SPOTLINE MOVE IT PRO
SPOTLINE MOVE IT PRO
Visualisation

SPOTLINE

MOVE IT PRO 1.5

Coming

Quickinfo

2700 K, 3000 K, 3500 K, 4000 K
CRI ≥ 90 / 3 SDCM (initial MacAdam)
UGR ≤ 10, UGR ≤ 13, UGR ≤ 16
up to 145 lm/W
L85 / 50000 h, L90 / 100000 h
0-10 V
IP20

Available from Q4/26

Cut sheet
Order codes & files
Discover family

Simple drawing

Light distribution

Cut sheet

Download all
Download all
  • IES
  • LDT

Description

Linear light inset made of plastic; light inset, incl. high power adapter + converter can be installed flexibly and without tools; flush with profile system; fitted with single LED light points; good glare reduction due to recessed light point plane; despite this increased efficiency through special lens technology; inserted lenses with medium or wide flood radiation characteristic; for use in schools, retail and offices; energy-efficient LEDs with excellent color rendering

low-glare design (UGR ≤ 19)

up to 145 lm/W (high efficiency)

Order codes & files

Filter
Length
Color Temperature
Beam
Finish
white
black
SPOTLINE MOVE IT PRO

SPOTLINE MOVE IT PRO 1.5

SPOTLINE MOVE IT PRO 1.5

Status
Article number(s)
Type
Dimming
jet black, medium, 2700 K, 99 lm/W
0-10 V
jet black, wide flood, 2700 K, 123 lm/W
0-10 V
jet black, medium, 3000 K, 104 lm/W
0-10 V
jet black, wide flood, 3000 K, 123 lm/W
0-10 V
jet black, medium, 3500 K, 82 lm/W
0-10 V
jet black, wide flood, 3500 K, 123 lm/W
0-10 V
jet black, medium, 4000 K, 111 lm/W
0-10 V
jet black, wide flood, 4000 K, 133 lm/W
0-10 V
jet black, medium, 2700 K, 98 lm/W
0-10 V
jet black, wide flood, 2700 K, 125 lm/W
0-10 V
jet black, medium, 3000 K, 103 lm/W
0-10 V
jet black, wide flood, 3000 K, 125 lm/W
0-10 V
jet black, medium, 3500 K, 84 lm/W
0-10 V
jet black, wide flood, 3500 K, 125 lm/W
0-10 V
jet black, medium, 4000 K, 110 lm/W
0-10 V
jet black, wide flood, 4000 K, 135 lm/W
0-10 V
jet black, medium, 2700 K, 98 lm/W
0-10 V
jet black, wide flood, 2700 K, 125 lm/W
0-10 V
jet black, medium, 3000 K, 103 lm/W
0-10 V
jet black, wide flood, 3000 K, 125 lm/W
0-10 V
jet black, medium, 3500 K, 83 lm/W
0-10 V
jet black, wide flood, 3500 K, 125 lm/W
0-10 V
jet black, medium, 4000 K, 110 lm/W
0-10 V
jet black, wide flood, 4000 K, 135 lm/W
0-10 V
jet black, medium, 2700 K, 100 lm/W
0-10 V
jet black, wide flood, 2700 K, 127 lm/W
0-10 V
jet black, medium, 3000 K, 105 lm/W
0-10 V
jet black, wide flood, 3000 K, 127 lm/W
0-10 V
jet black, medium, 3500 K, 83 lm/W
0-10 V
jet black, wide flood, 3500 K, 127 lm/W
0-10 V
jet black, medium, 4000 K, 112 lm/W
0-10 V
jet black, wide flood, 4000 K, 137 lm/W
0-10 V
SPOTLINE MOVE IT PRO

SPOTLINE MOVE IT PRO 1.5

SPOTLINE MOVE IT PRO 1.5

Status
Article number(s)
Type
Dimming
traffic white, medium, 2700 K, 113 lm/W
0-10 V
traffic white, wide flood, 2700 K, 130 lm/W
0-10 V
traffic white, medium, 3000 K, 119 lm/W
0-10 V
traffic white, wide flood, 3000 K, 130 lm/W
0-10 V
traffic white, medium, 3500 K, 94 lm/W
0-10 V
traffic white, wide flood, 3500 K, 130 lm/W
0-10 V
traffic white, medium, 4000 K, 128 lm/W
0-10 V
traffic white, wide flood, 4000 K, 140 lm/W
0-10 V
traffic white, medium, 2700 K, 112 lm/W
0-10 V
traffic white, wide flood, 2700 K, 132 lm/W
0-10 V
traffic white, medium, 3000 K, 118 lm/W
0-10 V
traffic white, wide flood, 3000 K, 132 lm/W
0-10 V
traffic white, medium, 3500 K, 96 lm/W
0-10 V
traffic white, wide flood, 3500 K, 132 lm/W
0-10 V
traffic white, medium, 4000 K, 126 lm/W
0-10 V
traffic white, wide flood, 4000 K, 142 lm/W
0-10 V
traffic white, medium, 2700 K, 112 lm/W
0-10 V
traffic white, wide flood, 2700 K, 132 lm/W
0-10 V
traffic white, medium, 3000 K, 118 lm/W
0-10 V
traffic white, wide flood, 3000 K, 132 lm/W
0-10 V
traffic white, medium, 3500 K, 95 lm/W
0-10 V
traffic white, wide flood, 3500 K, 132 lm/W
0-10 V
traffic white, medium, 4000 K, 126 lm/W
0-10 V
traffic white, wide flood, 4000 K, 142 lm/W
0-10 V
traffic white, medium, 2700 K, 114 lm/W
0-10 V
traffic white, wide flood, 2700 K, 134 lm/W
0-10 V
traffic white, medium, 3000 K, 120 lm/W
0-10 V
traffic white, wide flood, 3000 K, 134 lm/W
0-10 V
traffic white, medium, 3500 K, 95 lm/W
0-10 V
traffic white, wide flood, 3500 K, 134 lm/W
0-10 V
traffic white, medium, 4000 K, 129 lm/W
0-10 V
traffic white, wide flood, 4000 K, 145 lm/W
0-10 V

System products

Coming

MOVE IT PRO 1.5

trimless system
Cut sheet
Coming

MOVE IT PRO 1.5

surface / suspended system
Cut sheet
