Infos rapides

1800 K - 2700 K, 2700 K, 3000 K, 4000 K
CRI ≥ 90, 95 / 2, 3, 4 SDCM
UGR ≤ 10, 19
jusqu'à 93 lm/W
L80 / 50000 h, L90 / 50000 h
DALI-2, non DIM
IP20

Couleur

  • Mounting set

  • Dessin simple

    Distribution de la lumière

    Données sur les produits et documents de spécification

    Téléchargement global

    Description

    Spot rond encastrable en fonte d’aluminium injectée ; montage sans outil en kit de montage (sans bord ou avec bord continu) par système à déclic à bille ; surface thermolaquée ; encastrement possible dans différents boîtiers ; module d'éclairage rotatif et orientable ; eléments optiques disponibles comme accessoires ; également possible avec une optique de lentilles de haute qualité présentant des caractéristiques de rayonnement précises ; ou un réflecteur de haute qualité avec une optique sphérique à facettes, caractéristiques de rayonnement précises avec deux angles de rayonnement différents ; Installation resp. remplacement sans outil ; avec technologie COB (Chip on Board) ou High-Power-LED pour efficacité maximale ; pas d'ombres multiples ; LED économes en énergie à restitution de couleur élevée

    DiiA® standards 251, 252, 253

    pivotant à 360°, orientable à 35°

    Colour Warm Dimming 1800 – 2700 K

    Dieser Bereich wird neu geladen sobald ein Eingabefeld geändert wird.

    Produits et codes

    Filtre
    46
    lm/W
    93
    lm/W
    353
    lm
    1130
    lm
    87
    mm
    229
    mm
    83
    mm
    160
    mm
    98
    mm
    98
    mm
    6.5
    W
    12.2
    W
    0.4
    0.71
    0.44
    0.78

    Couleur

  • Mounting set

  • SASSO PRO 80 adjustable flush trim round;SASSO PRO 80 adjustable flush trim round concrete

    SASSO PRO 80 adjustable flush trim round

    SASSO PRO 80 adjustable flush trim round

    Statut
    Numéro(s) article(s)
    Type
    Dimming
    blanc, Noir profond, flood, 37°, 2700 K, 8.3 W
    non DIM
    blanc, Noir profond, medium, 26°, 2700 K, 8.3 W
    non DIM
    blanc, Noir profond, super spot, 8°, 2700 K, 7.7 W
    non DIM
    blanc, Noir profond, flood, 37°, 3000 K, 8.3 W
    non DIM
    blanc, Noir profond, medium, 26°, 3000 K, 8.3 W
    non DIM
    blanc, Noir profond, super spot, 8°, 3000 K, 7.7 W
    non DIM
    blanc, Noir profond, flood, 37°, 4000 K, 8.3 W
    non DIM
    blanc, Noir profond, medium, 26°, 4000 K, 8.3 W
    non DIM
    blanc, Noir profond, super spot, 8°, 4000 K, 7.7 W
    non DIM
    blanc, Noir profond, medium, 26°, 1800 K - 2700 K, 6.5 W
    DALI-2
    blanc, Noir profond, flood, 37°, 2700 K, 12.2 W
    non DIM
    blanc, Noir profond, medium, 26°, 2700 K, 12.2 W
    non DIM
    blanc, Noir profond, flood, 37°, 2700 K, 12.2 W
    DALI-2
    blanc, Noir profond, medium, 26°, 2700 K, 12.2 W
    DALI-2
    blanc, Noir profond, flood, 37°, 3000 K, 12.2 W
    non DIM
    blanc, Noir profond, medium, 26°, 3000 K, 12.2 W
    non DIM
    blanc, Noir profond, flood, 37°, 3000 K, 12.2 W
    DALI-2
    blanc, Noir profond, medium, 26°, 3000 K, 12.2 W
    DALI-2
    blanc, Noir profond, flood, 37°, 4000 K, 12.2 W
    non DIM
    blanc, Noir profond, medium, 26°, 4000 K, 12.2 W
    non DIM
    blanc, Noir profond, flood, 37°, 4000 K, 12.2 W
    DALI-2
    blanc, Noir profond, medium, 26°, 4000 K, 12.2 W
    DALI-2
    SASSO PRO 80 adjustable flush trim round;SASSO PRO 80 adjustable flush trim round concrete

    SASSO PRO 80 adjustable flush trim round

    SASSO PRO 80 adjustable flush trim round

    Statut
    Numéro(s) article(s)
    Type
    Dimming
    noir, Noir profond, flood, 37°, 2700 K, 8.3 W
    non DIM
    noir, Noir profond, medium, 26°, 2700 K, 8.3 W
    non DIM
    noir, Noir profond, super spot, 8°, 2700 K, 7.7 W
    non DIM
    noir, Noir profond, flood, 37°, 3000 K, 8.3 W
    non DIM
    noir, Noir profond, medium, 26°, 3000 K, 8.3 W
    non DIM
    noir, Noir profond, super spot, 8°, 3000 K, 7.7 W
    non DIM
    noir, Noir profond, flood, 37°, 4000 K, 8.3 W
    non DIM
    noir, Noir profond, medium, 26°, 4000 K, 8.3 W
    non DIM
    noir, Noir profond, super spot, 8°, 4000 K, 7.7 W
    non DIM
    noir, Noir profond, medium, 26°, 1800 K - 2700 K, 6.5 W
    DALI-2
    noir, Noir profond, flood, 37°, 2700 K, 12.2 W
    non DIM
    noir, Noir profond, medium, 26°, 2700 K, 12.2 W
    non DIM
    noir, Noir profond, flood, 37°, 2700 K, 12.2 W
    DALI-2
    noir, Noir profond, medium, 26°, 2700 K, 12.2 W
    DALI-2
    noir, Noir profond, flood, 37°, 3000 K, 12.2 W
    non DIM
    noir, Noir profond, medium, 26°, 3000 K, 12.2 W
    non DIM
    noir, Noir profond, flood, 37°, 3000 K, 12.2 W
    DALI-2
    noir, Noir profond, medium, 26°, 3000 K, 12.2 W
    DALI-2
    noir, Noir profond, flood, 37°, 4000 K, 12.2 W
    non DIM
    noir, Noir profond, medium, 26°, 4000 K, 12.2 W
    non DIM
    noir, Noir profond, flood, 37°, 4000 K, 12.2 W
    DALI-2
    noir, Noir profond, medium, 26°, 4000 K, 12.2 W
    DALI-2
    SASSO PRO 80 adjustable flush trim round;SASSO PRO 80 adjustable flush trim round concrete;SASSO PRO 80 trim/trimless

    SASSO PRO 80 adjustable flush trim round

    SASSO PRO 80 adjustable flush trim round

    Statut
    Numéro(s) article(s)
    Type
    Dimming
    blanc, blanc signalisation, flood, 37°, 2700 K, 8.3 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 2700 K, 8.3 W
    non DIM
    blanc, blanc signalisation, super spot, 8°, 2700 K, 7.7 W
    non DIM
    blanc, blanc signalisation, flood, 37°, 3000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 3000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, super spot, 8°, 3000 K, 7.7 W
    non DIM
    blanc, blanc signalisation, flood, 37°, 4000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 4000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, super spot, 8°, 4000 K, 7.7 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 1800 K - 2700 K, 6.5 W
    DALI-2
    blanc, blanc signalisation, flood, 37°, 2700 K, 12.2 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 2700 K, 12.2 W
    non DIM
    blanc, blanc signalisation, flood, 37°, 2700 K, 12.2 W
    DALI-2
    blanc, blanc signalisation, medium, 26°, 2700 K, 12.2 W
    DALI-2
    blanc, blanc signalisation, flood, 37°, 3000 K, 12.2 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 3000 K, 12.2 W
    non DIM
    blanc, blanc signalisation, flood, 37°, 3000 K, 12.2 W
    DALI-2
    blanc, blanc signalisation, medium, 26°, 3000 K, 12.2 W
    DALI-2
    blanc, blanc signalisation, flood, 37°, 4000 K, 12.2 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 4000 K, 12.2 W
    non DIM
    blanc, blanc signalisation, flood, 37°, 4000 K, 12.2 W
    DALI-2
    blanc, blanc signalisation, medium, 26°, 4000 K, 12.2 W
    DALI-2
    SASSO PRO 80 adjustable flush trim round;SASSO PRO 80 adjustable flush trim round concrete

    SASSO PRO 80 adjustable flush trim round

    SASSO PRO 80 adjustable flush trim round

    Statut
    Numéro(s) article(s)
    Type
    Dimming
    noir, blanc signalisation, flood, 37°, 2700 K, 8.3 W
    non DIM
    noir, blanc signalisation, medium, 26°, 2700 K, 8.3 W
    non DIM
    noir, blanc signalisation, super spot, 8°, 2700 K, 7.7 W
    non DIM
    noir, blanc signalisation, flood, 37°, 3000 K, 8.3 W
    non DIM
    noir, blanc signalisation, medium, 26°, 3000 K, 8.3 W
    non DIM
    noir, blanc signalisation, super spot, 8°, 3000 K, 7.7 W
    non DIM
    noir, blanc signalisation, flood, 37°, 4000 K, 8.3 W
    non DIM
    noir, blanc signalisation, medium, 26°, 4000 K, 8.3 W
    non DIM
    noir, blanc signalisation, super spot, 8°, 4000 K, 7.7 W
    non DIM
    noir, blanc signalisation, medium, 26°, 1800 K - 2700 K, 6.5 W
    DALI-2
    noir, blanc signalisation, flood, 37°, 2700 K, 12.2 W
    non DIM
    noir, blanc signalisation, medium, 26°, 2700 K, 12.2 W
    non DIM
    noir, blanc signalisation, flood, 37°, 2700 K, 12.2 W
    DALI-2
    noir, blanc signalisation, medium, 26°, 2700 K, 12.2 W
    DALI-2
    noir, blanc signalisation, flood, 37°, 3000 K, 12.2 W
    non DIM
    noir, blanc signalisation, medium, 26°, 3000 K, 12.2 W
    non DIM
    noir, blanc signalisation, flood, 37°, 3000 K, 12.2 W
    DALI-2
    noir, blanc signalisation, medium, 26°, 3000 K, 12.2 W
    DALI-2
    noir, blanc signalisation, flood, 37°, 4000 K, 12.2 W
    non DIM
    noir, blanc signalisation, medium, 26°, 4000 K, 12.2 W
    non DIM
    noir, blanc signalisation, flood, 37°, 4000 K, 12.2 W
    DALI-2
    noir, blanc signalisation, medium, 26°, 4000 K, 12.2 W
    DALI-2
    SASSO PRO 80 adjustable flush concrete;SASSO PRO 80 adjustable flush trimless;SASSO PRO 80 adjustable flush trimless concrete

    SASSO PRO 80 adjustable flush trimless

    SASSO PRO 80 adjustable flush trimless

    Statut
    Numéro(s) article(s)
    Type
    Dimming
    blanc, blanc signalisation, flood, 37°, 2700 K, 8.3 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 2700 K, 8.3 W
    non DIM
    blanc, blanc signalisation, super spot, 8°, 2700 K, 7.7 W
    non DIM
    blanc, blanc signalisation, flood, 37°, 3000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 3000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, super spot, 8°, 3000 K, 7.7 W
    non DIM
    blanc, blanc signalisation, flood, 37°, 4000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 4000 K, 8.3 W
    non DIM
    blanc, blanc signalisation, super spot, 8°, 4000 K, 7.7 W
    non DIM
    blanc, blanc signalisation, medium, 26°, 1800 K - 2700 K, 6.5 W
    DALI-2
    blanc, blanc signalisation, flood, 37°, 2700 K, 12.2 W
    non DIM
