TUBO | SETA 60 CONEX

surface / suspended system

Nueva longitud

Información rápida

3000 K, 4000 K
CRI ≥ 80 / 3 SDCM
UGR ≤ 10, 13, 16, 19
hasta 8,190 lm/↑ 9,080 lm
hasta 149 lm/W
L90 / 50000 h
DALI-2
High Performance Opal, Reflector
IP20
Productos del sistema
Descubrir familia

Plano simple

Distribución de la luz

Descargar todo
Descargar todo
  • ROLF
  • ULD

Descripción

Sistema de iluminación cilíndrico de aluminio; recubierto de polvo; montaje sobre techo o suspendido; altura regulable sin herramientas; incl. cable de alimentación transparente; unión eléctrica de las luminarias con conexión macho/hembra; conector opcional (en forma de L, T o X); conexión de luminaria girable en su propio eje que permite la orientación en cualquier ángulo de la sala; disponible con difusor cilíndr. HPO (High Performance Opal) o reflector de alto brillo con óptica facetada; direccionamiento de la luz con óptica de lente de alta calidad para un alumbrado homogéneo (HPO); proyección directa, indirecta o directa/indirecta (reflector); componente de luz indir. con plet. propias y ópt. de lente de alta calidad para un alumb. de techo y homog. con control indep.; LED energét. efic. - excelente reprod. crom.

conector CONEX

combinable con TUBO & SETA

hasta 132 lm/W (high efficiency)

DIN EN 12464-1 UGR ≤ 19

iluminación directa sin deslumbramiento e indirecta a 170°

iluminación homogénea

System components

Click to see components

SETA 60 indirect surface / suspended system;SETA 60 CONEX indirect surface / suspended system

SETA 60 CONEX indirect surface / suspended system

3000 K, 4000 K
CRI ≥ 80 / 3 SDCM
UGR ≤ 10, 13, 16, 19
hasta 8,190 lm/↑ 9,080 lm
hasta 149 lm/W
L90 / 50000 h
DALI-2
High Performance Opal, Reflector
IP20
TUBO 60 CONEX surface / suspended system;TUBO 60 surface / suspended system

TUBO 60 surface / suspended system

3000 K, 4000 K
CRI ≥ 80 / 3 SDCM
UGR ≤ 10, 13, 16, 19
hasta 8,190 lm/↑ 9,080 lm
hasta 149 lm/W
L90 / 50000 h
DALI-2
High Performance Opal, Reflector
IP20

BLIND CHANNEL CONEX system

con cableado pasante

CONEX CONNECTOR

mecánico y eléctrico

TUBO END CAPS

5 × 1.5 mm²

TUBO CONNECTOR

1 pieza, 10 piezas, mecánico angular 60° | con conector cubierta opalina, mecánico y eléctrico angular 60° | con conector cubierta opalina, mecánico y eléctrico | con conector cubierta opalina, mecánico | con conector cubierta opalina

TUBO 60 SUSPENSION

angular máx. 60°

TUBO END CAPS

1 par

Productos y códigos

Filtro
95
lm/W
149
lm/W
1880
lm
9080
lm
3490
lm
9080
lm
1181
mm
2936
mm
19.6
W
118
W
0.56
0.72
0.51
0.65

Color

    • Reflector

    • SETA 60 indirect surface / suspended system;SETA 60 CONEX indirect surface / suspended system

    SETA 60 CONEX indirect surface / suspended system

    SETA 60 CONEX indirect surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    blanco, 3000 K, 26,6 W, 131 lm/W, 1.181 mm
    DALI-2
    blanco, 4000 K, 26,6 W, 136 lm/W, 1.181 mm
    DALI-2
    blanco, 3000 K, 33 W, 132 lm/W, 1.474 mm
    DALI-2
    blanco, 4000 K, 33 W, 137 lm/W, 1.474 mm
    DALI-2
    blanco, 3000 K, 53 W, 132 lm/W, 2.351 mm
    DALI-2
    blanco, 4000 K, 53 W, 137 lm/W, 2.351 mm
    DALI-2
    blanco, 3000 K, 66 W, 132 lm/W, 2.936 mm
    DALI-2
    blanco, 4000 K, 66 W, 138 lm/W, 2.936 mm
    DALI-2
    SETA 60 indirect surface / suspended system;SETA 60 CONEX indirect surface / suspended system

    SETA 60 CONEX indirect surface / suspended system

    SETA 60 CONEX indirect surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    negro, 3000 K, 26,6 W, 131 lm/W, 1.181 mm
    DALI-2
    negro, 4000 K, 26,6 W, 136 lm/W, 1.181 mm
    DALI-2
    negro, 3000 K, 33 W, 132 lm/W, 1.474 mm
    DALI-2
    negro, 4000 K, 33 W, 137 lm/W, 1.474 mm
    DALI-2
    negro, 3000 K, 53 W, 132 lm/W, 2.351 mm
    DALI-2
    negro, 4000 K, 53 W, 137 lm/W, 2.351 mm
    DALI-2
    negro, 3000 K, 66 W, 132 lm/W, 2.936 mm
    DALI-2
    negro, 4000 K, 66 W, 138 lm/W, 2.936 mm
    DALI-2
    SETA linear direct ceiling / suspended system;SETA linear direct / indirect power suspended system;SETA linear direct / indirect TW power suspended system;SETA 60 reflector direct / indirect surface / suspended system;SETA 60 reflector direct surface / suspended system;SETA 60 CONEX reflector direct / indirect surface / suspended system;SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    blanco, 3000 K, 46 W, 133 lm/W, 1.181 mm
    DALI-2
    blanco, 4000 K, 46 W, 138 lm/W, 1.181 mm
    DALI-2
    blanco, 3000 K, 56 W, 136 lm/W, 1.474 mm
    DALI-2
    blanco, 4000 K, 56 W, 149 lm/W, 1.474 mm
    DALI-2
    blanco, 3000 K, 93 W, 141 lm/W, 2.351 mm
    DALI-2
    blanco, 4000 K, 93 W, 147 lm/W, 2.351 mm
    DALI-2
    blanco, 3000 K, 118 W, 141 lm/W, 2.936 mm
    DALI-2
    blanco, 4000 K, 118 W, 146 lm/W, 2.936 mm
    DALI-2
    SETA linear direct ceiling / suspended system;SETA linear direct / indirect power suspended system;SETA linear direct / indirect TW power suspended system;SETA 60 reflector direct / indirect surface / suspended system;SETA 60 reflector direct surface / suspended system;SETA 60 CONEX reflector direct / indirect surface / suspended system;SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    negro, 3000 K, 46 W, 133 lm/W, 1.181 mm
    DALI-2
    negro, 4000 K, 46 W, 138 lm/W, 1.181 mm
    DALI-2
    negro, 3000 K, 56 W, 136 lm/W, 1.474 mm
    DALI-2
    negro, 4000 K, 56 W, 149 lm/W, 1.474 mm
    DALI-2
    negro, 3000 K, 93 W, 141 lm/W, 2.351 mm
    DALI-2
    negro, 4000 K, 93 W, 147 lm/W, 2.351 mm
    DALI-2
    negro, 3000 K, 118 W, 141 lm/W, 2.936 mm
    DALI-2
    negro, 4000 K, 118 W, 146 lm/W, 2.936 mm
    DALI-2
    SETA linear direct ceiling / suspended system;SETA linear direct / indirect power suspended system;SETA linear direct / indirect TW power suspended system;SETA 60 reflector direct / indirect surface / suspended system;SETA 60 reflector direct surface / suspended system;SETA 60 CONEX reflector direct / indirect surface / suspended system;SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    blanco, 3000 K, 46 W, 117 lm/W, 1.181 mm
    DALI-2
    blanco, 4000 K, 46 W, 121 lm/W, 1.181 mm
    DALI-2
    blanco, 3000 K, 56 W, 120 lm/W, 1.474 mm
    DALI-2
    blanco, 4000 K, 56 W, 132 lm/W, 1.474 mm
    DALI-2
    blanco, 3000 K, 93 W, 122 lm/W, 2.351 mm
    DALI-2
    blanco, 4000 K, 93 W, 127 lm/W, 2.351 mm
    DALI-2
    blanco, 3000 K, 118 W, 122 lm/W, 2.936 mm
    DALI-2
    blanco, 4000 K, 118 W, 127 lm/W, 2.936 mm
    DALI-2
    SETA linear direct ceiling / suspended system;SETA linear direct / indirect power suspended system;SETA linear direct / indirect TW power suspended system;SETA 60 reflector direct / indirect surface / suspended system;SETA 60 reflector direct surface / suspended system;SETA 60 CONEX reflector direct / indirect surface / suspended system;SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    SETA 60 CONEX reflector direct / indirect surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    negro, 3000 K, 46 W, 117 lm/W, 1.181 mm
    DALI-2
    negro, 4000 K, 46 W, 121 lm/W, 1.181 mm
    DALI-2
    negro, 3000 K, 56 W, 120 lm/W, 1.474 mm
    DALI-2
    negro, 4000 K, 56 W, 132 lm/W, 1.474 mm
    DALI-2
    negro, 3000 K, 93 W, 122 lm/W, 2.351 mm
    DALI-2
    negro, 4000 K, 93 W, 127 lm/W, 2.351 mm
    DALI-2
    negro, 3000 K, 118 W, 122 lm/W, 2.936 mm
    DALI-2
    negro, 4000 K, 118 W, 127 lm/W, 2.936 mm
    DALI-2
    SETA linear direct ceiling / suspended system;SETA linear direct / indirect power suspended system;SETA linear direct / indirect TW power suspended system;SETA 60 reflector direct / indirect surface / suspended system;SETA 60 reflector direct surface / suspended system;SETA 60 CONEX reflector direct / indirect surface / suspended system;SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    blanco, 3000 K, 19,6 W, 134 lm/W, 1.181 mm
    DALI-2
    blanco, 4000 K, 19,6 W, 139 lm/W, 1.181 mm
    DALI-2
    blanco, 3000 K, 24 W, 135 lm/W, 1.474 mm
    DALI-2
    blanco, 4000 K, 24 W, 140 lm/W, 1.474 mm
    DALI-2
    blanco, 3000 K, 46 W, 133 lm/W, 2.351 mm
    DALI-2
    blanco, 4000 K, 46 W, 138 lm/W, 2.351 mm
    DALI-2
    blanco, 3000 K, 59 W, 134 lm/W, 2.936 mm
    DALI-2
    blanco, 4000 K, 59 W, 139 lm/W, 2.936 mm
    DALI-2
    SETA linear direct ceiling / suspended system;SETA linear direct / indirect power suspended system;SETA linear direct / indirect TW power suspended system;SETA 60 reflector direct / indirect surface / suspended system;SETA 60 reflector direct surface / suspended system;SETA 60 CONEX reflector direct / indirect surface / suspended system;SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct surface / suspended system

    SETA 60 CONEX reflector direct surface / suspended system

    Estado
    Número(s) de artículo
    Tipo
    Dimmable
    negro, 3000 K, 19,6 W, 134 lm/W, 1.181 mm
    DALI-2
    negro, 4000 K, 19,6 W, 139 lm/W, 1.181 mm
    DALI-2
    negro, 3000 K, 24 W, 135 lm/W, 1.474 mm
    DALI-2
    negro, 4000 K, 24 W, 140 lm/W, 1.474 mm
    DALI-2
