 1.193 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 80, 2.690 lm/m, 27,5 W, 3.160 lm, 115 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.340 lm/m, 27,5 W, 2.740 lm, 100 lm/W, 1.193 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.350 lm/m, 27,5 W, 2.750 lm, 100 lm/W, 1.193 mm

DALI-2

Grau, High Performance Opal, 4000 K, 80, 2.690 lm/m, 27,5 W, 3.160 lm, 115 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 4000 K, 80, 2.340 lm/m, 27,5 W, 2.740 lm, 100 lm/W, 1.193 mm

DALI-2

Grau, Microprismatic, 3000 K, 90, 2.030 lm/m, 35 W, 2.990 lm, 85 lm/W, 1.493 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 90, 2.340 lm/m, 35 W, 3.440 lm, 98 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.030 lm/m, 35 W, 2.990 lm, 85 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 90, 2.030 lm/m, 35 W, 2.990 lm, 85 lm/W, 1.493 mm

DALI-2

Grau, High Performance Opal, 3000 K, 90, 2.340 lm/m, 35 W, 3.440 lm, 98 lm/W, 1.493 mm

DALI-2

Grau, Microprismatic, 3000 K, 90, 2.030 lm/m, 35 W, 2.990 lm, 85 lm/W, 1.493 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.100 lm/m, 35 W, 3.090 lm, 88 lm/W, 1.493 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 90, 2.410 lm/m, 35 W, 3.550 lm, 101 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.090 lm/m, 35 W, 3.080 lm, 88 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 90, 2.100 lm/m, 35 W, 3.090 lm, 88 lm/W, 1.493 mm

DALI-2

Grau, High Performance Opal, 4000 K, 90, 2.410 lm/m, 35 W, 3.550 lm, 101 lm/W, 1.493 mm

DALI-2

Grau, Microprismatic, 4000 K, 90, 2.090 lm/m, 35 W, 3.080 lm, 88 lm/W, 1.493 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.200 lm/m, 34 W, 3.240 lm, 95 lm/W, 1.493 mm

nicht dimmbar

Grau, High Performance Opal, 3000 K, 80, 2.530 lm/m, 34 W, 3.730 lm, 110 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.200 lm/m, 34 W, 3.240 lm, 95 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 3000 K, 80, 2.200 lm/m, 34 W, 3.240 lm, 95 lm/W, 1.493 mm

DALI-2

Grau, High Performance Opal, 3000 K, 80, 2.530 lm/m, 34 W, 3.730 lm, 110 lm/W, 1.493 mm

DALI-2

Grau, Microprismatic, 3000 K, 80, 2.200 lm/m, 34 W, 3.240 lm, 95 lm/W, 1.493 mm

DALI-2

Grau, Microprismatic, 4000 K, 80, 2.330 lm/m, 34 W, 3.440 lm, 101 lm/W, 1.493 mm

nicht dimmbar

Grau, High Performance Opal, 4000 K, 80, 2.680 lm/m, 34 W, 3.950 lm, 116 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.330 lm/m, 34 W, 3.430 lm, 101 lm/W, 1.493 mm

nicht dimmbar

Grau, Microprismatic, 4000 K, 80, 2.330 lm/m, 34 W, 3.440 lm, 101 lm/W, 1.493 mm

DALI-2

Grau, High Performance Opal, 4000 K, 80, 2.680 lm/m, 34 W, 3.950 lm, 116 lm/W, 1.493 mm

DALI-2
